Atoms in complex twisted light

The coupling of the light to all the atomic multipoles is achievable via a PZW canonical transformation or, equivalently, a gauge transformation involving a characteristic generating function S in the form [13, 16]

$\begin{eqnarray}&&{\rm{\Lambda }}={e}^{{iS}}={e}^{\tfrac{-i}{{\hslash }}\int {\boldsymbol{ \mathcal Q }}({\bf{r}})\cdot {{\bf{A}}}^{\perp }({\bf{r}})d{\bf{r}}}.\end{eqnarray} \tag{ 14 }$

This unitary transformation gives rise to a new Hamiltonian H_new which has the same form as the old Hamiltonian H, and to mark the distinction we now represent all transformed canonical variables with a prime. We have

$\begin{eqnarray}\begin{array}{rcl}{H}_{{new}} & = & \displaystyle \frac{{[{\bf{p}}{{\prime} }_{1}+{e}_{1}{{\bf{A}}}^{\perp }({{\bf{q}}}_{1})]}^{2}}{2{m}_{1}}+\displaystyle \frac{{[{\bf{p}}{{\prime} }_{2}+{e}_{2}{{\bf{A}}}^{\perp }({{\bf{q}}}_{2})]}^{2}}{2{m}_{2}}\\ & & +\displaystyle \frac{{e}_{1}{e}_{2}}{4\pi {\epsilon }_{0}| {{\bf{q}}}_{1}-{{\bf{q}}}_{2}| }+\displaystyle \frac{1}{2}\displaystyle \int \left(\displaystyle \frac{{\boldsymbol{\Pi }}{{\prime} }^{{\perp }^{2}}}{{\epsilon }_{0}}+\displaystyle \frac{{{\bf{B}}}^{2}}{{\mu }_{0}}\right)d{\bf{r}}.\end{array}\end{eqnarray} \tag{ 15 }$

After transformation, the new momenta ${{\bf{p}}}_{\alpha }^{{\prime} }$ and ${\boldsymbol{\Pi }}{{\prime} }^{\perp }$ are given by

$\begin{eqnarray}&&{\bf{p}}{{\prime} }_{\alpha }={e}^{-{iS}}{{\bf{p}}}_{\alpha }{e}^{{iS}}={{\bf{p}}}_{\alpha }+i[{{\bf{p}}}_{\alpha },S],\end{eqnarray} \tag{ 16 }$

$\begin{eqnarray}&&{\boldsymbol{\Pi }}{{\prime} }^{\perp }={e}^{-{iS}}{{\boldsymbol{\Pi }}}^{\perp }{e}^{{iS}}={{\boldsymbol{\Pi }}}^{\perp }+i[{{\boldsymbol{\Pi }}}^{\perp },S].\end{eqnarray} \tag{ 17 }$

The evaluations of equations (16) and (17) both involve a commutator series, but it is easy to verify that both series terminate at the first commutator in each case due to the form of S in equation (14). We find

$\begin{eqnarray}&&{\bf{p}}{{\prime} }_{\alpha }={{\bf{p}}}_{\alpha }+{\hslash }{{\boldsymbol{\nabla }}}^{\alpha }S,\end{eqnarray} \tag{ 18 }$

$\begin{eqnarray}&&{\boldsymbol{\Pi }}{{\prime} }^{\perp }({\bf{r}})={{\boldsymbol{\Pi }}}^{\perp }({\bf{r}})-{{\boldsymbol{ \mathcal Q }}}^{\perp }({\bf{r}}),\end{eqnarray} \tag{ 19 }$

where ${{\boldsymbol{\nabla }}}^{\alpha }$ in equation (18) denotes differentiation with respect to the canonical coordinate q_α. The vector field ${{\boldsymbol{ \mathcal Q }}}^{\perp }$ appearing in equation (19) stands for the transverse vector field part of the electric polarisation vector field given in equation (8), having made use of the commutation relations in equation (7).

The formal multipolar Hamiltonian follows from equation (15) by direct use of equations (18) and (19). The next steps involve the division of the motion into the internal motion (which is characterised by the appearance of the relative coordinate q), and the gross motion involving the centre of mass coordinate R.

Although we can continue the treatment without further recall of a multipolar expansion, it is instructive to focus again on the approximation in which the electric polarisation vector field takes its truncated form in equation (11) with leading contributions including only the electric dipole and the electric quadrupole terms We obtain for ${{\boldsymbol{\nabla }}}^{\alpha }S$ after some algebra

$\begin{eqnarray}&&{\hslash }{{\boldsymbol{\nabla }}}^{\alpha }S=-{e}_{\alpha }{{\bf{A}}}^{\perp }({{\bf{q}}}_{\alpha })+\displaystyle \frac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}}).\end{eqnarray} \tag{ 20 }$

Hence we can write for the transformed momenta, equations (18) and (19)

$\begin{eqnarray}&&{\bf{p}}{{\prime} }_{\alpha }={{\bf{p}}}_{\alpha }-{e}_{\alpha }{{\bf{A}}}^{\perp }({{\bf{q}}}_{\alpha })+\displaystyle \frac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}}),\end{eqnarray} \tag{ 21 }$

$\begin{eqnarray}&&{\boldsymbol{\Pi }}{{\prime} }^{\perp }({\bf{r}})={{\boldsymbol{\Pi }}}^{\perp }({\bf{r}})-{{\boldsymbol{ \mathcal Q }}}^{\perp }({\bf{r}}).\end{eqnarray} \tag{ 22 }$

Note that the last term in equation (21) does not depend on α. Finally, substituting from equations (21) and (22) in equation (15), we obtain the transformed Hamiltonian in the following form

$\begin{eqnarray}\begin{array}{rcl}{H}_{{new}} & = & \displaystyle \sum _{\alpha =1,2}\displaystyle \frac{{\left|{{\bf{p}}}_{\alpha }+\tfrac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}})\right|}^{2}}{2{m}_{\alpha }}-\displaystyle \frac{{e}^{2}}{4\pi {\epsilon }_{0}{\rm{q}}}\\ & & +\displaystyle \frac{1}{2}\displaystyle \int \left\{\displaystyle \frac{{| {{\boldsymbol{\Pi }}}^{\perp }({\bf{r}})-{{\boldsymbol{ \mathcal Q }}}^{\perp }({\bf{r}})| }^{2}}{{\epsilon }_{0}}+\displaystyle \frac{{\bf{B}}{({\bf{r}})}^{2}}{{\mu }_{0}}\right\}d{\bf{r}}.\end{array}\end{eqnarray} \tag{ 23 }$

To arrive at a theory with explicit division of the motion into internal and gross motions, we have to define the centre of mass momentum P conjugate to the centre of mass position vector R, as defined in equation (9)

$\begin{eqnarray}&&{\bf{P}}={{\bf{p}}}_{1}+{{\bf{p}}}_{2}\end{eqnarray} \tag{ 24 }$

and the internal momentum p conjugate to the internal variable q by

$\begin{eqnarray}&&{\bf{p}}=\displaystyle \frac{{m}_{2}{{\bf{p}}}_{1}-{m}_{1}{{\bf{p}}}_{2}}{M};\,\,\,{\bf{q}}={{\bf{q}}}_{1}-{{\bf{q}}}_{2}.\end{eqnarray} \tag{ 25 }$

We can then express p₁ and p₂ in terms of P and p as follows

$\begin{eqnarray}&&{{\bf{p}}}_{\alpha }=\displaystyle \frac{{m}_{\alpha }}{M}{\bf{P}}+{(-1)}^{\alpha +1}{\bf{p}};\,\,\,\alpha =1,2.\end{eqnarray} \tag{ 26 }$

Equation (26) enables the explicit change from the particle canonical variables ${{\bf{q}}}_{{\boldsymbol{\alpha }}}$ and p_α to internal variables (q, p) and gross motion variables (R, P). That the new pairs are independent canonical variables can easily be checked. We have $[{{\rm{P}}}_{i},{{\rm{R}}}_{j}]=-i{\hslash }{\delta }_{{ij}};\,[{{\rm{p}}}_{i},{{\rm{q}}}_{j}]=-i{\hslash }{\delta }_{{ij}}$ and $[{{\rm{P}}}_{i},{{\rm{q}}}_{j}]=0\,=[{{\rm{p}}}_{i},{{\rm{R}}}_{j}]$ which follow by direct use of the commutator $[{{\rm{p}}}_{\alpha i},{{\rm{q}}}_{\beta j}]=-i{\hslash }{\delta }_{\alpha \beta }{\delta }_{{ij}}.$ The above commutator relationships ensure that the new variables conform with the requirements for independent sets representing two independent motions in the absence of coupling. Substituting from equation (26) in equation (23), we get

$\begin{eqnarray}\begin{array}{rcl}{H}_{{new}} & = & \displaystyle \sum _{\alpha =1,2}\left(\displaystyle \frac{{\left|\tfrac{{\bf{P}}}{M}{m}_{\alpha }+{(-1)}^{\alpha +1}{\bf{p}}+\tfrac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}})\right|}^{2}}{2{m}_{\alpha }}\right)\\ & & -\displaystyle \frac{{e}^{2}}{4\pi {\epsilon }_{0}{\rm{q}}}+\displaystyle \frac{1}{2}\displaystyle \int \left[\displaystyle \frac{{| {{\boldsymbol{\Pi }}}^{\perp }({\bf{r}})-{{\boldsymbol{ \mathcal Q }}}^{\perp }({\bf{r}})| }^{2}}{{\epsilon }_{0}}+\displaystyle \frac{{{\bf{B}}}^{2}({\bf{r}})}{{\mu }_{0}}\right]d{\bf{r}}.\end{array}\end{eqnarray} \tag{ 27 }$

The Hamiltonian (27) simplifies considerably on expanding the square and we find

$\begin{eqnarray}\begin{array}{rcl}{H}_{{new}} & = & \displaystyle \frac{{{\bf{P}}}^{2}}{2M}+\left(\displaystyle \frac{{{\bf{p}}}^{2}}{2\mu }-\displaystyle \frac{{e}^{2}}{4\pi {\epsilon }_{0}{\rm{q}}}\right)\\ & & +\displaystyle \frac{1}{2}\displaystyle \int \left(\displaystyle \frac{{{{\rm{\Pi }}}^{\perp }({\bf{r}})}^{2}}{{\epsilon }_{0}}+\displaystyle \frac{{B}^{2}({\bf{r}})}{{\mu }_{0}}\right)d{\bf{r}}+\displaystyle \frac{1}{{\epsilon }_{0}}{\bf{D}}.{{\boldsymbol{\Pi }}}^{\perp }({\bf{R}})\\ & & +\displaystyle \frac{1}{2M}({\bf{P}}.{\bf{D}}\times {\bf{B}}({\bf{R}})+{\bf{D}}\times {\bf{B}}({\bf{R}}).{\bf{P}})\\ & & +\displaystyle \frac{{[{\bf{D}}\times {\bf{B}}({\bf{R}})]}^{2}}{8\mu }+\displaystyle \frac{1}{2{\epsilon }_{0}}\displaystyle \int {{\boldsymbol{ \mathcal Q }}}^{\perp }{({\bf{r}})}^{2}d{\bf{r}}+{\boldsymbol{ \mathcal M }}\cdot {\bf{B}}({\bf{R}}),\end{array}\end{eqnarray} \tag{ 28 }$

where μ is the reduced mass $\mu =({m}_{1}{m}_{2})/M$ and coupling terms are given in the truncated approximation. The ultimate term involves the magnetic moment ${\boldsymbol{ \mathcal M }}$ coupling to the magnetic field also in the truncated approximation. This term arises from the product between p and D × B. In the dipole approximation where ${\bf{D}}={\bf{d}}$, the leading contribution to the magnetic dipole moment is

$\begin{eqnarray}&&{\boldsymbol{ \mathcal M }}=\displaystyle \frac{1}{2{m}_{e}}{\bf{d}}\times {\bf{p}}.\end{eqnarray} \tag{ 29 }$

Equation (28) is the non-relativistic Hamiltonian for the electrically neutral two-particle atom in interaction with light. It is seen that the internal electronic-type motion is essentially separated from the gross motion, but these two subsystems of the atom are coupled by mutual interactions between charges and with the light fields. Amongst the various terms there are three that essentially represent unperturbed components of the system; these are the (zero-order) Hamiltonians representing the gross (centre of mass) motion, the internal (electronic-type) motion and the light fields—which appear as the first three terms of equation (28). Other terms represent couplings between the three subsystems; the fourth term represents the coupling of the atomic dipole as well as the quadrupole moments to the transverse part of the displacement field ${{\boldsymbol{\Pi }}}^{\perp }$ (evaluated at the centre of mass coordinate R); the fifth constitutes the leading interaction involving the centre of mass with the truncated multipole moment and the magnetic field; the sixth is the diamagnetic field-type energy and the seventh term is an integral of the square of the polarisation field. The latter is a self energy contributing to the Lamb shift and may be absorbed in any renormalised energies pertaining to the internal motion. Finally, the last term is the leading interaction between the magnetic dipole of the atom and the magnetic field of the light, evaluated at the centre of mass R.

A prominent feature of the Hamiltonian in equation (28), when taken in the truncated multipole approximation is the appearance of the term D × B. In the electric dipole approximation, this can be written as eA_R where A_R = q × B. Clearly A_R plays the role of an electrodynamic vector potential. The significance of this can readily be seen by considering the particle canonical momenta. From equation (21), we can write

$\begin{eqnarray}&&({\bf{p}}{{\prime} }_{\alpha }+{e}_{\alpha }{{\bf{A}}}^{\perp }({{\bf{q}}}_{\alpha }))={{\bf{p}}}_{\alpha }+\displaystyle \frac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}}).\end{eqnarray} \tag{ 30 }$

The left hand side is equal to ${m}_{\alpha }{\dot{{\bf{q}}}}_{\alpha }$, so we can write

$\begin{eqnarray}&&{m}_{\alpha }{\dot{{\bf{q}}}}_{\alpha }={{\bf{p}}}_{\alpha }+\displaystyle \frac{1}{2}{\bf{D}}\times {\bf{B}}({\bf{R}}).\end{eqnarray} \tag{ 31 }$

Summation over α = 1, 2 in all terms we get

$\begin{eqnarray}&&\displaystyle \sum _{\alpha =1,2}{m}_{\alpha }{\dot{{\bf{q}}}}_{\alpha }=\displaystyle \sum _{\alpha =1,2}{{\bf{p}}}_{\alpha }+{\bf{D}}\times {\bf{B}}({\bf{R}}).\end{eqnarray} \tag{ 32 }$

Using equation (9), the left hand side of equation (32) is exactly $M\dot{{\bf{R}}}$ while the first term on the right hand side is just P. We therefore have

$\begin{eqnarray}&&M\dot{{\bf{R}}}={\bf{P}}+{\bf{D}}\times {\bf{B}}({\bf{R}}).\end{eqnarray} \tag{ 33 }$

The relationship in (33) is between the canonical momentum P and the mechanical momentum $M\dot{{\bf{R}}}$ of the centre of mass in the truncated multipole approximation. The result also follows as a Heisenberg operator equation based on the Hamiltonian in equation (28). We have,

$\begin{eqnarray}&&\dot{{\bf{R}}}=\displaystyle \frac{i}{{\hslash }}[{H}_{{new}},{\bf{R}}]=\displaystyle \frac{({\bf{P}}+{\bf{D}}\times {\bf{B}}({\bf{R}}))}{M}.\end{eqnarray} \tag{ 34 }$

The radiation pressure force acting on the centre of mass in the dipole approximation follows from equation (33) by total time differentiation

$\begin{eqnarray}&&{\bf{F}}=\displaystyle \frac{d}{{dt}}(M\dot{{\bf{R}}})=\displaystyle \frac{d{\bf{P}}}{{dt}}+\displaystyle \frac{d}{{dt}}({\bf{D}}\times {\bf{B}}).\end{eqnarray} \tag{ 35 }$

The force also follows from equation (34) as a Heisenberg operator equation in the form

$\begin{eqnarray}\begin{array}{rcl}M\ddot{{\bf{R}}} & = & \displaystyle \frac{i}{{\hslash }}[{H}_{{new}},({\bf{P}}+{\bf{D}}\times {\bf{B}})]\\ & = & -{\boldsymbol{\nabla }}({\bf{D}}\cdot {\bf{E}}({\bf{R}}))+\displaystyle \frac{d}{{dt}}({\bf{D}}\times {\bf{B}}),\end{array}\end{eqnarray} \tag{ 36 }$

where ${\boldsymbol{\nabla }}$ refers to differentiation with respect to the components of R. We have explicitly evaluated the first commutator $\tfrac{i}{{\hslash }}[{H}_{{new}},{\bf{P}}]={\boldsymbol{\nabla }}({\bf{D}}\cdot {\bf{E}})$ but left the second commutator as a time derivative. The last term is referred to as the Röntgen force, generalised here to include the quadrupole contribution. The so-called Röntgen effect arises when an electrically neutral system possessing a dipole moment is in motion in a magnetic field [19]. Here, we have shown that the corresponding interaction arises from a treatment incorporating the motion of the atomic centre of mass as a dynamical variable. Other effects that have been predicted to arise from the motion of neutral quantum systems include the rotational motion of a BEC with a form of distribution effectively associated with either a magnetic monopole distribution or an electric charge distribution [20]. We have therefore established that both dynamical attributes, namely the momentum and the corresponding pressure force, receive contributions directly attributable to the Röntgen interaction. The complete Hamiltonian in the truncated pole approximation is essential for studying processes involving the coupling of the atomic system to electromagnetic fields.

The multipolar theory of atom-field interactions, beginning with the seminal work by Power and Zienau [21] was subsequently developed and applied by several contributors. The reader is referred to the following sources for further information [22–29].

Before proceeding further, it is helpful to recognise two quite distinct forms of mechanical response that arise in describing the evolution of a given atom + radiation state. As fully discussed elsewhere [30, 31], gradient forces are generally produced in response to interactions in which the initial and final states are identical, resulting in mechanical motion through response to a potential energy surface sculpted by the structure of a light-beam. Here, forces arise essentially as a secondary result from a position-dependent shift in the electronic energy, ΔE, which in the quantum framework is identifiable with the real part of a corresponding quantum amplitude. With no exchange of energy taking place between the radiation and the atom, the response has to be mediated by an isotropic property—one that has the full three-dimensional symmetry of the atom. Most commonly this is polarizability, denoted here by $\tilde{\alpha }$, and when this engages with a radiation field with a locally variable strength there will be a resulting optical force given by;

$\begin{eqnarray}&&M\ddot{{\bf{R}}}=\displaystyle \frac{1}{2}\tilde{\alpha }{\boldsymbol{\nabla }}{{\rm{E}}}^{2}({\bf{R}}).\end{eqnarray} \tag{ 37 }$

This expression of this form is commonly used to determine an optical trapping force.

In contrast are non-conservative interactions, in which radiation directly produces mechanical effect through quantum transitions that impart linear or angular momentum. Since the atomic and the radiation states both change, these interactions engage transition moments that are intrinsically non-isotropic. A further significant difference is that since the initial and final states differ, any observable will have a direct relation to the process rate—the latter normally associated with the modulus square of a quantum amplitude. In either case, in connection with imparted linear momentum the changes in matter state are generally associated with translational motion amenable to representation by classical physics; with angular momentum, however, internal changes in electronic state are necessarily quantum events and must be dealt with accordingly.

A helical structure can be associated with two important and largely distinct aspects of light; most familiarly the sweep of the field vectors in circular polarization, and for twisted light the phase structure. Circular polarizations represent radiation states that are eigenfunctions of the operator for optical spin angular momentum (SAM), whose density operator is given by;

$\begin{eqnarray}&&\tilde{{\boldsymbol{S}}}({\bf{r}})={\epsilon }_{0}\{{{\bf{E}}}^{\perp }({\bf{r}})\times {{\bf{A}}}^{\perp }({\bf{r}})\}.\end{eqnarray} \tag{ 38 }$

As such, each circularly polarized photon conveys a well-defined quantum spin, precisely σℏ, where σ = ±1 according to left/right helicity [32]. Photons of twisted or vortex forms of structured light in principle represent quantum eigenstates of an OAM density operator, expressible as follows;

$\begin{eqnarray}&&{\bf{L}}({\bf{r}})={\epsilon }_{0}\{{E}_{i}^{\perp }({\bf{r}}\times {\boldsymbol{\nabla }}){A}_{i}\}.\end{eqnarray} \tag{ 39 }$

Both of the above results, equations (38) and (39), represent gauge-dependent quantities, cast in terms of the vector potential A(r). However, the separation of angular momentum into spin and orbital parts is a simplification that applies only in the paraxial approximation. More generally the separation is not absolute; there are transverse components and spin–orbit coupling in any significantly structured beam [33, 34] and there is indeed recent experimental proof of their interconversion in a cylindrically symmetric optical fibre [35]. For an objective perspective, it is therefore expedient to introduce more definitive, generalized measures of chirality for the radiation field. One suitable measure is the optical chirality density, defined as;

$\begin{eqnarray}&&\chi ({\bf{r}})=\displaystyle \frac{1}{2}{\epsilon }_{0}\{{{\bf{E}}}^{\perp }({\bf{r}})\cdot {\boldsymbol{\nabla }}\times {{\bf{E}}}^{\perp }({\bf{r}})+{c}^{2}{\bf{B}}({\bf{r}})\cdot {\boldsymbol{\nabla }}\times {\bf{B}}({\bf{r}})\},\end{eqnarray} \tag{ 40 }$

whose expectation value relative to the energy density in cognate units is bounded within the interval [−1, 1], the two limits signifying right- and left-handed circular polarizations [36]. We can also define a corresponding chirality flux;

$\begin{eqnarray}\begin{array}{rcl}{\boldsymbol{\varphi }}({\bf{r}}) & = & \displaystyle \frac{1}{2}{\epsilon }_{0}\{{{\bf{E}}}^{\perp }({\bf{r}})\times ({\boldsymbol{\nabla }}\times {\bf{B}}({\bf{r}}))\\ & & -{{\bf{B}}}^{\perp }({\bf{r}})\times ({\boldsymbol{\nabla }}\times {\bf{E}}({\bf{r}}))\},\end{array}\end{eqnarray} \tag{ 41 }$

to satisfy the continuity equation

$\begin{eqnarray}&&\displaystyle \frac{\partial \chi ({\bf{r}})}{\partial t}+{\boldsymbol{\nabla }}\cdot {\boldsymbol{\varphi }}({\bf{r}})=0.\end{eqnarray} \tag{ 42 }$

The volume integrals of both χ(r) and ${\boldsymbol{\varphi }}({\bf{r}})$ are also directly related to the scalar field helicity [37]

$\begin{eqnarray}&&{\boldsymbol{\kappa }}=\int \{{\bf{A}}({\bf{r}})\cdot {\bf{B}}({\bf{r}})\}{d}^{3}{\bf{r}}.\end{eqnarray} \tag{ 43 }$

For plane waves, χ(r) and ${\boldsymbol{\varphi }}({\bf{r}})$ effectively quantify a net SAM in terms of a difference in the number of left- and right-handed photons, for example [38]

$\begin{eqnarray}&&\int \chi ({\bf{r}}){d}^{3}{\bf{r}}={\hslash }c\displaystyle \sum _{{\bf{k}}}{k}^{2}\{{\hat{N}}^{(L)}({\bf{k}})-{\hat{N}}^{(R)}({\bf{k}})\}\end{eqnarray} \tag{ 44 }$

in which the right-hand side contains a difference between the corresponding photon number operators. When vortex modes are entertained, the key optomechanical parameter is represented by the OAM operator. In the paraxial approximation, for a mode with topological charge l this operator is expressible as;

$\begin{eqnarray}&&{\hslash }\displaystyle \sum _{{\rm{k}},l}l\hat{{\boldsymbol{k}}}\{{\hat{N}}^{(L)}({\bf{k}})+{\hat{N}}^{(R)}({\bf{k}})\},\end{eqnarray} \tag{ 45 }$

so that the spin and orbital parts of the total angular momentum effectively depend on the difference and sum, respectively, of the number operators for modes of opposite polarization helicity. From a different perspective this result is also consistent with the fact that fields whose mode expansions convey a phase factor $\exp ({il}\phi )$, are eigenfunctions of the angular momentum operator L [7]. The wide variety of other beams conveying OAM includes several other kinds of modified-Gaussian vortex beams [39], described as having a perfect optical vortex structure [40] and propagation-invariant Bessel beams [41]. For mode structures cast in a form that necessarily involves summation over an additional parameter (as is the case with perfect vortex beams, for example) the associated quanta are correspondingly associated with state superposition [40].

The term 'laser cooling' refers to various methods in which an interaction of laser light is made to systematically cool atomic, molecular and condensed matter systems to lower temperatures. For general reviews (see [42–46]). The primary processes involve the exchange of laser photons leading to momentum and hence velocity changes. Doppler cooling is the simplest of a number of techniques leading to the systematic reduction of the temperature of atomic or molecular ensembles while Raman anti-Stokes techniques are used for cooling condensed matter systems. Besides Doppler cooling, the list of laser cooling schemes includes, among others: Sisyphus cooling [47]; Raman sideband cooling [48]; velocity-selective coherent population trapping; [49, 50] and electromagnetically induced transparency cooling [51]. In addition to laser cooling, the laser light can be made to trap atoms in the minima of optical potential wells set up by the laser light.

The atoms to be cooled are normally in the form of a dilute atomic gas and the Doppler mechanism is employed for cooling down to a microkelvin limit; for ⁸⁵Rb the limit is commonly around 150 μK. The physical principles underlying Doppler cooling can be summarised succinctly as follows. When the frequency of the laser light is below a strong atomic transition frequency (a scenario referred to as red-detuning), then for an atom travelling in the direction of the laser source the light is blue-shifted in accordance with the Doppler effect. The atom absorbs a photon and so is slowed down on recoil. Consider now the effects of two counter-propagating laser beams of the same wavelength on a representative atom in a dilute atomic gas. Each atom absorbs more photons belonging to the laser beam opposite to its direction of motion in each event, thereby losing a linear momentum equal to the photon momentum. This atom is now in the excited state and so discharges its excitation by spontaneous emission in a random direction. The total effect of this basic cycle of photon absorption followed by emission is a reduction of the momentum of the atom, and so the atom loses speed. Repeated cycles then lead to a reduction of the centre of mass kinetic energy, which signifies cooling of the atom since (when compared with the case of molecules) they have no other centre of mass degrees of freedom.

Currently the most prominent use of laser cooling is in preparing samples of atomic ensembles with temperatures just above absolute zero, widely used for experiments that lead to a variety of effects, most notably Bose–Einstein condensation (BEC). Laser cooling has primarily been applied to atoms, but recently there has been progress leading to the cooling of more complex systems such as molecules [52, 53] and macro-scale objects [54, 55]. Depending on the size of the molecule, the problem of dissipating the energy from internal vibrational and rotational levels can present a considerable additional challenge [56].

When laser light is employed in the context of the laser cooling techniques mentioned above, it is commonly regarded as ordinary laser light in the sense that it is not endowed with OAM unless this feature is specifically introduced. The aim in the following is to highlight what has been achieved to date as regards the modifications to processes involving cooling and trapping of atoms when the laser light is twisted.

Soon after Doppler cooling appeared to be well-explained theoretically the experimental evidence showed that the existent theory was inadequate [57], as the measured kinetic temperatures achieved were significantly lower than those predicted by the Doppler mechanism. The failure of the Doppler mechanism to account solely for the lower temperatures achieved meant that a new theory was needed. This paved the way for the development of so-called sub-Doppler cooling mechanisms, most notably the mechanism based on the Sisyphus effect [58, 59]. As we discuss later, the Sisyphus effect is modified when the laser light is endowed with OAM, so it is helpful to first review the salient features of this effect.

There are two main differences between the Sisyphus cooling mechanism and Doppler cooling. In Sisyphus cooling, the main process involves the interaction of atoms with a light field characterised by spatial polarisation gradients. The specific polarisation gradients which have been utilised in the Sisyphus effect can be created by the superposition of two (for one-dimensional cooling) counter-propagating plane wave laser beams, with either mutually orthogonal linear polarisations [58], or with opposite circular polarisations [59]. The former is known in the literature as the lin ⊥ lin case, while the latter is represented as the σ₊–σ₋.

Consider now the first case where the two fields have mutually orthogonal polarisations. The electric field vectors of two identical, but counter-propagating laser beams, of frequency ω and axial wavevector $| {\bf{k}}| =k=2\pi \lambda$ travelling in opposite directions along the z-axis, are given by ${{\bf{E}}}_{\pm }(z)\,={\hat{{\boldsymbol{e}}}}_{\pm }{E}_{0}{e}^{\pm {ikz}}$ where ${\hat{{\boldsymbol{e}}}}_{\pm }$ are the corresponding polarisation vectors and E₀ is the amplitude or its quantum operator counterpart. We assume that the two beams have mutually orthogonal polarisations, ${\hat{{\boldsymbol{e}}}}_{+}={\hat{{\boldsymbol{e}}}}_{x}$ and ${\hat{{\boldsymbol{e}}}}_{-}={\hat{{\boldsymbol{e}}}}_{y}$. The total the total electric field is the vector sum:

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal E }}}^{+}(z)=\sqrt{2}{E}_{0}\left\{\cos ({kz})\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}+{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}+i\sin ({kz})\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}-{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}\right\}.\end{eqnarray} \tag{ 46 }$

As depicted in figure 1, the interference of two counter-propagating laser beams with mutually orthogonal linear polarisations results in a total polarisation of left- and right-handed circularity alternately σ⁺ and σ⁻ at planes separated by an axial distance of λ/4. Between planes the polarisation is linear with polarisation vector pointing at angles ±45°. This spatial variation of the wave polarisation along the common axis of the interfering beams constitutes a polarisation gradient, which—as will be explained—can lead to a spatially-dependent population differential.

Zoom In Zoom Out Reset image size

To explain how Sisyphus cooling works, we consider an atom that possesses a J_g = 1/2 ground state which has only two Zeeman sub-levels g_±1/2. Most laser cooling experiments use optical transitions ${J}_{g}\to {J}_{e}={J}_{g}+1$, the energy gap between the two states defined as ℏω₀. We, therefore, consider a ${J}_{g}\to {J}_{e}=3/2$ transition. As in Doppler cooling, we assume red-detuning Δ₀ < 0 where Δ₀ = (ω − ω₀) [43]. The polarisation gradients created by the interfering counter-propagating beams affect the light shifts and the populations of the atomic levels which now become spatially dependent. This can be explained as follows. When the atom interacts with a non-resonant light field, then in the weak-field limit the ground state levels acquire light shifts U_±. Similarly the populations of the Zeeman sub-levels (for an atom at rest) are now given by ${{\rm{\Pi }}}_{1/2}^{{st}}(z)={\sin }^{2}({kz})$ and ${{\rm{\Pi }}}_{-1/2}^{{st}}(z)={\cos }^{2}({kz})$, so that these light shifts are spatially dependent and different for the Zeeman sub-levels g_±1/2 as illustrated in figure 1. The optical potentials associated with the two Zeeman sub-level shifts are given by

$\begin{eqnarray}&&{U}_{\pm }=\displaystyle \frac{2}{3}{\hslash }{{\rm{\Delta }}}_{0}^{{\prime} }[2\mp \cos (2{kz})],\end{eqnarray} \tag{ 47 }$

where Ω₀ is the Rabi frequency. Also, Δ₀ and ${{\rm{\Delta }}}_{0}^{{\prime} }$ and the saturation parameter s₀ are given by

$\begin{eqnarray}&&{{\rm{\Delta }}}_{0}^{{\prime} }={s}_{0}{{\rm{\Delta }}}_{0}/2;\,\,\,\,{s}_{0}=\displaystyle \frac{{{\rm{\Omega }}}_{0}/2}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Gamma }}}^{2}/4}.\end{eqnarray} \tag{ 48 }$

Note that U_± are the optical potentials of the ground state sub-levels $| {g}_{\pm 1/2}\rangle$. It is easy to see that the minima of U₊ correspond to the maxima of U₋ and vice versa and the maxima and minima correspond to positions where the polarisation is ${\hat{\sigma }}_{\pm }$ (purely circular).

Early theoretical works which sought to explain the Doppler cooling argued that the damping of the atomic gross motion arises from the fact that the atomic internal state does not follow adiabatically the variations of the laser field resulting from atomic motion [60]. Such an effect may be described by a non-adiabaticity parameter  = vτ_P/λ = v/(λΓ), defined as the ratio between the distance vτ_P covered by the atom with a velocity v during its internal relaxation time τ_P (τ_P = Γ⁻¹), and the laser wavelength. For multi-level atoms, we can similarly define a non-adiabaticity parameter $\epsilon ^{\prime} =v{\tau }_{P}^{\prime} /\lambda =v/(\lambda {\rm{\Gamma }}^{\prime} )$. At low intensities, since ${\rm{\Gamma }}^{\prime} \ll {\rm{\Gamma }}$ it follows that $\epsilon ^{\prime} \gg \epsilon$. Thus non-adiabatic effects can appear at much lower velocities (${kv}\approx {\rm{\Gamma }}^{\prime}$) than those required by Doppler cooling, and thus can ensure the presence of damping forces even at very low velocities.

Dalibard and Cohen-Tannoudji [58] explained how the damping of the atomic motion is generated. The key point is that, as a condition, the atom must have internal states with energy sub-levels with a strong position-dependence, and which therefore experience large changes as the atom moves. The creation of polarisation gradients can ensure this condition. Let us assume that the atom moves along the z-axis, and it has a speed such that during the optical pumping time ${\tau }_{P}={\rm{\Gamma }}{{\prime} }^{-1}$ it travels a distance of the order of the laser wavelength λ. If the atom starts from the bottom of a valley in a given Zeeman sub-level, then it has sufficient time to reach the top of the hill. At this position, it has a large probability to be optically pumped to the other sub-level and be shifted to the bottom of a valley, and so on: see figure 2. The atom is running uphill more frequently than downhill. This is called a low intensity Sisyphus effect, which arises from the correlations between the spatial modulations of light shifts and optical pumping rates. It is important to emphasise the term 'low intensity' as the Sisyphus effect we are discussing is valid in the low intensity regime. This is in contrast to another Sisyphus effect which is valid at high intensities, which we shall not discuss any further here [61].

Zoom In Zoom Out Reset image size

In the process of Sisyphus cooling, an atomic sample eventually reaches an equilibrium temperature. In each optical pumping cycle, we have the emission of a fluorescence photon. Each such photon has an energy higher than the energy of the absorbed photon, by an amount in the order of the light shift $| {U}_{\pm }|$. The excess energy is transferred from the atom to the light field leading to a decrease of the atomic energy by the same amount. Repeated pumping cycles, thus, lead to a stepwise decrease of the atomic energy until its total energy is so low that the atom becomes trapped in the optical potential wells associated with the spatially modulated light shifts. The equilibrium temperature of sub-Doppler cooling is therefore expected to be given by:

$\begin{eqnarray}&&{k}_{B}{T}_{{Sis}}\approx {U}_{\pm }=\displaystyle \frac{{\hslash }{{\rm{\Omega }}}^{2}| {{\rm{\Delta }}}_{0}| }{4{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Gamma }}}^{2}},\end{eqnarray} \tag{ 49 }$

which for large detuning Δ₀ ≫ Γ takes the form,

$\begin{eqnarray}&&{k}_{B}{T}_{{Sis}}\approx {U}_{\pm }=\displaystyle \frac{{\hslash }{{\rm{\Omega }}}^{2}}{4| {{\rm{\Delta }}}_{0}| }.\end{eqnarray} \tag{ 50 }$

The detailed quantitative treatment of these predictions has been given in [58]. At low intensity, the magnitude of the light shift $| {U}_{\pm }|$ of the ground state is much smaller than the natural width ℏΓ of the excited state. This explains why it is possible to attain temperatures about two orders of magnitude lower than the Doppler limit, which itself scales as ℏΓ. The Sisyphus cooling leads to a damping force which for large detuning is in the form,

$\begin{eqnarray}&&{F}_{{Sis}}=-{\alpha }_{F}v,\,\,\,\,\,\,{\alpha }_{F}={\hslash }{k}^{2}\displaystyle \frac{{{\rm{\Delta }}}_{0}}{{\rm{\Gamma }}}.\end{eqnarray} \tag{ 51 }$

The friction coefficient α_F which applies in the case of low intensity Sisyphus cooling, as given in equation (51), is much larger than the friction coefficient of Doppler cooling: the latter is of the order of ${\hslash }{k}^{2}{s}_{0}$, where the saturation parameter s₀ must be smaller than one. In typical experiments, both cooling mechanisms come into play. Although the friction force of the low intensity Sisyphus cooling acts within a much smaller velocity interval than the Doppler cooling, both mechanisms are useful. The Doppler cooling that acts over a relatively large velocity interval drags the atoms towards the velocity region where the Sisyphus cooling operates. Thus, use of the Doppler mechanism as a first step serves to increase dramatically the number of atoms affected by the sub-Doppler mechanism.

We have seen that the equilibrium temperature is proportional to the square of the Rabi frequency, which means that it is directly proportional to the laser intensity. This may incorrectly imply that lowering the intensity can lower the temperature indefinitely. But we must take into account the fact that the scheme is based on spontaneously emitted photons in each pumping cycle. Each photon imparts a recoil momentum ℏk to the atom which, according to its direction relative to the atomic motion, may either decrease or increase the atomic kinetic energy. The atomic motion continues to be cooled only so far as the decrease of the total atomic energy due to the Sisyphus effect, remains larger than the increase of the kinetic energy, of the order of E_rec, due to recoil associated with the spontaneously emitted photon.

The qualitative description of low intensity Sisyphus cooling, as given above, is based on a classical description of the position of the atomic centre of mass. This means that the moving atom is treated as a classical point particle. This is a reasonable assumption only if the atomic wave packet, which describes quantum mechanically the centre of mass, is well localised in the laser wave. This assumption breaks down when the minimum temperature is achieved and this leads to the conclusion that we must then treat both internal and external variables quantum mechanically. In this case, we can take advantage of the fact that in the Sisyphus effect the motion of the atom occurs in spatially periodic potential wells. This is reminiscent of the electron motion in solid state lattices. Thus, the description of atomic motion could also be given in terms of Bloch states and energy bands [62–64]. In this regime, low intensity Sisyphus cooling is a result of optical pumping processes that accumulates the atoms into the lowest energy bands.

The above arguments may suggest that the photon recoil energy E_rec should be the ultimate cooling limit. However, to cool the atomic motion to kinetic energies below the photon recoil energy, atoms with velocity v smaller than the recoil velocity v_rec must be prevented from absorbing light [49, 50]. This condition can be satisfied by the creation of atomic dark states for which the fluorescence rate depends on the atomic velocity at the excitation, by a Raman process. When the velocity is zero, or close to zero, the atom does not absorb photons; it thus does not fluoresce, and so it does not experience recoil. We can also use selective Raman processes in which the excitation of the atoms is velocity-selective [65]. However, these mechanisms have basic physical differences from Doppler and Sisyphus cooling. First, the cooling with velocity-dependent dark states is not based on a force. It is rather the result of an inhomogeneous random walk in momentum space which vanishes as the atomic velocity tends to zero. Secondly, in Doppler and Sisyphus cooling the system reaches a steady state as a result of the competition between the cooling introduced by the friction, and the heating due to fluctuations associated with the random spontaneous emission processes. Such a competition does not exist in sub-recoil cooling.

As a corollary, it is interesting to note why the mechanism in question is called the Sisyphus effect. The name comes from Sisyphus, a hero of ancient Greek mythology who was punished by Zeus by being forced to transport a heavy rock to the top of a hill. Just before reaching the top, the rock slipped away and rolled downhill to the bottom. The Sisyphus effect is an allusion to his condemnation to repeat this eternally just as the atom loses kinetic energy through transitions involving the potential hills of its space modulated energy levels.

It is a general feature of twisted light, exemplified by the LG beams, that different modes have helical wavefronts consisting of intertwined helices, as shown schematically in figure 3. Modes of the LG type, denoted LG_klp, have a wavevector component k along the propagation direction and are characterised by the two integer indices: an azimuthal integer index l, representing the number of intertwined helices and a radial integer index p which arbitrates the number of radial nodes. These directly equate to the degree and order of the associated (generalised) Laguerre polynomial that modifies the Gaussian radial profile. The integer l can be positive or negative, representing two senses of helical wavefront rotation. When both l and p are zero, the mode (k, 0, 0) becomes simply a Gaussian distribution with no angular momentum.

Zoom In Zoom Out Reset image size

In the paraxial approximation, the electric field associated with a LG mode, of wavelength λ = 2π/k and frequency ω propagating in the z-direction, and polarised in the x-direction is given by

$\begin{eqnarray}&&{{\bf{E}}}_{{klp}}(\rho ,\phi ,z,t)=\displaystyle \frac{1}{2}{u}_{p}^{| l| }(\rho ,z){e}^{i{{\rm{\Theta }}}_{{klp}}(\rho ,\phi ,z)}{e}^{-i\omega t}\widehat{{\bf{x}}},\end{eqnarray} \tag{ 52 }$

where ${u}_{p}^{| l| }(\rho ,z)$ is the amplitude or mode distribution function

$\begin{eqnarray}\begin{array}{rcl}{u}_{p}^{| l| }(\rho ,z) & = & {E}_{k00}\displaystyle \frac{{C}_{| l| p}}{{(1+{z}^{2}/{z}_{{R}^{2}})}^{1/2}}{\left(\displaystyle \frac{\sqrt{2}\rho }{w(z)}\right)}^{| l| }\\ & & \times {L}_{p}^{| l| }\left(\displaystyle \frac{2{\rho }^{2}}{{w}^{2}(z)}\right)\times {e}^{-{\rho }^{2}/{w}^{2}(z)}\end{array}\end{eqnarray} \tag{ 53 }$

and Θ_klp is the phase function

$\begin{eqnarray}&&\begin{array}{l}{{\rm{\Theta }}}_{{klp}}(\rho ,\phi ,z)\,=\,{skz}+l\phi -s(2p+| l| +1){\tan }^{-1}(z/{z}_{R})\\ \,+\,s\displaystyle \frac{k{\rho }^{2}z}{2({z}^{2}+{z}_{R}^{2})}.\end{array}\end{eqnarray} \tag{ 54 }$

Here ${L}_{p}^{| l| }$ is the associated Laguerre polynomial, w(z) is the beam waist at position z defined by ${w}^{2}(z)=2({z}^{2}+{z}_{R}^{2})/{{kz}}_{R}$, and z_R is the Rayleigh range, which is related to w₀, the waist at focus, by ${z}_{R}=\pi {w}_{0}^{2}/\lambda$ where λ the wavelength of the light. In equation (54), the third term is the Gouy phase for the LG mode and the fourth term is referred to as the curvature phase term. The factor s = ±1 takes into account propagation in the opposite directions along the ±z-axes, while the factor ${C}_{| l| p}$ is given by ${C}_{| l| p}=\sqrt{2p!/\pi (| l| !+p!)}$.

An important feature of all twisted light fields is the existence of the phase factor e^ilϕ. However, the full phase Θ_klp(ρ, ϕ, z) is essential for describing the various effects including rotational effects when the light interacts with atoms and molecules. Figure 3 shows by way of an example the characteristic features of optical vortex beams concerning phase variations and helical wavefronts.

A LG beam characterised by the electric field E_klp(ρ, ϕ, z) has a linear momentum ℏk and carries an angular momentum equal to lℏ per photon. The quantum number l is called the winding number (or the topological charge) and we re-emphasise that l can take both negative and positive integer values, corresponding to right-hand and left-hand twisting of the wavefront. LG modes for which $l\ne 0$ but p = 0 are called donut modes, since the light intensity is ring-shaped as shown figure 4 for the cases l = 1 and l = 3. Figure 4 also shows the case of a double ring mode arising when l = 1, p = 1.

Zoom In Zoom Out Reset image size

Zoom In Zoom Out Reset image size

It is often sufficient to focus on the form of twisted light without explicit details of the LG form. An electromagnetic light mode of frequency ω and OAM lℏ possesses an electric field vector distribution which can be written in cylindrical polar coordinates ${\bf{r}}=({\boldsymbol{\rho }},z)$ as follows

$\begin{eqnarray}&&{{\bf{E}}}_{{kl}}({\bf{r}},t)=\displaystyle \frac{1}{2}\hat{{\boldsymbol{\epsilon }}}F(\rho ){e}^{i({kz}-\omega t)}{e}^{{il}\phi },\end{eqnarray} \tag{ 55 }$

where $\hat{{\boldsymbol{\epsilon }}}$ is a wave polarisation vector and F(ρ) is a scalar distribution function which depends only on the radial coordinate ρ. Note that, unless a paraxial approximation is deployed, the polarisation vector need not necessarily reside in the plane represented by ${\boldsymbol{\rho }}$. The field in equation (55) emerges from the familiar LG light distribution in the limit of large Rayleigh range ${z}_{R}\to \infty$, a situation which is often encountered and is realisable in practice. This simplified form of field is advantageous for a number of reasons. It has the desired feature in being endowed with OAM, by virtue of the azimuthal phase factor, and is free from the curvature problems which often distract from the fundamental issues involving OAM of light in a real LG beam, i.e. with a finite Rayleigh range.

Besides the LG beam, a second, somewhat simpler, type of vortex beam is the Bessel beam [84]. This is characterised by a transverse electric field which is also a solution to the electromagnetic vector Helmholtz equation, with the modes characterised by only one integer number l, that can take either positive or negative values. We have in cylindrical polar coordinates r = (ρ, ϕ, z)

$\begin{eqnarray}&&{\bf{E}}({\bf{r}},t)=\hat{{\boldsymbol{\varepsilon }}}{E}_{0l}{J}_{l}({k}_{\perp }\rho ){e}^{{ikz}}{e}^{{il}\phi }{e}^{-i\omega t},\end{eqnarray} \tag{ 56 }$

where E_0l is the amplitude and the unit vector $\hat{{\boldsymbol{\varepsilon }}}$ designates a wave polarisation. The radial function J_l(k_⊥ρ) is the Bessel function of order l where, as in LG beams, l is the winding number and the vortex beam carries lℏ OAM per photon. The wavevectors k_⊥ and k stand for in-plane and axial wavevector variables. Figure 5 displays the field intensity distributions of two different Bessel beams characterised by different values of the winding number.

The superposition of multiple beams endowed with OAM can give rise to various field distributions and associated properties which become more complex when wave polarisation is included. The simplest cases are those in which two beams are involved and arranged to be co-axial identical or otherwise and may have different magnitudes and signs of winding numbers. They can be co-propagating or counter-propagating and may have the same polarisation. The influence of such states of twisted light on the near resonant optical forces and torques leading to the trapping and dynamics of the atoms immersed in them is discussed in section 7. It has been shown [85] how further complexity arises when the twisted light beams have circular wave polarisations (optical spins), giving rise to spatio-temporal polarisation gradients. We discuss below the simplest cases involving only two beams, as done in [85].

Consider the case of two co-propagating LG beams, labelled 1 and 2 of the same frequency ω and axial wave vector k, with coinciding centres. The beams have the same magnitude of winding number l, but differ only in the sign of l. The total electric field vector distribution is then given by

$\begin{eqnarray}&&{\bf{E}}(\rho ,\phi ,z,t)=\{{{ \mathcal F }}^{+}(\rho ,\phi ,z){e}^{-i\omega t}+{\rm{c}}.{\rm{c}}.\}{e}^{{ikz}},\end{eqnarray} \tag{ 57 }$

where c.c. denotes complex conjugation and ${{ \mathcal F }}^{+}(\rho ,\phi ,z)$ arises from the sum of the two electric fields. We have

$\begin{eqnarray}&&{{ \mathcal F }}^{+}(\rho ,\phi ,z)={f}_{1}(\rho ,z){e}^{{il}\phi }{\hat{{\boldsymbol{e}}}}_{1}+{f}_{2}(\rho ,z){e}^{-{il}\phi }{\hat{{\boldsymbol{e}}}}_{2},\end{eqnarray} \tag{ 58 }$

where f_1,2 describe any LG light beam expressible through equations (52)–(54) with appropriate choice of quantum numbers and parameters. However, for the applications we consider here, the beams differ in the sign of l such that l₁ = l and l₂ = −l. The vectors $\hat{{{\boldsymbol{e}}}_{1}}$ and $\hat{{{\boldsymbol{e}}}_{2}}$ specify the wave polarisations of the beams, which in general involve any combination of linear polarisations, but more specifically we consider circular polarisation.

5.2.1. Co-propagating with σ⁺ − σ⁻

When the two co-propagating beams have opposite l, as well as opposite circular polarisations, we write

$\begin{eqnarray}&&{\hat{{\boldsymbol{e}}}}_{1}={{\boldsymbol{\sigma }}}^{+}=-\displaystyle \frac{1}{\sqrt{2}}({\hat{{\boldsymbol{e}}}}_{x}+i{\hat{{\boldsymbol{e}}}}_{y}),\end{eqnarray} \tag{ 59 }$

$\begin{eqnarray}&&\hat{{{\boldsymbol{e}}}_{2}}={{\boldsymbol{\sigma }}}^{-}=\displaystyle \frac{1}{\sqrt{2}}({\hat{{\boldsymbol{e}}}}_{x}-i{\hat{{\boldsymbol{e}}}}_{y}),\end{eqnarray} \tag{ 60 }$

where ${\hat{{\boldsymbol{e}}}}_{x}$ and ${\hat{{\boldsymbol{e}}}}_{y}$ are the usual linear wave polarisation vectors along the x and y axes. Substituting for $\hat{{\boldsymbol{e}}}{}_{\mathrm{1,2}}$ in equation (58), we have

$\begin{eqnarray}\begin{array}{rcl}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z) & = & \displaystyle \frac{1}{\sqrt{2}}\{[{f}_{2}(\rho ,z)-{f}_{1}(\rho ,z)]{\hat{{\boldsymbol{\Sigma }}}}_{-}(\phi )\\ & & -i[{f}_{2}(\rho ,z)+{f}_{1}(\rho ,z)]{\hat{{\boldsymbol{\Sigma }}}}_{+}(\phi )\},\end{array}\end{eqnarray} \tag{ 61 }$

where ${\hat{{\boldsymbol{\Sigma }}}}_{\pm }(\phi )$ are polarisation vectors that depend on only the azimuthal angular position.

$\begin{eqnarray}&&{\hat{{\boldsymbol{\Sigma }}}}_{-}(\phi )={\hat{{\boldsymbol{e}}}}_{x}\cos (l\phi )-{\hat{{\boldsymbol{e}}}}_{y}\sin (l\phi ),\end{eqnarray} \tag{ 62 }$

$\begin{eqnarray}&&{\hat{{\boldsymbol{\Sigma }}}}_{+}(\phi )={\hat{{\boldsymbol{e}}}}_{x}\sin (l\phi )+{\hat{{\boldsymbol{e}}}}_{y}\cos (l\phi ).\end{eqnarray} \tag{ 63 }$

Thus, the polarisation of the interference fields is, in general, locally elliptical with an ellipticity given by

$\begin{eqnarray*}&&\displaystyle \frac{({f}_{2}(\rho ,z)-{f}_{1}(\rho ,z))}{({f}_{2}(\rho ,z)+{f}_{1}(\rho ,z))}.\end{eqnarray*}$

To illustrate the polarisation distribution in the resultant field of the above scenario involving co-propagating LG beams, we make use of the fact that the two beams are identical, except for the sign of l. This means that f₁ = f₂ = f. We then have from equation (61)

$\begin{eqnarray}\begin{array}{rcl}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z) & = & -i\sqrt{2}f(\rho ,z){\hat{{\boldsymbol{\Sigma }}}}_{+}(\phi )\\ & = & -i\sqrt{2}f(\rho ,z)\{{\hat{{\boldsymbol{e}}}}_{x}\sin (l\phi )+{\hat{{\boldsymbol{e}}}}_{y}\cos (l\phi )\}.\end{array}\end{eqnarray} \tag{ 64 }$

The polarisation is linear throughout, but its direction is independent of the axial position and depends only on the in-plane positions $(\rho ,\phi )$. Figure 6 displays the polarisation distributions for two cases, l = ±1 and l = ±2. The dashed red circles coincide with the radial positions of maximum intensity.

Zoom In Zoom Out Reset image size

5.2.2. Co-propagating with lin ⊥ lin polarisations

When the co-propagating beams have opposite winding numbers, but with wave polarizations that are linear and orthogonal, we have

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)={f}_{1}(\rho ,z){e}^{{il}\phi }\hat{{{\boldsymbol{e}}}_{1}}+{f}_{2}(\rho ,z){e}^{-{il}\phi }\hat{{{\boldsymbol{e}}}_{2}},\end{eqnarray} \tag{ 65 }$

where now ${\hat{{\boldsymbol{e}}}}_{1}={\hat{{\boldsymbol{e}}}}_{x}$ and ${\hat{{\boldsymbol{e}}}}_{2}={\hat{{\boldsymbol{e}}}}_{y}$. Substituting in equation (65), we get:

$\begin{eqnarray}&&\begin{array}{l}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)\\ \quad =\sqrt{2}f(\rho ,z)\left\{\cos (l\phi )\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}+{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}+i\sin (l\phi )\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}-{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}\right\}.\end{array}\end{eqnarray} \tag{ 66 }$

Clearly the polarization direction distribution does not depend on the axial position, but its form varies with angular position and is in general elliptical, displaying both linear and circular forms, as the azimuthal angle varies. This is illustrated in table 1. For a donut mode where p = 0 and a general value of l > 0, the region of maximum intensity occurs at a radial position, ${\rho }_{0}={w}_{0}\sqrt{l/2}$, the polarisation changes from linear to circular along the arc of length ${\rm{\Delta }}s=\pi {w}_{0}/4\sqrt{2l}$. Thus, the spatial extent of the polarisation depends on the beam waist and the magnitude of the OAM.

Table 1.  Variation with azimuthal angle ϕ of the type of polarization for two co-propagating donut modes at fixed radial position ${\rho }_{0}={w}_{0}\sqrt{(}l/2)$. It is seen that as ϕ changes from 0 to π/l, the type of polarization switches between linear and circular.

ϕ	Polarization
0	Linear
π/4l	Circular σ−
π/2l	Linear
3π/4l	Circular σ+
π/l	Linear

Now consider counter-propagating beams with opposite signs of winding numbers. The electric field distribution associated with an LG beam travelling along the negative z-axis can be found from the standard form by a simple transformation. This involves rotating the LG beam as a rigid body about the Cartesian y-axis by an angle π, which amounts to the substitution $x\to -x;\,y\to y\,$ and $z\to -z$. In terms of cylindrical polar coordinates, we have $\rho \to \rho ;\,\phi \to -\phi$ and $z\to -z$. It is easy to see that this transformation affects only the phase factors but leaves the function f(ρ, z) unchanged. The polarisation of the light field in this case depends also on the axial position z.

5.3.1. Counter-propagating with ${\sigma }^{+}\mbox{--}{\sigma }^{-}$

Here, two counter-propagating beams have opposite circular polarisations, but the same winding number. The total electric field vector is now given by the analogue of equation (57)

$\begin{eqnarray}&&{\bf{E}}(\rho ,\phi ,z,t)=\{{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z){e}^{-i\omega t}+{\rm{c}}.{\rm{c}}.\},\end{eqnarray} \tag{ 67 }$

where now we have

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)={f}_{1}(\rho ,z){e}^{i({kz}+l\phi )}\hat{{{\boldsymbol{e}}}_{1}}+{f}_{2}(\rho ,z){e}^{-i({kz}+l\phi )}\hat{{{\boldsymbol{e}}}_{2}},\end{eqnarray} \tag{ 68 }$

where $\hat{{{\boldsymbol{e}}}_{1}}$ and $\hat{{{\boldsymbol{e}}}_{2}}$ are given by equations (59) and (60), respectively. On substituting for these vectors in equation (68), we find

$\begin{eqnarray}\begin{array}{rcl}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z) & = & \displaystyle \frac{1}{\sqrt{2}}\{[{f}_{2}(\rho ,z)-{f}_{1}(\rho ,z)]{\tilde{{\boldsymbol{\Sigma }}}}_{-}(\phi )\\ & & -i[{f}_{2}(\rho ,z)+{f}_{1}(\rho ,z)]{\tilde{{\boldsymbol{\Sigma }}}}_{+}(\phi )\},\end{array}\end{eqnarray} \tag{ 69 }$

where ${\tilde{{\boldsymbol{\Sigma }}}}_{\pm }(\phi ,z)$ are polarisation vectors that now depend on both the azimuthal angular position ϕ and the axial position z.

$\begin{eqnarray}&&{\tilde{{\boldsymbol{\Sigma }}}}_{-}(\phi ,z)={\hat{{\boldsymbol{e}}}}_{x}\cos ({kz}+l\phi )-{\hat{{\boldsymbol{e}}}}_{y}\sin ({kz}+l\phi ),\end{eqnarray} \tag{ 70 }$

$\begin{eqnarray}&&{\tilde{{\boldsymbol{\Sigma }}}}_{+}(\phi ,z)={\hat{{\boldsymbol{e}}}}_{x}\sin ({kz}+l\phi )+{\hat{{\boldsymbol{e}}}}_{y}\cos ({kz}+l\phi ).\end{eqnarray} \tag{ 71 }$

Once again we shall consider the case where the beams are similar, in which case, we have

$\begin{eqnarray}&&\begin{array}{l}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)=-i\sqrt{2}f(\rho ,z){\tilde{{\boldsymbol{\Sigma }}}}_{+}(\phi ,z)\\ \quad =\,-i\sqrt{2}f(\rho ,z)\{{\hat{{\boldsymbol{e}}}}_{x}\sin ({kz}+l\phi )+{\hat{{\boldsymbol{e}}}}_{y}\cos ({kz}+l\phi )\}.\end{array}\end{eqnarray} \tag{ 72 }$

In this case, the polarisation distribution is z-dependent as well as angular dependent. The polarisation is linear and is constant in direction along spirals which result from the equation ${kz}+l\phi ={constant}$. For example, the polarisation vector is ${\hat{{\boldsymbol{e}}}}_{y}$ along the spiral kz + lϕ = 0 and ${\hat{{\boldsymbol{e}}}}_{x}$ along the spiral kz + lϕ = π/2, as shown in figure 7.

Zoom In Zoom Out Reset image size

Figure 8 displays the polarisation distributions on the planes z = 0; λ/4; λ/2; 3λ/4 and λ in the case where l = 1. It is easy to see that the polarisation gradient distribution on the plane z = 0 for the counter-propagating fields is identical to that for the co-propagating LG beams for any z value.

Zoom In Zoom Out Reset image size

5.3.2. Counter-propagation with lin $\perp$ lin polarisations

The second case is the one where the two beams have mutually orthogonal polarisations. The total electric field vector is now given by the analogue of equation (57)

$\begin{eqnarray}&&{\bf{E}}(\rho ,\phi ,z,t)=\{{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z){e}^{-i\omega t}+{\rm{c}}.{\rm{c}}.\},\end{eqnarray} \tag{ 73 }$

where now we have

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)={f}_{1}(\rho ,z){e}^{i({kz}+l\phi )}\hat{{{\boldsymbol{e}}}_{x}}+{f}_{2}(\rho ,z){e}^{-i({kz}+l\phi )}\hat{{{\boldsymbol{e}}}_{y}}.\end{eqnarray} \tag{ 74 }$

On substituting for these vectors in equation (74), we find

$\begin{eqnarray}&&\begin{array}{l}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z)\\ \quad =\,\sqrt{2}f(\rho ,z)\left\{\cos (l\phi +{kz})\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}+{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}\right.\\ \,\left.+\,i\sin (l\phi +{kz})\displaystyle \frac{{\hat{{\boldsymbol{e}}}}_{x}-{\hat{{\boldsymbol{e}}}}_{y}}{\sqrt{2}}\right\}.\end{array}\end{eqnarray} \tag{ 75 }$

Now the polarisation is also in general elliptical, displaying both linear and circular forms, as the function kz + lϕ varies. This is illustrated in table 2.

Table 2.  Variation with axial and azimuthal position (z, ϕ) of the type of polarisation for two counter-propagating donut modes at fixed radial position $r={w}_{0}\sqrt{| l| /2}$. As (kz + lϕ) changes from 0 to π, the type of polarisation switches between linear and circular.

kz + lϕ	Polarisation
0	Linear
π/4	Circular$\,\,\hat{{{\boldsymbol{\sigma }}}_{-}}$
π/2	Linear
3π/4	Circular$\,\,{\hat{{\boldsymbol{\sigma }}}}_{+}$
π	Linear

As shown in table 2, the polarisation acquires certain forms along the spiral lines defined by kz + lϕ = constant. Figure 9 displays two sets of helices in separate plots, one set representing two helices of constant linear polarisation and the other set represents two of opposite circular polarisations. The helices correspond to points of maximum intensity.

Zoom In Zoom Out Reset image size

Finally, consider the case where the intensity pattern of the light fields rotates in time. This is achieved when the interfering beams have a slight difference in their frequencies. The selection of different values of beam winding numbers and polarizations gives rise to temporal polarization gradients. Here, we present two such schemes.

5.4.1. Circular polarisation ${\sigma }^{+}\,-{\sigma }^{-}$

Consider first two co-propagating LG beams, of opposite l but slightly different frequencies. Assume that beam 1 has frequency ω₁ and a positive circular polarisation ${{\boldsymbol{\sigma }}}^{+}$ and beam 2 has frequency ω₂ and a negative circular polarisation ${{\boldsymbol{\sigma }}}^{-}$. The electric field vector for the two co-propagating circularly polarised LG beams with different frequencies is given by the analogues of equations (57) and (58). We have

$\begin{eqnarray}&&{\bf{E}}(\rho ,\phi ,z,t)=\{{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t)+{\rm{c}}.{\rm{c}}.\}{e}^{{ikz}},\end{eqnarray} \tag{ 76 }$

where

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t)={f}_{1}(\rho ,z){e}^{i(l\phi -{\omega }_{1}t)}\hat{{{\boldsymbol{e}}}_{1}}+{f}_{2}(\rho ,z){e}^{-({il}\phi +{\omega }_{2}t)}\hat{{{\boldsymbol{e}}}_{2}}.\end{eqnarray} \tag{ 77 }$

On following analogous steps to those in section 5.2.2, we have the analogue of equation (64)

$\begin{eqnarray}&&\begin{array}{l}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t)=-i\sqrt{2}f(\rho ,z){e}^{-i\tfrac{({\omega }_{1}+{\omega }_{2})t}{2}}\\ \ \ \times \,\left\{{\hat{{\boldsymbol{e}}}}_{x}\sin \left[\displaystyle \frac{(2l\phi +{\rm{\Delta }}t)}{2}\right]+{\hat{{\boldsymbol{e}}}}_{y}\cos \left[\displaystyle \frac{(2l\phi +{\rm{\Delta }}t)}{2}\right]\right\},\end{array}\end{eqnarray} \tag{ 78 }$

where Δ is the frequency difference Δ = ω₂ − ω₁. We now see the polarisation varying in both space and time. At a given axial plane, the polarisation pattern rotates at a rate which depends on the frequency difference Δ and the magnitude of the winding number l. Figure 10 displays a graphical illustration of the rotation of the polarisation vector in two different cases. The first is the case in which the beam 1 of frequency ω₁ has l = 1 while beam 2 of frequency ω₂ has l = −1, shown for different times t = 0 (left) and t = π/Δ (right). The second is the case in which beam 1 of frequency ω₁ has l = −1 and beam 2 of frequency ω₂ has l = 1 again shown for two different times t = 0 (left) and t = π/Δ (right). It is interesting to see that in the second case the polarisation changes from fully azimuthal to radial. Finally, we note that in the limit where the beams have the same frequency, i.e. when Δ ≡ ω₂ − ω₁ = 0, equation (78) reduces to equation (64), as it should.

Zoom In Zoom Out Reset image size

5.4.2. The lin $\perp$ lin case

Finally, we deal with the case where the two co-propagating LG beams, of opposite l but slightly different frequency have mutually orthogonal linear polarisations. Assume that beam 1 has frequency ${\omega }_{1}$ and polarisation ${\hat{{\boldsymbol{e}}}}_{x}$ and beam 2 has frequency ω₂ and a polarisation ${\hat{{\boldsymbol{e}}}}_{y}$. In this case, we have

$\begin{eqnarray}&&{\bf{E}}(\rho ,\phi ,z,t)=\{{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t)+{\rm{c}}.{\rm{c}}.\}{e}^{{ikz}},\end{eqnarray} \tag{ 79 }$

where

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t)={f}_{1}(\rho ,z){e}^{i(l\phi -{\omega }_{1}t)}\hat{{{\boldsymbol{e}}}_{x}}+{f}_{2}(\rho ,z){e}^{-({il}\phi +{\omega }_{2}t)}\hat{{{\boldsymbol{e}}}_{y}}.\end{eqnarray} \tag{ 80 }$

Since f₁(ρ, z) = f₂(ρ, z) = f(ρ, z), we find

$\begin{eqnarray}\begin{array}{rcl}{{\boldsymbol{ \mathcal F }}}^{+}(\rho ,\phi ,z,t) & = & f(\rho ,z){e}^{-i\tfrac{({\omega }_{1}+{\omega }_{2})t}{2}}\\ & & \times \{{{\rm{e}}}^{i(l\phi -{\rm{\Delta }}t/2)}{\hat{{\boldsymbol{e}}}}_{x}+{{\rm{e}}}^{i(-l\phi +{\rm{\Delta }}t/2)}{\hat{{\boldsymbol{e}}}}_{y}\}.\end{array}\end{eqnarray} \tag{ 81 }$

Figure 11 displays the evolution of the polarisation vector, at z = 0, for the light field arising from the interference of two LG beams with mutually orthogonal polarisations, opposite winding numbers and slightly different frequencies. Two different cases involving two different time instants are shown. Note in particular how the polarisation changes from linear to circular and vice versa at different azimuthal angles.

Zoom In Zoom Out Reset image size

In summary of this section, we have investigated the spatial and temporal polarisation of light fields created by the interference of either co-propagating, or counter-propagating LG beams when they have opposite winding number l and for the cases where they possess opposite circular polarisations, ${\sigma }_{+}$ and σ₋ and mutually orthogonal linear polarisations.

When the LG beams are co-propagating and possess opposite circular polarisations we have found that for a fixed value of $| l|$, the polarisation is independent of the axial position z, so that within a normal beam cross-section, it is everywhere locally linear but the direction changes, depending on its polar position $(\rho ,\phi )$. When the beams have mutually orthogonal polarisations the total polarisation again does not depend on the radial position, but now it can change from linear to σ₋ and then back to linear and σ₊ as the azimuthal angle changes from 0 to 2π.

When the LG beams are counter-propagating, the polarisation distribution depends on the axial position as well as the in-plane polar position (ρ, ϕ). Note the interesting symmetry in which the the distribution for z = λ/4 is the mirror reflection of that at z = 3λ/4. Similarly, the polarisation distribution for z = λ/2 is the mirror reflection of that for z = 0. The distributions at z = 0 and z = λ are identical.

A case in which the polarisation shows both temporal and spatial variations is that of interfering beams with slightly different frequency and opposite signs of winding number. We may again consider two different cases when the beams have opposite circular polarisations and mutually orthogonal polarisations. This difference in frequency has been shown to give rise to a rotation of the polarisation pattern. The temporal evolution is very similar to the sequence exhibited by the spatial dependence and so similar patterns will emerge, except that position-dependence is now replaced by a time-dependence.

As an area of atomic and optical physics, atom optics is primarily concerned with the manipulation and control of the gross motion of atoms. The word 'optics' in 'atom optics' is in many respects an indication of realising and manipulating atoms in beam format, just as laser photons are realised in optical beam format. The analogy has led to the realisation in the laboratory of analogues of ordinary optical elements, such as atom mirrors, atom beam splitters and atom-guides [86], with the main control of atomic motion provided by optical forces.

The principal basis for the frequency-tuned optical confinement of atoms has its origin in forces associated with beam profile effects: equation (37) highlights the key role of the atomic polarizability. Resonance damping of the polarizability is attributable to several physically distinct processes responsible for the finite lifetimes of electronic excited states, which are not, in general, solely attributable to radiative decay. The accommodation of damping serves to represent dissipative and essentially stochastic effects, but it is impossible to fully accommodate the condition of time-reversal invariance—the Hamiltonian for an implicitly non-conservative system is necessarily non-Hermitian [87]. Accounting for the spherical symmetry of an ion or atom, the result is cast as:

$\begin{eqnarray}\begin{array}{rcl}\tilde{\alpha }(\omega ) & = & \displaystyle \frac{1}{3}\displaystyle \sum _{r}{| {d}^{r0}| }^{2}\left\{\displaystyle \frac{1}{{E}_{r}-{\hslash }\omega -i{\hslash }{{\rm{\Gamma }}}_{r}/2}\right.\\ & & \left.+\displaystyle \frac{1}{{E}_{r}+{\hslash }\omega \pm i{\hslash }{{\rm{\Gamma }}}_{r}/2}\right\},\end{array}\end{eqnarray} \tag{ 82 }$

where the sum is taken over all excited electronic levels r of energy E_r. The effect of the damping is primarily significant in the first, potentially resonant term in equation (82), and on approach to resonance with a specific excited state, ${{\rm{\Delta }}}_{X}=\omega -{E}_{X}/{\hslash }\to 0$ , it delivers signals with an approximately Lorentzian lineshape and full-width at half-maximum (FWHM) linewidth Γ_X. Specifically, we have:

$\begin{eqnarray}\begin{array}{rcl}\tilde{\alpha }(\omega ) & = & -\displaystyle \frac{1}{3}\left[\displaystyle \frac{| {d}^{X0}{| }^{2}}{{{\rm{\Delta }}}_{X}+i{\hslash }{{\rm{\Gamma }}}_{X}/2}-\displaystyle \frac{{| {d}^{X0}| }^{2}}{{E}_{X}+{\hslash }\omega \pm i{\hslash }{{\rm{\Gamma }}}_{X}/2}\right.\\ & & \left.+\displaystyle \sum _{r\ne X}\left\{\displaystyle \frac{{| {d}^{r0}| }^{2}}{{E}_{r}-{\hslash }\omega -i{\hslash }{{\rm{\Gamma }}}_{r}/2}+\displaystyle \frac{{| {d}^{r0}| }^{2}}{{E}_{r}+{\hslash }\omega \pm i{\hslash }{{\rm{\Gamma }}}_{r}/2}\right\}\right].\end{array}\end{eqnarray} \tag{ 83 }$

Different arguments support varying conclusions on the sign and magnitude of the damping in the anti-resonant terms the second and fourth in equation (83) (see [87–90]). However, the results for alternative signs cannot be experimentally discriminated, so these corrections can effectively be neglected.

In principle, red- and blue-detuning from a resonance leads to opposite signs for the dominant leading term—the principle is exploited in securing forces of opposite direction towards or away from regions of highest intensity, according to equation (37) and the first term in equation (83). However, it should be kept in mind that the presence of the third terms in equation (83) means that any switch in sign generally occurs at a frequency displaced from exact resonance.

Besides atom trapping as a useful property, optical forces can also lead to the transport of atoms in atom guides [91]. When Bessel beams are used as atom guides the atoms can be confined within the central region of the beam. The non-diffracting nature of the central region facilitates atom transport over long distances without transverse spreading as expected from the use of a non-vortex structured light beam. The width of the atom guide in the central region of the beam can be arranged to be as small as the order of the optical wavelength.

A LG-based dipole trap for atoms was first realized in 1997, in which approximately 10⁸ Rb atoms were confined in the LG core region using a blue-detuned LG beam and two in-plane light beams [92]. A three-dimensional dark core region surrounded by bright light, referred to as a bottle beam, has subsequently been constructed using suitable combinations of LG beams [93]. Such beams have been used to trap samples of cold atoms [94, 95], including single Rb atoms [96] which could be trapped for several seconds. Theoretical work on atom trapping in bottle beams has been reported by Aldossary [97]. Furthermore, LG beams and their superpositions have been exploited in the construction of optical ring traps and ring lattices. A dark ring trap, generated at the focus of an LG₁₀ mode, was shown to hold Rb atoms with a decay time of 1.5 s [98].

With suitable superpositions of co- or counter-propagating LG beams, ring lattices can be realized for trapping in bright or dark intensity regions. These may be used to simulate condensed matter effects: adjusting the phase twist can generate persistent currents [99, 100], and adjusting the boundary between the lattice sites should allow the realization of Mott insulator transitions. A large number of different trapping geometries is possible by combining LG modes of different OAM and radial mode number [101]. Single Rb atoms have been trapped at individual lattice sites of a bright rotating optical Ferris wheel [102]. The transfer of atoms between a bright and dark ring trap, simply by modifying the laser detuning, has also been observed [103]. OAM beams have also been used in the creation of dark spontaneous optical force traps [104].

One of the issues that quickly arose in the context of the interaction of twisted light with atoms is whether OAM can be exchanged between the twisted light and the internal atomic degrees of freedom in a process involving transition between the energy levels in analogy with the photon SAM manifestation in a radiative transition. Electromagnetically driven transitions between atomic states occur whenever the exciting field properties match the redistribution of the atomic charge and the phase of the material wavefunction. As we have seen at the outset, atomic transitions are categorised as dipole-allowed, quadrupole-allowed and higher multipolar-allowed orders. The relatively clear-cut distinction between transitions allowed at different levels of multipolarity is one of the key simplifications, due to symmetry, that arise when dealing with atoms—in contrast to molecules where electronic transitions are frequently allowed by more than one form of multipole. In a dipole-allowed transition the atom engages with the optical field strength while in a quadrupole transition it engages only with the field gradient. The field gradients in atom-field interactions can lead to transitions for atoms localised in the dark regions of the light beam where there is weak light intensity but relatively strong field gradients.

Theoretical work has necessarily focused on the distinction between the internal motion and the gross motion of an atom (or molecule) due to interaction with fields possessing OAM, with due consideration of the selection rules involved in transitions [105, 106]. Initial forays into the theory were followed by some experimental work [107, 108] which confirmed the theoretical finding of [106] that no exchange of angular momentum arises between the light and the internal degrees of freedom in a dipole-allowed transition.

Here we outline the underlying theory of OAM transfer as given in reference [106]. We focus on the two-particle model of the neutral atom as a system consisting of a negatively charged electron of mass m₁ and a positive atomic core of mass m₂ as emphasised at the outset. The Hamiltonian of this system in interaction with the light field can be written as the following sum of four parts, to be discussed in turn

$\begin{eqnarray}&&H={H}_{M}^{0}+{H}_{\mu }^{0}+{H}_{{field}}^{0}+{H}_{{int}}.\end{eqnarray} \tag{ 84 }$

H⁰_M is the centre of mass Hamiltonian, which is essentially the kinetic energy of the centre of mass

$\begin{eqnarray}&&{H}_{M}^{0}=\displaystyle \frac{{P}^{2}}{2M},\end{eqnarray} \tag{ 85 }$

where P is the centre of mass momentum with M = m₁ + m₂ the total mass. The centre of mass momentum is conjugate to the centre of mass coordinate R, defined in terms of the particle position vectors q_i; i = 1, 2, by

$\begin{eqnarray}&&{\bf{R}}=\displaystyle \frac{{m}_{1}{{\bf{q}}}_{1}+{m}_{2}{{\bf{q}}}_{2}}{M}.\end{eqnarray} \tag{ 86 }$

We are, however, interested in the possibility of the centre of mass rotating about a beam axis, so that the in-plane motion of the centre of mass kinetic energy is rotational. The appropriate form of the centre of mass Hamiltonian is then given by

$\begin{eqnarray}&&{H}_{M}^{0}=\displaystyle \frac{{L}_{z}^{2}}{2I}+\displaystyle \frac{{P}_{z}^{2}}{2M},\end{eqnarray} \tag{ 87 }$

where L_z is the angular momentum operator. Here I stands for the moment of inertia of the atomic centre of mass about the z-axis and P_z is the centre of mass momentum axial vector component. The second term in equation (84), namely ${H}_{\mu }^{0}$, pertains to the internal 'electronic-type' motion

$\begin{eqnarray}&&{H}_{\mu }^{0}=\displaystyle \frac{{p}^{2}}{2\mu }-\displaystyle \frac{{e}^{2}}{4\pi {\epsilon }_{0}q},\end{eqnarray} \tag{ 88 }$

where μ = m₁m₂/M is the reduced mass and p is the momentum conjugate to the internal coordinate q = q₁ − q₂. The second term in equation (88) is the Coulomb potential binding the two-particle system, with $q=| {\bf{q}}|$. The third term in the total Hamiltonian is defined by

$\begin{eqnarray}&&{H}_{{field}}={\hslash }\omega {a}_{{kl}}^{\dagger }{a}_{{kl}}\end{eqnarray} \tag{ 89 }$

which is the field Hamiltonian in quantised form with a_kl the annihilation operator (its Hermitian conjugate being the corresponding creation operator) of the light mode in question of frequency ω, OAM lℏ and axial wavevector ${\bf{k}}=k\hat{{\bf{z}}}$. For present purposes, any radial index p can be suppressed; the assumption is a donut mode of the lowest order for any given value of l. Finally, the last Hamiltonian term is the interaction Hamiltonian describing the coupling between the light and the two-particle bound system, representing the molecule. In the PZW scheme this can be written as

$\begin{eqnarray}&&{H}_{{int}}=-\int {d}^{3}{\bf{r}}\,{\boldsymbol{ \mathcal Q }}({\bf{r}})\cdot {\tilde{{\bf{E}}}}_{{kl}}({\bf{r}},t),\end{eqnarray} \tag{ 90 }$

where ${\tilde{{\bf{E}}}}_{{kl}}({\bf{r}},t)$ is the second quantised form of the electric field; ${\boldsymbol{ \mathcal Q }}({\bf{r}})$ is the electric polarisation defined in a closed integral form as in equation (8).

For simplicity, we have ignored all magnetic interactions. Note that, although the electric polarisation field defined in equation (8) appears to be a function of the individual particle coordinates q₁ and q₂, it can be written entirely in terms of the relative coordinate q using the relations

$\begin{eqnarray}&&{{\bf{q}}}_{\mathrm{1,2}}-{\bf{R}}=\pm {m}_{\mathrm{2,1}}{\bf{q}}/M.\end{eqnarray} \tag{ 91 }$

Any quantum-mechanical treatment of the interaction between the light and the atomic system must start by specifying the zero-order states of the overall motion, comprising the centre of mass motion (rotational and translational), the internal 'electronic-type' motion and the field state. The appropriate states are product states of the three-subsystem Hamiltonian ${H}^{0}={H}_{M}^{0}+{H}_{\mu }^{0}+{H}_{{field}}^{0}$ and can be written as

$\begin{eqnarray}&&| {P}_{z},{L}_{z};j;\{{N}_{{kl}}\}\rangle .\end{eqnarray} \tag{ 92 }$

The unperturbed motion of the centre of mass in this product state is represented by an axial translational state with linear momentum P_z, together with a rotational eigenstate of the angular momentum operator L_z with corresponding eigenvalues ℏL_z. The internal motion enters in terms of the hydrogenic excited discrete states $| j\rangle \equiv | e\rangle$ of energy E_e and a ground state $| j\rangle \equiv | g\rangle$ of energy E_g. The shorthand notation $| e\rangle$ and $| g\rangle$ stand for $| {n}_{e};{l}_{e};{m}_{e}\rangle$ and $| {n}_{g};{l}_{g};{m}_{g}\rangle$, respectively, where n_j, l_j, m_j with j ≡ e, g are hydrogenic state quantum numbers. Finally, the ket $| \{{N}_{{kl}}\rangle$ is the number state of the light field.

The evaluation of the coupling between matter and field involves working out the interaction matrix element ${{ \mathcal M }}_{{if}}$ where

$\begin{eqnarray}&&| i\rangle \equiv | {P}_{z},{L}_{z};e;\{{N}_{{kl}}\}\rangle ;\,\,\,\,\,\,\,\,| f\rangle \equiv | {P}_{z}^{{\prime} },{L}_{z}^{{\prime} };g;\{{N}_{{kl}}^{{\prime} }\}\rangle .\end{eqnarray} \tag{ 93 }$

Specifically, we have

$\begin{eqnarray}\begin{array}{rcl}{{ \mathcal M }}_{{if}} & = & -\langle {P}_{z},{L}_{z};e;\{{N}_{{kl}}\}| \\ & & \times \int {d}^{3}{\bf{r}}\,{\boldsymbol{ \mathcal Q }}({\bf{r}})\cdot {\tilde{{\bf{E}}}}_{{kl}}({\bf{r}},t)| {P}_{z}^{{\prime} },{L}_{z}^{{\prime} };g;\{{N}_{{kl}}^{{\prime} }\}\rangle .\end{array}\end{eqnarray} \tag{ 94 }$

To evaluate this matrix element, we begin by expressing the interaction Hamiltonian in the following form

$\begin{eqnarray}\begin{array}{rcl}{H}_{{int}} & = & e\displaystyle \int {d}^{3}{\bf{r}}{\displaystyle \int }_{0}^{1}\,d\lambda \left\{\displaystyle \frac{{m}_{2}}{M}{\bf{q}}\delta \left[{\bf{r}}-{\bf{R}}-\lambda \displaystyle \frac{{m}_{2}}{M}{\bf{q}}\right]\right.\\ & & \left.+\displaystyle \frac{{m}_{1}}{M}{\bf{q}}\delta \left[{\bf{r}}-{\bf{R}}+\lambda \displaystyle \frac{{m}_{1}}{M}{\bf{q}}\right]\right\}\cdot {\tilde{{\bf{E}}}}_{{kl}}({\bf{r}},t).\end{array}\end{eqnarray} \tag{ 95 }$

We cannot carry out the usual multipolar expansion, whereby the two delta functions are each expanded in powers of λm_1,2/M, leading to a series of terms multiplied by $\delta ({\bf{r}}-{\bf{R}})$ which ultimately gives rise to a dipole term, a quadrupole term and higher multipole terms The reason why the multipolar expansion is inappropriate at this stage is that the hydrogenic system has a centre of mass R which is significantly off-axis. To proceed, we now carry out the volume integral involving the full delta functions, but keeping the λ integral untouched for the time being. We have

$\begin{eqnarray}\begin{array}{rcl}{H}_{{int}} & = & \displaystyle \frac{e}{M}{\bf{q}}\cdot {\int }_{0}^{1}d\lambda \{{m}_{2}{\tilde{{\bf{E}}}}_{{kl}}({\bf{R}}+\lambda {m}_{2}{\bf{q}}/M,t)\\ & & +{m}_{1}{\tilde{{\bf{E}}}}_{{kl}}({\bf{R}}-\lambda {m}_{1}{\bf{q}}/M,t)\}.\end{array}\end{eqnarray} \tag{ 96 }$

Note that the interaction is now such that the electric field of the twisted light is now evaluated at the r = R + λm₂q/M in the first term and at r = R − λm₁q/M in the second term.

The azimuthal dependence of the atomic internal motion is referred to the centre of mass coordinates, while the twisted beam has an axis coinciding with the z-axis of the laboratory coordinate system. The position vector variables of the centre of mass ${\bf{R}}$ and the atomic internal coordinate q in polar coordinates are written as follows:

$\begin{eqnarray}&&{\bf{R}}=({R}_{\parallel },{{\rm{\Phi }}}_{R},{R}_{z});\,\,\,\,\,{\bf{q}}=({q}_{\parallel },\phi ,{q}_{z}).\end{eqnarray} \tag{ 97 }$

We need to incorporate the full azimuthal angular dependence which must be split into internal and centre of mass dependences. To be able to establish the azimuthal angular dependence, we consider projections of relevant vectors in a plane parallel to the (x, y) plane. The situation is shown in figure 12 for the vectors ${{\bf{R}}}_{\parallel },\,\lambda {m}_{2}{{\bf{q}}}_{\parallel }/M$ and their sum

$\begin{eqnarray*}&&{{\bf{V}}}_{1}={{\bf{R}}}_{\parallel }+\lambda {m}_{2}{{\bf{q}}}_{\parallel }/M\end{eqnarray*}$

in the context of the first interaction term. Similarly, the vectors R_∥ and (−λm₁q_∥/M) and their sum

$\begin{eqnarray*}&&{{\bf{V}}}_{2}={{\bf{R}}}_{\parallel }-\lambda {m}_{1}{{\bf{q}}}_{\parallel }/M\end{eqnarray*}$

would apply in the context of the second interaction term.

Zoom In Zoom Out Reset image size

In pursuit of a multipolar expansion of the interaction Hamiltonian, the next step is to express the azimuthal dependence of the two vectors V₁ and V₂ in terms of the azimuthal angle Φ_R of the centre of mass relative to the laboratory frame, and the azimuthal angle of the internal 'electronic' position vector ϕ relative to the centre of mass. This is followed by applying the approximations

$\begin{eqnarray}&&\lambda {m}_{2}{q}_{\parallel }/M\ll {R}_{\parallel };\,\,\,\,\,\lambda {m}_{2}{q}_{z}/M\ll {R}_{z}.\end{eqnarray} \tag{ 98 }$

We then find that the interaction Hamiltonian up to the quadrupole term consists of four contributions, which we can write as

$\begin{eqnarray}&&{H}_{{int}}={H}_{{int}}^{(1)}+{H}_{{int}}^{(2)}+{H}_{{int}}^{(3)}+{H}_{{int}}^{(4)}.\end{eqnarray} \tag{ 99 }$

The leading term is identifiable as the electric dipole term, which emerges from the sum of the terms linear in the vector components of the internal coordinate q. We have

$\begin{eqnarray}&&{H}_{{int}}^{(1)}=e\hat{{\boldsymbol{\epsilon }}}.{\bf{q}}{e}^{{{ikR}}_{z}}F({R}_{\parallel }){e}^{{il}{\phi }_{R}}{e}^{-i\omega t}{a}_{{kl}}+{\rm{h}}.{\rm{c}}.,\end{eqnarray} \tag{ 100 }$

where F(R_∥) is a function of the centre of mass coordinate R_∥ only. We see that, besides the internal position operator $e\hat{{\boldsymbol{\epsilon }}}.{\bf{q}}$, this interaction Hamiltonian involves the centre of mass cylindrical coordinates (R_∥, Φ_R, R_z). Remember that the eigenstates of the internal dynamics are as for a hydrogen atom, with the position vector q expressible in spherical polar coordinates where ϕ is the azimuthal angle, as is the case in cylindrical coordinates. Substitution of this in the transition matrix element, equation (94), writing the explicit forms of the translational and rotational eigenstates of the centre of mass motion and performing the space integrals, we obtain

$\begin{eqnarray}&&{{ \mathcal M }}_{{if}}={(2\pi )}^{2}\langle e| \hat{{\boldsymbol{\epsilon }}}.{\bf{d}}| g\rangle {N}_{{kl}}^{1/2}{e}^{-i\omega t}{\delta }_{({L}_{z}-{L}_{z}^{{\prime} }),l}\delta ({P}_{z}-{P}_{z}^{{\prime} }-{\hslash }k){{ \mathcal M }}_{\parallel },\end{eqnarray} \tag{ 101 }$

where d = eq is the electric dipole moment vector and ${{ \mathcal M }}_{\parallel }$ is the integral

$\begin{eqnarray}&&{{ \mathcal M }}_{\parallel }={\int }_{0}^{\infty }{{dR}}_{\parallel }{R}_{\parallel }F({R}_{\parallel }).\end{eqnarray} \tag{ 102 }$

The Dirac delta function in equation (101) exhibits conservation of the centre of mass axial linear momentum with conventional linear momentum transfer between the light and the centre of mass. The Kronecker delta expresses conservation of OAM and there is clearly OAM transfer of magnitude lℏ between the light and the centre of mass rotational motion. This transfer is not to the internal motion, and it should be emphasised again that the internal motion does not participate in any exchange of momentum between the atom and the vortex light, neither linear momentum nor OAM. Only the centre of mass responds to the vortex. As we explain later, this is the process that leads to mechanical action involving the gross dynamics of the atom as a whole, through the motion of its centre of mass, and in which the atom experiences both rotational and translational forces.

Consider next the terms ${H}_{{int}}^{(2)},{H}_{{int}}^{(3)}$ and ${H}_{{int}}^{(4)}$. These interaction terms are quadratic in the vector components of q and so correspond to quadrupole interactions. Explicitly, we have for the first type of quadrupole interaction

$\begin{eqnarray}&&{H}_{{int}}^{(2)}={c}_{1}\hat{{\boldsymbol{\epsilon }}}.{\bf{q}}{q}_{z}{e}^{{il}{{\rm{\Phi }}}_{R}}F({R}_{\parallel }){e}^{{{ikR}}_{z}}{e}^{-i\omega t}{a}_{{kl}}+{\rm{h}}{\rm{.}}{\rm{c}}.,\end{eqnarray} \tag{ 103 }$

where c₁ is a constant. The next type is of the form

$\begin{eqnarray}&&{H}_{{int}}^{(3)}={c}_{2}\hat{{\boldsymbol{\epsilon }}}.{\bf{q}}{q}_{\parallel }{e}^{i\phi }{e}^{i(l-1){{\rm{\Phi }}}_{R}}{G}_{l}^{-}({R}_{\parallel }){e}^{{{ikR}}_{z}}{e}^{-i\omega t}{a}_{{kl}}+{\rm{h}}{\rm{.}}{\rm{c}}.,\end{eqnarray} \tag{ 104 }$

where c₂ is a constant. The last is of the form

$\begin{eqnarray}&&{H}_{{int}}^{(4)}={c}_{2}\hat{{\boldsymbol{\epsilon }}}.{\bf{q}}{q}_{\parallel }{e}^{-i\phi }{e}^{i(l+1){{\rm{\Phi }}}_{R}}{G}_{l}^{+}({R}_{\parallel }){e}^{{{ikR}}_{z}}{e}^{-i\omega t}{a}_{{kl}}+{\rm{h}}.{\rm{c}}.\end{eqnarray} \tag{ 105 }$

Once ${H}_{{int}}^{(2)}$, equation (103), is inserted in the matrix element in equation (94), we can readily deduce that this term cannot mediate any transfer of OAM between the light and the internal motion. However, transfer of OAM does occur between the light and the centre of mass motion, as in the electric dipole case. This is essentially the next order of the multipolar process, over and above that due to ${H}_{{int}}^{(1)}$. By contrast, we see in the expression for ${H}_{{int}}^{(3)}$ in equation (104) that a factor ${e}^{i\phi }$ now appears in the matrix element between the internal states $| e\rangle$ and $| g\rangle$, and the centre of mass azimuthal phase factor is now ${e}^{i(l-1){{\rm{\Phi }}}_{R}}$. This is indicative of a transfer of OAM from the light beam to the internal motion, leaving only (l − 1)ℏ units to be transferred to the centre of mass rotation. Similarly when ${H}_{{int}}^{(4)}$, equation (105), is substituted in the matrix element, we can conclude that a transfer of OAM occurs between the internal motion and the light beam, with a balance of (l + 1)ℏ transferred to the centre of mass rotation. It is easy to check that the integrals over the azimuthal angle ϕ for the internal motion lead to the usual quadrupole selection rule $| {m}_{e}-{m}_{g}| =0,\pm 1,\pm 2$ where, as defined earlier, m_e and m_g are the azimuthal quantum numbers of the respective internal states $| e\rangle$ and $| g\rangle$ involved in the transition.

We have thus demonstrated by explicit analysis that in the interaction of light possessing OAM with atoms (or molecules, by a directly similar mechanism) the major mechanism of exchange of OAM occurs in the electric dipole approximation and involves only the centre of mass motion and the light beam. The internal 'electronic-type' motion does not participate in any OAM exchange with the light beam to this leading order. It is only in the weaker electric quadrupole interaction that an exchange involving all three subsystems (the light, the atomic centre of mass and the internal motion) can take place. This involves one unit of OAM being exchanged between the light beam and the internal motion, with the remaining (l ± 1)ℏ units of OAM being transferred to the centre of mass motion. The quadrupole transitions thus involve participation of two units of OAM. These conclusions rule out any experiments which seek to observe OAM exchange involving light beams and the internal states of molecular systems via electric dipole transitions.

A different treatment of this problem was given by Lloyd et al [84] in the conventional QED framework using a coupling involving the vector potential A rather than the electric field as above. Lloyd et al confirmed theoretically that an optical vortex cannot transfer OAM to the internal atomic motion in a dipole active transition, although it could do so in a quadrupole transition.

Following the publication of the work in [106], experimental research began to test the validity of the main theoretical prediction, namely that OAM cannot be transferred between an optical vortex in a dipole active transition. There was need to experimentally find out whether the OAM can influence the internal electronic degrees of freedom of the atoms, a requirement at the core of the theoretical analysis, both in the electric dipole approximation and for higher order transitions. Mathevet et al [109] gave an intuitive argument for explaining the absence of magnetic orbital dichroism in an isotropic medium as a function of the sign of the OAM. They suggested that this effect cannot be observed in transitions essentially described by the electric dipole approximation, but only when considering (at least) the higher quadrupole order.

As noted earlier the compartmentalisation of optical angular momentum into spin and orbital parts cannot always be clear-cut, and when vortex radiation is associated with circular polarizations, spin–orbit coupling can arise [33]. Circular polarizations are, of course, widely associated with chiroptical phenomena, i.e. optical interactions exhibiting a quantitative difference in an observable such as rate of excitation, for molecules of opposite handedness engaging with a particular circular polarization or equally vice versa. It is therefore not surprising that the possibility of engaging twisted light with chiral matter has become a widely researched topic. Moreover, whilst the manifestations of spin–orbit interactions do not require engagement with chiral matter (see [33–35]) the latter offer additional scope for novel effects.

The first experimental report was by Araoka et al [107] who showed that LG light is not specific in interaction with chiral matter. This was followed by the work of Löffler et al [108] who concluded that they could not find any influence of the OAM on circular dichroism in cholesteric polymers. Despite the experimental evidence provided by the work of Aroaka et al [107] and Löffler et al [108], subsequent theoretical investigations continued on the issue of the transfer of OAM to the internal degrees of freedom of atoms and molecules with some regarding it as an unsettled matter (see [109–120]) and it appeared that the community was not entirely decided upon a matter which the theoretical analysis makes quite clear. As has recently been shown, it is only possible to break this embargo under conditions that thoroughly undermine the powerful spatial isotropy principles that otherwise generally apply. Specifically, they require a chiral molecule (which can support transitions simultaneously allowed by both electric dipole and quadrupole forms of coupling) held in a fixed orientation [121].

The most recent experimental work on OAM transfer in atoms is that by Giammanco et al [122] whose results we outline below. Giammanco et al's results confirmed the earliest theoretical finding and subsequent experimental evidence [106–108] regarding the lack of influence of the photon OAM on electric dipole transitions.

In their experiment, Giammanco et al [122] aimed to find out whether or not the OAM of light has the same ability and manner of interacting with atoms as occurs for the SAM. They used laser light with different combinations of OAM and SAM to excite Rb atoms. The laser radiation was selected to inhibit or enhance the fluorescence according to the selection rules for the electric dipole transitions between the ground state and the first excited doublet states. Their experimental results showed that the OAM does not engage with the atomic internal (electronic) motion in dipole active transitions.

Figure 13 shows the absorption profiles in the case of left and right circularly polarized untwisted light (without OAM) and twisted light (with OAM). By sweeping the laser frequency in a range of 10 GHz across the Rb resonance profile, Giammanco et al were able observe the four minima in the transmission corresponding to the transitions from the ground state of ⁸⁵Rb (F₃, F₂, inner minima) and ⁸⁷Rb (F₂, F₁, outer minima). The Doppler width at their working temperature was about 529 MHz. This enabled the resolution of the hyperfine structure of the ground state (3.03 GHz and 6.83 GHz for ⁸⁵Rb and ⁸⁷Rb, respectively).

Zoom In Zoom Out Reset image size

Figure 14 shows the fluorescence signals measured under the same experimental conditions as given in figure 13. As expected, the fluorescence exhibits a complementary behaviour with respect to the absorption. The profiles of the transition lines do not exhibit significant variations within the limits of the experimental error; and with both polarizations and OAM, no disappearance of the electric dipole transition effects was observed.

Zoom In Zoom Out Reset image size

As pointed out, the experiment was an attempt to verify whether the total angular momentum of a light beam with an OAM component induces fluorescence excitation on alkali atoms or inhibits it, depending on the values of the OAM and of the SAM of the beam. Theoretical results [84, 106] suggested that this effect cannot be observed in transitions essentially described by the electric dipole approximation, but only when considering (at least) the higher quadrupole order. In short, these results corroborate the theoretical predictions [106].

The first experimental confirmation of quadrupole transitions involving twisted light interacting with a ⁴⁰Ca⁺ ion was given in [123], in which Schmiegelow et al demonstrated that a transfer of OAM from the beam to the internal electronic degrees of freedom could be observed for a quadrupole transition of a single trapped ion. This paper is briefly summarised in the next section. More recent related work extended research by both theory and experiment involving ⁴⁰Ca⁺ ion is that by Afansev et al [124] who also considered the effects of the position of the atom relative to the beam axis.

In their experiment, Schmiegelow et al [123] excited an atomic transition with a vortex laser beam and demonstrated the transfer of optical OAM to the valence electron (i.e. to the internal degrees of freedom) of a single trapped ion. They observed strongly modified selection rules showing that an atom can absorb two quanta of angular momentum from a single photon: one from the spin and another from the spatial structure of the beam. Optical vortex beams possess both an axial field gradient and a transverse (i.e. in-plane) gradient both of which can drive quadrupole transitions. In particular, the core region of the LG_1,0 beam possesses a strong field gradient, even though the intensity at the core vanishes. The interaction of such a gradient field with the quadrupole moment involves the transfer of OAM from the LG_1,0 mode to the internal dynamics of the trapped ion.

The experiment by Schmiegelow et al involved a single laser-cooled ⁴⁰Ca⁺ ion in a microstructured, segmented Paul trap. The positioning of the ion along the beam was achieved to a sub-micron accuracy by adjusting the voltages of the trapping electrodes. The key aspects of the experiment are the use of a quadrupole transition, the focusing of the probe beam close to the diffraction limit and the use of a well-localized atomic (ionic) system.

To derive the optical forces acting on a hydrogenic atom or molecule due to application of laser light we initially adopt a quantum mechanical approach based, once again, on the simple picture in which the atomic motion is described in terms of the gross dynamics of the centre of mass and the internal dynamics is in terms of a two-level system [131]. We shall see how the optical forces emerge naturally from the quantum-mechanical approach by appeal to the classical limit.

The total Hamiltonian of the light and atom and their interaction can be written as follows

$\begin{eqnarray}&&H={\hslash }\omega {a}^{\dagger }a+\displaystyle \frac{{{\bf{P}}}^{2}}{2M}+{\hslash }{\omega }_{0}{\pi }^{\dagger }\pi -i{\hslash }[{\tilde{\pi }}^{\dagger }f({\bf{R}})-{\rm{h}}.{\rm{c}}.],\end{eqnarray} \tag{ 106 }$

where $\tilde{\pi }$ and f(R) are given by

$\begin{eqnarray}&&\tilde{\pi }=\pi {{\rm{e}}}^{i\omega t};\,\,\,\,\,\,\,f({\bf{R}})=({{\boldsymbol{D}}}_{12}\cdot \hat{{\boldsymbol{\epsilon }}}){{ \mathcal F }}_{{klp}}({\bf{R}}){{\rm{e}}}^{i{{\rm{\Theta }}}_{{klp}}({\bf{R}})}/{\hslash },\end{eqnarray} \tag{ 107 }$

where π and π^† are the ladder operators of the two-level atom; P is the momentum operator of the centre-of-mass with M the total mass and ω₀ the transition frequency; a and a^† are the annihilation and creation operators of the laser light of frequency ω.

Our goal is to derive expressions for the forces acting on the atomic centre of mass appropriate for the case of a coherent optical beam whose close approximation to classical wave means that the a and a^† operators for the light become c-numbers involving a parameter b, such that

$\begin{eqnarray}&&a(t)\to b{{\rm{e}}}^{-i\omega t};\,\,\,\,\,\,\,{a}^{\dagger }(t)\to {b}^{* }{{\rm{e}}}^{i\omega t}.\end{eqnarray} \tag{ 108 }$

The interaction between the two-level atom and the laser light is given by the last term in equation (106). This is given above in the truncated multipole approximation as well as the rotating wave approximation and is evaluated at the centre of mass position vector ${\bf{R}}$. The function f(R) in equation (107) involves ${{\bf{D}}}_{12}$, the transition matrix element of the atom, including both dipole allowed and quadrupole allowed transitions. The atom is subject to a LG light mode characterised by the wave polarisation vector $\hat{{\boldsymbol{\varepsilon }}}$, the mode amplitude function, ${{ \mathcal F }}_{{klp}}({\bf{R}})$ and phase Θ_klp(R), given by expressions of the forms in equations (52)–(54) with s = 1 (denoting forward propagation) in the latter case. Here, we have

$\begin{eqnarray}\begin{array}{rcl}{{ \mathcal F }}_{{klp}}({\bf{R}}) & = & {E}_{k00}\displaystyle \frac{{C}_{p| l| }}{{(1+{z}^{2}/{z}_{R}^{2})}^{1/2}}{\left(\displaystyle \frac{\sqrt{2}\rho }{w(z)}\right)}^{| l| }\\ & & \times {L}_{p}^{| l| }\left(\displaystyle \frac{2{\rho }^{2}}{{w}^{2}(z)}\right){{\rm{e}}}^{-{\rho }^{2}/{w}^{2}(z)},\end{array}\end{eqnarray} \tag{ 109 }$

$\begin{eqnarray}\begin{array}{rcl}{{\rm{\Theta }}}_{{klp}}({\bf{R}}) & = & \displaystyle \frac{k{\rho }^{2}z}{2({z}^{2}+{z}_{R}^{2})}+l\phi \\ & & +(2p+| l| +1){\tan }^{-1}(z/{z}_{R})+{kz}.\end{array}\end{eqnarray} \tag{ 110 }$

The mode indices l and p determine the field intensity distribution and are such that lℏ is the OAM content carried by each quantum.

The classical limit demands that the position R and the momentum operator P of the atomic centre of mass should take their average values r and P₀ = MV, where V is the velocity vector of the centre of mass. This scheme treats the centre of mass motion classically while the internal atomic motion in terms of the two-level system continues to be treated quantum mechanically. This is a good approximation provided that the atomic wavepacket spread is much smaller than the laser wavelength, and that the centre of mass recoil energy in a transition is much smaller than the linewidth. The density matrix of the system can then be written as

$\begin{eqnarray}&&{\rho }_{S}=\delta ({\bf{R}}-{\bf{r}})\delta ({\bf{P}}-M{\bf{V}})\rho (t),\end{eqnarray} \tag{ 111 }$

where ρ(t) is the density matrix of the internal two-level system. This follows the standard time evolution

$\begin{eqnarray}&&\displaystyle \frac{d\rho }{{dt}}=-\displaystyle \frac{i}{{\hslash }}[H,\rho ]+{ \mathcal R }\rho ,\end{eqnarray} \tag{ 112 }$

where ${ \mathcal R }\rho$ is an added term representing relaxation in the two-level system. The evolution of the density matrix is governed by the optical Bloch equations, which are as follows

$\begin{eqnarray}&&\begin{array}{rcl}\left[\begin{array}{c}{\dot{\hat{\rho }}}_{21}(t)\\ {\dot{\hat{\rho }}}_{12}(t)\\ {\dot{\rho }}_{22}(t)\end{array}\right] & = & \left[\begin{array}{ccc}-({{\rm{\Gamma }}}_{2}-i{\rm{\Delta }}) & 0 & 2f({\bf{r}})\\ 0 & -({{\rm{\Gamma }}}_{2}+i{\rm{\Delta }}) & 2{f}^{* }({\bf{r}})\\ -{f}^{* }({\bf{r}}) & -f({\bf{r}}) & -{{\rm{\Gamma }}}_{1}\end{array}\right]\\ & & \times \,\left[\begin{array}{c}{\hat{\rho }}_{21}(t)\\ {\hat{\rho }}_{12}(t)\\ {\rho }_{22}(t)\end{array}\right]\,+\,\left[\begin{array}{c}-f({\bf{r}})\\ -{f}^{* }({\bf{r}})\\ 0\end{array}\right].\end{array}\end{eqnarray} \tag{ 113 }$

The relaxation processes in general involve two types of rates Γ_1,2 and are assumed to include both elastic and inelastic collision rates Γ_coll and such that

$\begin{eqnarray}&&{{\rm{\Gamma }}}_{1}={\rm{\Gamma }};\,\,\,\,\,\,\,{{\rm{\Gamma }}}_{2}=\displaystyle \frac{{\rm{\Gamma }}}{2}+{{\rm{\Gamma }}}_{{coll}},\end{eqnarray} \tag{ 114 }$

where Γ is the de-excitation rate of the upper state of the atomic transition. In the optical Bloch equations, Δ is the effective velocity-dependent detuning given by

$\begin{eqnarray}&&{\rm{\Delta }}={{\rm{\Delta }}}_{0}-{\boldsymbol{\nabla }}{\rm{\Theta }}\cdot {\bf{V}};\,\,\,{{\rm{\Delta }}}_{0}=\omega -{\omega }_{0},\end{eqnarray} \tag{ 115 }$

so that ${{\rm{\Delta }}}_{0}$ is the static detuning. We have also set

$\begin{eqnarray}&&\hat{\rho }=\tilde{\rho }\exp (-{it}{\bf{V}}\cdot {\boldsymbol{\nabla }}{\rm{\Theta }}).\end{eqnarray} \tag{ 116 }$

and applied the sum rule ρ₁₁(t) + ρ₂₂(t) = 1. The average force acting on the centre of mass is given by

$\begin{eqnarray}&&\langle {\bf{F}}\rangle =-\langle {tr}(\rho {\boldsymbol{\nabla }}H)\rangle \end{eqnarray} \tag{ 117 }$

and this leads to a total force that is the sum of two different forces: a dissipative force $\langle {{\bf{F}}}_{{diss}}\rangle$ and a dipole force $\langle {{\bf{F}}}_{{dipole}}\rangle$. The two radiation forces are related to the density matrix elements as follows

$\begin{eqnarray}&&\langle {{\bf{F}}}_{{diss}}({\bf{r}},t)\rangle =-{\hslash }{\boldsymbol{\nabla }}{\rm{\Theta }}({\hat{\rho }}_{21}^{* }f({\bf{r}})+{\hat{\rho }}_{21}{f}^{* }({\bf{r}})),\end{eqnarray} \tag{ 118 }$

$\begin{eqnarray}&&\langle {{\bf{F}}}_{{dipole}}({\bf{r}},t)\rangle =i{\hslash }\displaystyle \frac{{\boldsymbol{\nabla }}{\rm{\Omega }}}{{\rm{\Omega }}}({\hat{\rho }}_{21}^{* }f({\bf{r}})-{\hat{\rho }}_{21}{f}^{* }({\bf{r}})),\end{eqnarray} \tag{ 119 }$

where Ω(R) is the position-dependent Rabi frequency

$\begin{eqnarray}&&{\hslash }{\rm{\Omega }}({\bf{R}})=2| ({{\boldsymbol{d}}}_{12}\cdot \hat{{\boldsymbol{\epsilon }}}){ \mathcal F }({\bf{R}})| ;\,\,\,\,\,\,\,f({\bf{R}})={\rm{\Omega }}({\bf{R}}){{\rm{e}}}^{i{\rm{\Theta }}({\bf{R}})}/2.\end{eqnarray} \tag{ 120 }$

The gross motion is that of the centre of mass in response to the light fields. Once the total force $\langle {\bf{F}}(t)\rangle$ is known the atom dynamics can be determined by application of Newton's law, written in the form

$\begin{eqnarray}&&M\displaystyle \frac{{d}^{2}{\bf{R}}}{{{dt}}^{2}}=\langle F(t)\rangle .\end{eqnarray} \tag{ 121 }$

This, together with the initial conditions, namely the initial position vector components R(0) and initial velocity vector components V(0), are sufficient to determine the classical trajectory R(t) and the corresponding velocity ${\bf{V}}(t)=\dot{{\bf{R}}}(t)$. The solution also provides information about the time-dependent torque acting on the atomic centre of mass.

A kind of transient atom dynamics arises initially, just after the light is switched on, and depends on the characteristic time scale of the system. This type of dynamics becomes important when the excited state of the atom has a relatively long lifetime Γ⁻¹ (Γ is the de-excitation rate of the upper state of the atomic transition) [136, 137]. An example of such a scenario was studied in detail by Carter et al [136] for the case of rare-earth ions such as Eu³⁺ ions whose transition ${}^{5}{D}_{0}\to {}^{7}{D}_{1}$ has a wavelength and transition rate λ = 614 nm and Γ = 1111 Hz, respectively [138]. Although transient dynamics is of interest, most of the attention has focused on the the steady state forces as in the case of laser cooling and trapping.

The steady state forces emerge on taking the limit $t\to \infty$. This corresponds to setting time derivatives in the optical Bloch equations to zero. In the steady state, we have Γt ≪ 1, and we find that the steady state forces become position- and velocity-dependent and consist of two types. The force acting on a moving atom subject to a single LG beam propagating along the positive z-axis turns out to be in the form

$\begin{eqnarray}&&{\langle {\bf{F}}\rangle }_{{klp}}={\langle {F}_{{diss}}\rangle }_{{klp}}+{\langle {{\bf{F}}}_{{dipole}}\rangle }_{{klp}},\end{eqnarray} \tag{ 122 }$

where ${\langle {{\bf{F}}}_{{diss}}\rangle }_{{klp}}$ is the dissipative force

$\begin{eqnarray}&&\begin{array}{l}{\langle {{\bf{F}}}_{{diss}}(R,V)\rangle }_{{klp}}\\ \quad =\,{\hslash }{\rm{\Gamma }}{{\rm{\Omega }}}_{{klp}}^{2}(R)\left(\displaystyle \frac{{\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{klp}}(R)/4}{{{\rm{\Delta }}}_{{klp}}^{2}({\bf{R}},{\bf{V}})+{{\rm{\Omega }}}_{{klp}}^{2}(R)/2+{{\rm{\Gamma }}}^{2}/4}\right),\end{array}\end{eqnarray} \tag{ 123 }$

and ${\langle {F}_{{dipole}}({\bf{R}},{\bf{V}})\rangle }_{{klp}}$ is the dipole force

$\begin{eqnarray}&&\begin{array}{l}{\langle {{\bf{F}}}_{{dipole}}({\bf{R}},{\bf{V}})\rangle }_{{klp}}\\ \quad =\,-\displaystyle \frac{1}{2}{\hslash }{{\rm{\Omega }}}_{{klp}}({\bf{R}}){\boldsymbol{\nabla }}{{\rm{\Omega }}}_{{klp}}\left(\displaystyle \frac{{{\rm{\Delta }}}_{{klp}}(R,V)}{{{\rm{\Delta }}}_{{klp}}^{2}({\bf{R}},{\bf{V}})+{{\rm{\Omega }}}_{{klp}}^{2}(R)/2+{{\rm{\Gamma }}}^{2}/4}\right),\end{array}\end{eqnarray} \tag{ 124 }$

where ${{\rm{\Delta }}}_{{klp}}({\bf{R}},{\bf{V}})$ is the detuning which is both position- and velocity-dependent

$\begin{eqnarray}&&{{\rm{\Delta }}}_{{klp}}({\bf{R}},{\bf{V}})={{\rm{\Delta }}}_{0}-{\bf{V}}\cdot {\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{klp}}({\bf{R}},{\bf{V}}).\end{eqnarray} \tag{ 125 }$

Both the dissipative and dipole forces involved in the context of non-vortex light are well known in atom cooling and trapping. The dissipative force is a net frictional force responsible for optical molasses, and the dipole force corresponds to a potential which traps the atom in regions of extremum light intensity.

A steady state light induced torque acts on the atomic centre of mass due to interaction with the twisted light as can be shown by examining the velocity-independent force terms Setting V = 0 and for motion near the beam waist, i.e. z ≪ z_R we have

$\begin{eqnarray}&&{\langle {{\bf{F}}}_{{diss}}^{0}({\bf{R}})\rangle }_{{klp}}=\displaystyle \frac{{\hslash }{\rm{\Gamma }}}{4}\displaystyle \frac{{{\rm{\Omega }}}_{{klp}}^{2}({\bf{R}})}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}_{{klp}}^{2}({\bf{R}})/2+{{\rm{\Gamma }}}^{2}/4}\left[k\hat{z}+\displaystyle \frac{l}{\rho }\hat{\phi }\right].\end{eqnarray} \tag{ 126 }$

There are two vector components of this force: an axial component and an azimuthal one. Only the azimuthal component is responsible for the torque about the beam axis. Associated with the light induced force is a torque given by

$\begin{eqnarray}&&{\boldsymbol{T}}={\bf{r}}\times \langle {\bf{F}}\rangle .\end{eqnarray} \tag{ 127 }$

We find

$\begin{eqnarray}&&{\boldsymbol{ \mathcal T }}=\displaystyle \frac{{\hslash }{\rm{\Gamma }}}{4}\displaystyle \frac{{{\rm{\Omega }}}_{{klp}}^{2}(R}{{{\rm{\Delta }}}^{2}+{{\rm{\Omega }}}_{{klp}}^{2}({\bf{R}})/2+{{\rm{\Gamma }}}^{2}/4}l\hat{{\boldsymbol{z}}}.\end{eqnarray} \tag{ 128 }$

Berry and Shukla [139] referred to forces akin to the above azimuthal component as a curl force. In the saturation limit of high intensity corresponding to Ω ≫ Δ₀ and Ω ≫ Γ, we obtain

$\begin{eqnarray}&&{\boldsymbol{ \mathcal T }}\approx \displaystyle \frac{1}{2}{\hslash }l{\rm{\Gamma }}\hat{z}.\end{eqnarray} \tag{ 129 }$

This relation of the light-induced torque acting on the atom was first derived by Babiker et al [129] and has a simple interpretation as follows. Since a torque is, by definition, angular momentum per unit time, the above saturation torque arises from an angular momentum lℏ delivered over a time period of ${({\rm{\Gamma }}/2)}^{-1}$. The general form of the light-induced torque displays both velocity- and position-dependences, and so has well defined values along the atom trajectory.

The dipole force is the gradient of the dipole potential

$\begin{eqnarray}&&{\langle U({\bf{R}})\rangle }_{{klp}}=\displaystyle \frac{{\hslash }{{\rm{\Delta }}}_{0}}{2}\mathrm{ln}\left[1+\displaystyle \frac{{{\rm{\Omega }}}_{{klp}}^{2}(R)/2}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Gamma }}}^{2}/4}\right],\end{eqnarray} \tag{ 130 }$

such that

$\begin{eqnarray}&&{\langle {{\bf{F}}}_{{dipole}}^{0}\rangle }_{{klp}}=-{\boldsymbol{\nabla }}{\langle U({\bf{R}})\rangle }_{{klp}}.\end{eqnarray} \tag{ 131 }$

As in laser trapping with ordinary light, the dipole potential due to the LG beam traps atoms either in the high intensity regions of the LG beam for Δ₀ < 0 (red-detuning), or in the case of blue detuning, ${{\rm{\Delta }}}_{0}\gt 0$, in the low-intensity (i.e. dark) regions.

As an illustration we consider the LG donut mode propagating along the z-axis for which l = 1, p = 0. At focus, i.e. in the beam waist plane z = 0, the dipole potential has a minimum at radial position $\rho ={\rho }_{0}={w}_{0}/\sqrt{2}$. The locus of the minimum is therefore a circle in the (x, y) plane given by ${x}^{2}+{y}^{2}={\rho }_{0}^{2}$ and the atom is trapped for Δ₀ < 0. Expanding the potential expression at focus, i.e. ${\langle U({\bf{R}},z=0)\rangle }_{k10}$ to a harmonic approximation about ρ₀, we have

$\begin{eqnarray}&&{\langle U\rangle }_{k10}\approx {U}_{0}+\displaystyle \frac{1}{2}{{\rm{\Lambda }}}_{k10},{(\rho -{\rho }_{0})}^{2},\end{eqnarray} \tag{ 132 }$

where $| {U}_{0}|$ is the depth of the potential

$\begin{eqnarray}&&{U}_{0}=\displaystyle \frac{1}{2}{\hslash }{{\rm{\Delta }}}_{0}\mathrm{ln}\left[1+\displaystyle \frac{{{\rm{\Omega }}}_{k10}^{2}({\bf{R}})/2}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Gamma }}}^{2}/4}\right],\end{eqnarray} \tag{ 133 }$

and ${{\rm{\Lambda }}}_{k10}$ is the effective elastic modulus given by

$\begin{eqnarray}&&{{\rm{\Lambda }}}_{k10}=-\displaystyle \frac{2{\hslash }{{\rm{\Delta }}}_{0}}{{{\rm{\Delta }}}_{0}^{2}+{e}^{-1}{C}_{| l| 0}^{2}{{\rm{\Omega }}}_{k00}^{2}/2+{{\rm{\Gamma }}}^{2}/4}\left(\displaystyle \frac{{e}^{-1}{C}_{| l| ,0}^{2}{{\rm{\Omega }}}_{k00}^{2}}{{w}_{0}^{2}}\right).\end{eqnarray} \tag{ 134 }$

An atom of mass M, trapped in this potential would exhibit a vibrational motion about ρ = ρ₀ of angular frequency approximately equal to ${\{{{\rm{\Lambda }}}_{k10}/M\}}^{1/2}$.

The light-induced force and torque involve the effective velocity and position-dependent detuning Δ_klp given by

$\begin{eqnarray}&&{{\rm{\Delta }}}_{{klp}}=\omega -{\omega }_{0}-{\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{klp}}\cdot {\bf{V}}.\end{eqnarray} \tag{ 135 }$

This can be written as follows

$\begin{eqnarray}&&{{\rm{\Delta }}}_{{klp}}=\omega -{\omega }_{0}-\delta .\end{eqnarray} \tag{ 136 }$

Because of its dependence on velocity the term δ is identified as a Doppler shift. On substituting for the LG phase function Θ(R), we obtain

$\begin{eqnarray}\begin{array}{rcl}\delta & = & \left(\displaystyle \frac{k\rho z}{{z}^{2}+{z}_{R}^{2}}\right){V}_{\rho }+\displaystyle \frac{{{lV}}_{\phi }}{\rho }\\ & & +\left\{\displaystyle \frac{k{\rho }^{2}}{2({z}^{2}+{z}_{R}^{2})}\left[1-\displaystyle \frac{2{z}^{2}}{{z}^{2}+{z}_{R}^{2}}\right]\right.\\ & & +\left.\displaystyle \frac{(2p+| l| +1){z}_{R}}{{z}^{2}+{z}_{R}^{2}}+k\right\}{V}_{z},\end{array}\end{eqnarray} \tag{ 137 }$

where V_ρ, V_ϕ and V_z are the velocity vector components in cylindrical polar coordinates. It is seen that δ consists of four terms: an axial term ${\delta }_{{axial}}$, a term arising from the Gouy phase δ_Gouy, a beam curvature term δ_curve and an azimuthal term δ_azimuth, so that

$\begin{eqnarray}&&\delta ={\delta }_{{axial}}+{\delta }_{{Gouy}}+{\delta }_{{curve}}+{\delta }_{{azimuth}}.\end{eqnarray} \tag{ 138 }$

The axial term δ_axial is identical to a Doppler shift due to a plane wave of wavenumber k travelling along the beam axis

$\begin{eqnarray}&&{\delta }_{{axial}}={{kV}}_{z}\end{eqnarray} \tag{ 139 }$

and the Gouy phase Doppler shift is

$\begin{eqnarray}&&{\delta }_{{Gouy}}=\left(\displaystyle \frac{(2p+| l| +1){z}_{R}}{{z}^{2}+{z}_{R}^{2}}\right){V}_{z}.\end{eqnarray} \tag{ 140 }$

For LG beam with low integer values of l and p, the Gouy phase Doppler shift would be negligibly small since typically z_R ≫ w₀. As will be discussed later, this term becomes significant, for large values of l and/or p.

The curvature Doppler shift is given by

$\begin{eqnarray}&&{\delta }_{{curve}}=\left(\displaystyle \frac{k\rho z}{{z}^{2}+{z}_{R}^{2}}\right){V}_{\rho }+\displaystyle \frac{k{\rho }^{2}}{2({z}^{2}+{z}_{R}^{2})}\left[1-\displaystyle \frac{2{z}^{2}}{{z}^{2}+{z}_{R}^{2}}\right]{V}_{z}.\end{eqnarray} \tag{ 141 }$

This Doppler shift is caused by the wavefront curvature spreading of the beam in the radial and axial directions and could be observable under appropriate conditions. Finally, a Doppler shift which arises directly from the vortex nature of the twisted light is the azimuthal Doppler shift, which is given by

$\begin{eqnarray}&&{\delta }_{{azimuth}}=\displaystyle \frac{{{lV}}_{\phi }}{\rho }.\end{eqnarray} \tag{ 142 }$

This is directly proportional to the winding number l characterising the angular momentum property of the twisted light, but it is also inversely proportional to ρ the radial coordinate of the atom. Note that the dependence on l includes both the magnitude and the sign of the winding number.

Experimental work on the azimuthal Doppler shift was reported by Luo et al [140] and Aramaki et al [141]. Luo et al detected the Doppler effect associated with light beams carrying OAM in 'left-handed materials'. However, they reported that the azimuthal Doppler shift, proportional to the OAM of photons, was not reversed compared to conventional positive-index materials. They attributed this result to two joint contributions, one from the negative phase velocity and the other from the inverse screw of the wave-front. Aramaki et al performed a modified saturated absorption spectroscopy to separate the components. The optical vortex and a plane wave are used as a probe beam and pump beam, respectively. Although the plane-wave pump laser cancels the axial-direction Doppler shift, the azimuthal Doppler shift remained in the saturated dip. The spatial variation of the dip width provided information on the azimuthal Doppler shift.

The dynamics of the atom is governed by Newton's second law, together with well defined initial conditions. The solutions leads to the trajectory R(t) as well as other dynamical properties of the system. However, the analytical form of the trajectory R(t) cannot be determined in general and there is, inevitably, a need to resort to computational analysis. One of the significant properties that can be verified directly is that the trajectories for two cases in which the atom is subject to single separate LG beams with opposite but equal signs of l, are identical except for a reversal of the direction of atom rotation. This is consistent with the dependence of the light-induced torque on the magnitude and sign of l.

It is well known that Doppler cooling leads to the optical molasses effect in multiple beams in one, two and three dimensions. We expect a form of optical molasses effect to occur for twisted beams, but the description of optical molasses in this context demands, as a first step, the specification of each of the multiple beam field distributions relative to the same (the laboratory) coordinate frame. This step requires the application of coordinate transformations. For relatively weak beams, the nett light-induced force due to all beams in the molasses configuration is the vector sum of individual light-induced forces and the atom trajectory in the multiple beams arises from the solution of the equation: mass times acceleration equals the vector sum of all forces entering Newton's law.

For illustration, we consider a basic twisted light beam of frequency ω, axial wavevector k and quantum numbers l and p coupled to an atom or an ion at a general position vector R = (ρ, ϕ, z). In cylindrical coordinates, the phase Θ_klp(R) and the Rabi frequency Ω_klp(R) are taken as follows

$\begin{eqnarray}&&{{\rm{\Theta }}}_{{klp}}=l\phi +{kz}\end{eqnarray} \tag{ 143 }$

and

$\begin{eqnarray}&&{{\rm{\Omega }}}_{{klp}}({\bf{R}})={{\rm{\Omega }}}_{0}{C}_{| l| p}{\left(\displaystyle \frac{\rho \sqrt{2}}{{w}_{0}}\right)}^{| l| }\exp (-{\rho }^{2}{/w}_{0}^{2}){L}_{p}^{| l| }\left(\displaystyle \frac{2{\rho }^{2}}{{w}_{0}^{2}}\right).\end{eqnarray} \tag{ 144 }$

The above expressions apply for a LG beam in the large Rayleigh range limit z ≪ z_R and also setting w(z) = w₀, which also means disregarding beam curvature effects.

The steady state light-induced forces acting on the centre of mass are given above but with the approximate phase Θ_klp(R) and Rabi frequency Ω_klp(R), as in equations (143) and (144). These expressions are in cylindrical polar coordinates with the direction of propagation along the positive z-axis. However, in order to derive the dynamics for multiple beams, we need to express the position dependence in Cartesian coordinates R = (x, y, z), using $\rho =\sqrt{{x}^{2}+{y}^{2}}$ and $\phi =\arctan (y/x)$. The expression for an LG beam whose axis of propagation is in an arbitrary direction is obtained by applying two successive transformations with the first transformation involving a rotation about the y-axis by an angle θ and the second is another rotation about the x-axis by an angle ψ.

An appropriate choice of θ and ψ leads to the force distribution due to a twisted light beam propagating in any desired direction. This procedure allows consideration of geometrical arrangements involving counter-propagating beams (especially those corresponding to one-, two- and three-dimensional optical molasses configurations).

As a specific application of the above scheme, we consider optical molasses of magnesium ions Mg⁺ in multiple beams. The requisite transition is of frequency ω₀ corresponding to the wavelength λ = 280.1 nm and transition rate ${\rm{\Gamma }}/2=2.7\,\times \,{10}^{8}$ s⁻¹. The Mg⁺ mass is M = 4.0 × 10⁻²⁶ kg. To have trapping in regions of high field intensities, we must choose red-detuned light such that Δ₀ = −Γ/2 and we assume a value of the beam waist w₀ = 35λ. The equation of motion for the Mg⁺ ion is written as

$\begin{eqnarray}&&M\displaystyle \frac{{d}^{2}}{{{dt}}^{2}}{\bf{R}}(t)=\displaystyle \sum _{i}\langle {{\bf{F}}}_{i}\rangle .\end{eqnarray} \tag{ 145 }$

The sum is over all individual force vector contributions due to all beams present in the configuration. The simplest case is the one-dimensional molasses configuration, which involves a pair of identical counter-propagating twisted light beams arranged along the z-axis. Figure 15 (top left) shows the trajectory of the Mg⁺ ion with ${l}_{1}=-{l}_{2}=1$ and p₁ = p₂ = 0. The initial radial position is ρ = 10λ and the initial velocity is V(0) = 5 m s${}^{-1}\hat{{\bf{z}}}$. The motion is for a time duration equal to 4 × 10⁵ Γ⁻¹.

Zoom In Zoom Out Reset image size

Once the Mg⁺ ion is trapped in the high intensity ring which is located at the fixed focus point z = 0, it rotates clockwise about the common axis. This rotation is due to the light-induced torque which, in the saturation limit, is given by $| \langle {\boldsymbol{ \mathcal T }}\rangle | \approx {l}_{1}{\hslash }{\rm{\Gamma }}/2-{l}_{2}{\hslash }{\rm{\Gamma }}/2={\hslash }{\rm{\Gamma }}$.

It is easy to see that the motion of the trapped ions at azimuthal speed v_s gives rise to an electric current equal to $e/\tau \equiv {{ev}}_{s}/2\pi {\rho }_{0}$ per rotating axially trapped particle. With v_s of about 2 m s⁻¹ and ${\rho }_{0}\approx {w}_{0}=35\lambda$ we have an ionic current of the order of a fA per particle. Note that the electric current scales with the number of trapped ions; if a million or so ions are involved they can produce an electric current on the nA scale.

The two-dimensional molasses configuration arises when we introduce in addition to the pair along the z-axis of waist w₀ a second pair of counter-propagating beams along the x-axis of waist ${w}_{0}^{{\prime} }$, which can be equal or different from w₀. The net force in this case is the vector sum of the individual forces from the four beams. The appropriate functional dependences of three of the beams are obtained from the expression of a beam along the z-direction using transformation equations for axis rotation. The trajectories in figure 15 (top right) are of two Mg⁺ ions initially located at different points with each having an initial velocity of ${v}_{z}=5\,{\rm{m}}\,{{\rm{s}}}^{-1}$. The ions are subject to the four beams where each beam of has a waist w₀, an azimuthal index, l = 1, and radial index, p = 0.

The total torque about the common axis arising from each pair is zero. This is because the choice of l values produces identical torques of opposite senses which cancel in this case. Thus each ion ends up at a specific fixed point, depending on the initial conditions and it remains at that fixed point essentially motionless. To understand this, we should note that the deepest dipole potential well is four times the depth due to a single beam. The potential minima are situated on the locus of spatial points defined simultaneously by two equations ${x}^{2}+{y}^{2}={w}_{0}^{2}/2$ and ${y}^{2}+{z}^{2}=w{{\prime} }_{0}^{2}/2$. For $w{{\prime} }_{0}={w}_{0}$ these two equations describe two orthogonal oblique circles representing the intersection curves of two cylinders of radii ${w}_{0}/\sqrt{2}$. Solving for x and y, we have $x=\pm z$ and $y=\pm \sqrt{{w}_{0}^{2}/2-{z}^{2}}$.

The locus of spatial points where the dipole potential is minimum can be described by the parametric equations

$\begin{eqnarray}\begin{array}{rcl}x(u) & = & ({w}_{0}^{{\prime} }/\sqrt{2})\cos u\\ y(u) & = & ({w}_{0}^{{\prime} }/\sqrt{2})\sin u\\ z(u) & = & \pm \sqrt{{w}_{0}^{2}/2-(w{{\prime} }_{0}^{2}/2){\sin }^{2}u}.\end{array}\end{eqnarray} \tag{ 146 }$

All Mg⁺ ions in the two-dimensional configuration of orthogonal counter-propagating pairs of twisted beams will be trapped at points lying on one of the two oblique circles, as determined by the initial conditions. An ensemble of Mg⁺ ions with a distribution of initial positions and velocities will populate the two circles, producing two orthogonal essentially static Mg⁺ ion loops. Associated with this system of charges would be a Coulomb field whose spatial distribution, for example, for ions uniformly distributed in the ring can easily be evaluated. When the values of l are such that each pair of beams generates a torque, the motion becomes more complicated, but the ions will seek to congregate in the region of potential minima, while responding to the combined effects of two orthogonal torques and orthogonal axial cooling forces.

When a third pair of counter-propagating beams is added to the two-dimensional configuration, orthogonal to the plane containing the original beams, we have a three-dimensional configuration. In this case, the deepest potential minima are located at eight discrete points defined by the coordinates: $x=\pm \tfrac{{w}_{0}}{\sqrt{2}},y=\pm \tfrac{{w}_{0}}{\sqrt{2}},z=\pm \tfrac{{w}_{0}}{\sqrt{2}}$. These coincide with the eight corners of a cube of side w₀, centred at the origin of coordinates. Figure 15 (bottom) exhibits the trajectories of eight atoms which end up being trapped at the eight corners of the cube.

A number of experiments by Anderson et al [142] and Clade' et al [144] showed that a BEC of sodium atoms can be trapped in the field of a donut beam and a Gaussian beam or a sheet beam and with the atomic ensemble exhibiting a quantised superfluid behaviour. The atoms were made to rotate in the donut ring by the light-induced torque [129] and constituted a relatively long-lived persistent current for a time more than twenty times the duration for the atoms confined in a spheroidal trap. A snap-shot image of the trapped atom is presented in figure 16. The flow was observed to persist even when there was a large (80%) thermal fraction present in the toroidal trap. These experiments open the possibility for investigations of the fundamental role of flow in superfluidity and of realizing the atomic equivalent of superconducting circuits and devices such as SQUIDs [145]. Atoms trapped in such ring-shaped traps could form the basis of quantum motors. Generally, such findings were hailed as paving the way towards the realisation of atom circuits in the field of atomtronics [145–147].

Zoom In Zoom Out Reset image size

As described earlier the Sisyphus effect which uses ordinary plane wave laser light has been shown to provide an efficient cooling mechanism, which has succeeded in cooling atoms to temperatures well below the Doppler cooling limit [44, 58]. The point to emphasise here is that this cooling method is based on the creation of a standing wave exhibiting polarisation gradients using counter-propagating laser beams. The polarisation gradients are responsible for the generation of spatially dependent light shifts, which result in spatially modulated energy levels along the beam axis. This interaction landscape is characterised by potential hills which an atom has to climb more than it descends in the processes of stimulated and spontaneous emission cycles between the energy levels. The atom progressively loses its kinetic energy and slows down.

An analogue of the Sisyphus mechanism has been predicted by Lembessis et al [148] concerned with the case of the azimuthal atomic motion in the annular region of maximum intensity when the atom is irradiated by two LG beams with ${\rm{lin}}\perp {\rm{lin}}$ polarizations, i.e. having orthogonal linear polarisations. The azimuthal motion arises in the context involving two co-centred, co propagating LG beams, labelled 1 and 2, of the same frequency ω and axial wave vector of magnitude k. The beams have the same magnitude of the winding number $| l|$ but differ only in the sign of l.

In the focus plane z = 0, the electric field consists of two in quadrature fields with the amplitudes proportional to $\cos (l\phi )$ and $\sin (l\phi )$. The wave polarisation form varies with angular position and is in general elliptical, displaying both linear and circular forms at certain angles, as ϕ varies. The situation is equivalent to the conventional polarisation gradient due to two counter-propagating plane wave light beams where the changes in polarisation are cyclic, with a spatial periodicity of the standing wave along the z-axis equal to the wavelength of the light λ = 2π/k. Here, the periodicity occurs in the azimuthal direction. However, the spatial extent of the polarisation gradient depends on the beam waist w₀ as well as the winding number l.

We now consider the atom dynamics in such a light field and we focus on an atom with transitions between a hyperfine ground state J_g = 1/2 and an excited state J_e = 3/2. The Clebsch–Gordan coefficients of the various possible transitions are indicated by the numbers in the inset of figure 17 with the squares of the numbers indicated representing the corresponding transition probabilities. We also make the assumption that the atomic motion is restricted in the annular region of radius ${\rho }_{0}={w}_{0}\sqrt{| l| /2}$ where the intensity of the beams is highest (when p = 0). The optical potentials associated with the two Zeeman sub-level shifts are given by

$\begin{eqnarray}&&{U}_{\pm }=\displaystyle \frac{2}{3}{\hslash }{{\rm{\Delta }}}_{0}^{{\prime} }[2\mp \cos (2| l| \phi )],\end{eqnarray} \tag{ 147 }$

where s₀ is the saturation parameter at ${\rho }_{0}={w}_{0}\sqrt{| l| /2}$ and ${{\rm{\Delta }}}_{0}^{{\prime} }$ is given by

$\begin{eqnarray}&&{{\rm{\Delta }}}_{0}^{{\prime} }={s}_{0}{{\rm{\Delta }}}_{0}/2;\,\,\,\,{s}_{0}=\displaystyle \frac{{{\rm{\Omega }}}_{\max }^{2}/2}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Gamma }}}^{2}/4}.\end{eqnarray} \tag{ 148 }$

Here Ω_max is the Rabi frequency at ρ₀ which, in the case where p = 0, is given by ${{\rm{\Omega }}}_{\max }={{\rm{\Omega }}}_{k00}{C}_{| l| 0}{e}^{-| l| /2}{(| l| /2)}^{| l| /2}{2}^{| l| /2}$. For large values of $| l|$, we may use Stirling's approximation and we have ${{\rm{\Omega }}}_{\max }={{\rm{\Omega }}}_{k00}{C}_{| l| 0}| l| !/\sqrt{2\pi | l| }$. The potentials U_± are the optical potentials for the $| {g}_{\pm 1/2}\rangle$ sub-levels. It is easy to see that the minima of one potential correspond to the maxima of the other and vice versa, and the maxima and minima correspond to positions where the polarisation is ${\hat{\sigma }}_{\pm }$ (purely circular).

Zoom In Zoom Out Reset image size

Suppose now that the angular position of the atom within the annular ring is $\phi =\pi /4| l|$ and that the light field has a circular polarisation ${\hat{\sigma }}_{-}$. If we assume that the atom is optically pumped to level $| {g}_{-1/2}\rangle$, the population of the level $| {g}_{+1/2}\rangle$ is then zero. Furthermore we consider that the detuning is negative so that both light shifts are negative. If the atom is shifted within the annular trap to an angular position at $\phi =3\pi /4| l|$ the level populations are reversed. Finally, if the atom is at angular positions where the polarization is linear, the two sublevels are equally populated. This scenario is summarized in figure 17.

When the light intensity is sufficiently low so that the excited state population is negligible the cooling of the atomic azimuthal motion can be explained with reference to the inset of figure 17. This shows the energy levels for the ${J}_{g}=1/2\leftrightarrow {J}_{e}=3/2$ transition and the relevant transition probabilities. If the atom is located at $\phi =\pi /4| l|$ where the polarization is ${\hat{\sigma }}_{-}$, the absorption of a σ₋ photon takes the atom from $| {g}_{+1/2}\rangle$ to $| {e}_{-1/2}\rangle$. This process is followed by a decay of the atom from the state $| {e}_{-1/2}\rangle$ to the state $| {g}_{-1/2}\rangle$. If the decay is from $| {e}_{-1/2}\rangle$ to $| {g}_{+1/2}\rangle$, the atom can absorb a σ₋ photon and have another chance to arrive at $| {g}_{-1/2}\rangle$. By contrast, absorbing a σ₋ photon when in $| {g}_{-1/2}\rangle$ promotes the atom to $| {e}_{-3/2}\rangle$ from which the atom can decay to $| {g}_{-1/2}\rangle$. It follows that in the steady state all the atomic population is optically pumped into $| {g}_{-1/2}\rangle$. If the atom is at $\phi =3\pi /4| l|$ where the polarization is ${\hat{\sigma }}_{+}$, the above scenario is reversed.

The damping of the atomic motion in the Sisyphus effect is characterised by a damping coefficient which can be calculated as follows. Let us assume that initially the atom performs circular motion at a radius ${\rho }_{0}={w}_{0}/\sqrt{2| l| }$ with an azimuthal speed v_ϕ. As explained in table 1 and with reference to figure 17, the atom in effect sees an azimuthal standing wave of an equivalent wavelength ${\lambda }_{\phi }=\pi {w}_{0}/\sqrt{2| l| }$. We define the two-level relaxation time as τ_R = Γ⁻¹ and an optical pumping time between sublevels ${\tau }_{P}={\rm{\Gamma }}{{\prime} }^{-1}$. In general the atomic internal state does not follow adiabatically the variations of the light field. To take into account this fact, we introduce two adiabaticity parameters: one is a two-level atom adiabaticity parameter _ϕ, defined as the ratio between the length of the arc travelled by the atom during its internal relaxation. The other is a characteristic length of the azimuthal spatial variations of the laser field (i.e. the wavelength λ_ϕ). For _ϕ, we write

$\begin{eqnarray}&&{\epsilon }_{\phi }=\displaystyle \frac{{v}_{\phi }{\tau }_{R}}{{\lambda }_{\phi }}=\displaystyle \frac{{v}_{\phi }\sqrt{2| l| }}{\pi {w}_{0}{\rm{\Gamma }}}.\end{eqnarray} \tag{ 149 }$

The corresponding multi-level parameter ${\epsilon }_{\phi }^{{\prime} }$ is defined as

$\begin{eqnarray}&&{\epsilon }_{\phi }^{{\prime} }=\displaystyle \frac{{v}_{\phi }{\tau }_{P}}{{\lambda }_{\phi }}=\displaystyle \frac{{v}_{\phi }\sqrt{2| l| }}{\pi {w}_{0}{\rm{\Gamma }}^{\prime} }.\end{eqnarray} \tag{ 150 }$

At low laser powers, we have ${\epsilon }_{\phi }^{{\prime} }\gg {\epsilon }_{\phi }$ since ${\rm{\Gamma }}^{\prime} \ll {\rm{\Gamma }}$, i.e. τ_R ≪ τ_P. The condition for the non-adiabatic effects coming into play is then approximately given by $\epsilon ^{\prime} \approx 1$, which leads to

$\begin{eqnarray}&&\displaystyle \frac{{v}_{\phi }\sqrt{2| l| }}{\pi {w}_{0}}\approx {\rm{\Gamma }}^{\prime} .\end{eqnarray} \tag{ 151 }$

The resulting azimuthal damping force is then given by

$\begin{eqnarray}&&{F}_{\phi }=-{\alpha }_{\phi }{v}_{\phi }.\end{eqnarray} \tag{ 152 }$

where α_ϕ is an azimuthal damping coefficient. This coefficient can be estimated qualitatively following Dalibard and Cohen-Tannoudji [58] and is given by

$\begin{eqnarray}&&{\alpha }_{\phi }={\hslash }{\left(\displaystyle \frac{2\pi }{\pi {w}_{0}/\sqrt{2| l| }}\right)}^{2}\displaystyle \frac{{{\rm{\Delta }}}_{0}}{{\rm{\Gamma }}}=\displaystyle \frac{8{\hslash }| l| {{\rm{\Delta }}}_{0}}{{w}_{0}^{2}{\rm{\Gamma }}}.\end{eqnarray} \tag{ 153 }$

Associated with the friction force is a torque about the common beams' axis directed along $\hat{{\boldsymbol{z}}}$, operative at ${\rho }_{0}={w}_{0}/\sqrt{2| l| }$ and given by

$\begin{eqnarray}&&{\boldsymbol{ \mathcal T }}={{\boldsymbol{r\times F}}}_{\phi }=\displaystyle \frac{4\sqrt{2| l| }{\hslash }{v}_{\phi }{{\rm{\Delta }}}_{0}}{{w}_{0}{\rm{\Gamma }}}\hat{{\boldsymbol{z}}}.\end{eqnarray} \tag{ 154 }$

It is seen that the damping coefficient is proportional to the magnitude of the winding number l, while the torque is proportional to the square root of $| l|$ through its dependence on the radius of the annular region. Hence the higher the value of $| l|$ the larger the annular radius, and consequently the larger the number of potential hills there are for the atoms to climb. Note that the damping coefficient and the torque are inversely proportional to the beam waist w₀. The larger the beam waist, the further apart the potential hills are and this amounts to less effective damping and smaller torque due to the potential hill climbed by the atom.

As an illustration, we consider Cs atoms interacting with a light field of wavelength λ = 852.35 nm, which can thus excite the transition ${6}^{2}{S}_{1/2}-{6}^{2}{P}_{3/2}$, where the upper state ${6}^{2}{P}_{3/2}$ has a spontaneous emission rate Γ = 3.25 × 10⁷ s⁻¹. We assume a detuning Δ₀ = 2Γ and the Rabi frequency Ω is taken to be 0.1Γ. These atomic transitions and orders of parameter were used in the pioneering experiment that confirmed the validity of Sisyphus cooling mechanism [47]. Finally, for the LG beams we take $| l| =20$ and the beam waist w₀ = 10λ. With these parameters equation (151) yields the azimuthal velocity at which Sisyphus effect commences as v_ϕ = 3.6 cm s⁻¹. We have made use of the following relationship [58] giving the pumping rate ${\rm{\Gamma }}^{\prime}$ in terms of Γ and the saturation parameter ${\rm{\Gamma }}^{\prime} =2{\rm{\Gamma }}{s}_{0}/9$. The value of the azimuthal damping coefficient corresponding to the above parameters turns out to be α_ϕ = 4.65 × 10⁻²² kg s⁻¹. For the same parameters, the azimuthal velocity in the Doppler limit is v_ϕ = 8.82 cm s⁻¹ approximately twice the azimuthal velocity at which the Sisyphus effect commences. Both are much larger than the recoil velocity of 0.35 cm s⁻¹.

It is instructive to compare the Sisyphus cooling mechanism with other azimuthal cooling mechanisms. The Doppler regime for a twisted single beam involves a torque acting on the two-level atom, which has a magnitude at the radial coordinate ${\rho }_{0}={w}_{0}\sqrt{| l| /2}$ (where the Rabi frequency maximises), is given by:

$\begin{eqnarray}&&{T}_{{TS}}={\hslash }{\rm{\Gamma }}l\displaystyle \frac{{{\rm{\Omega }}}_{\max }^{2}/4}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}_{\max }^{2}/2+{{\rm{\Gamma }}}^{2}/4}.\end{eqnarray} \tag{ 155 }$

This torque is proportional to l and so can be positive or negative. It is easy to verify that it depends on the radial but not the angular position of the atom. In the saturation limit, achieved at high intensities, the torque becomes T_TS ≈ lℏΓ/2, which is position-independent. In the twisted molasses (M) situation, which involves two counter-propagating donut beams, also within the Doppler regime, the atom experiences a torque of magnitude given by:

$\begin{eqnarray}&&{T}_{M}=\displaystyle \frac{{\hslash }{kl}{{\rm{\Delta }}}_{0}{\rm{\Gamma }}{{\rm{\Omega }}}_{\max }^{2}}{{({{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}_{\max }^{2}/2+{{\rm{\Gamma }}}^{2}/4)}^{2}}{v}_{z},\end{eqnarray} \tag{ 156 }$

where v_z is the axial component of the velocity. This torque is also proportional to l and in the high intensity limit, we have ${{\boldsymbol{ \mathcal T }}}_{M}\approx \left(\tfrac{4{\hslash }{kl}{{\rm{\Delta }}}_{0}{\rm{\Gamma }}}{{{\rm{\Omega }}}_{\max }^{2}}\right){v}_{z}$. So this torque decreases with increasing intensity. By contrast, here the general torque in the azimuthal Sisyphus effect emerges as

$\begin{eqnarray}&&{{\boldsymbol{ \mathcal T }}}_{S}=\displaystyle \frac{8{\hslash }| l| {{\rm{\Delta }}}_{0}}{{w}_{0}^{2}{\rm{\Gamma }}}{v}_{\phi }\rho ,\end{eqnarray} \tag{ 157 }$

where ${{\rm{\Delta }}}_{0}$ is the static detuning, applicable here as the Doppler effect is negligible at low velocities. This torque is proportional to the azimuthal velocity and the magnitude of l, and inversely proportional to the beam waist w₀. It is a function of the radial coordinate ρ, but it does not depend on the light intensity. Significantly, this torque is proportional to the detuning Δ₀, which can be positive, or negative. This suggests that the Sisyphus effect is a mechanism with which we can accelerate or decelerate the azimuthal atomic motion by simply changing the sign of the detuning, as in the twisted molasses case. This may be exploited for controlling the azimuthal motion in different types of atomic samples trapped in annular regions. We also see that the general torque in the azimuthal Sisyphus effect is inversely proportional to the relaxation rate Γ while in the case of Doppler cooling, it is directly proportional to Γ. This reflects the different physical processes that are behind the generation of the two cooling mechanisms.

A crucial parameter in this context is the beam waist. In the case of the azimuthal Sisyphus effect the torque is inversely proportional to the square of the beam waist. In the annular region, where $\rho ={w}_{0}\sqrt{| l| /2}$, equation (157) yields ${{\boldsymbol{ \mathcal T }}}_{S}=\tfrac{4\sqrt{2}{\hslash }| l{| }^{3/2}{{\rm{\Delta }}}_{0}}{{w}_{0}{\rm{\Gamma }}}{v}_{\phi }$. Thus twisted beams with large cross sections, i.e. weak focusing, will result in smaller torques. This is because as the beam waist increases the characteristic length of the azimuthal spatial variations of the laser field (i.e. the 'wavelength' λ_ϕ) becomes larger. This is equivalent to a Sisyphus effect in a field with a larger wavelength and thus to a smaller Sisyphus torque. The torque created by the Doppler mechanism does not depend explicitly on the beam waist. This is clear in the case of irradiation by a single beam in the saturation limit; for the case of twisted molasses as given by equation (156), a larger beam waist (for a given power) results in a smaller Rabi frequency and thus to larger torques.

Finally, we must emphasise the role of the dependence on the winding number l. In the Doppler mechanism, a larger winding number leads to larger torques and this is reasonable since it is associated with the angular momentum exchanged between the light and the atom. In the case of the azimuthal Sisyphus effect, again an increase in l leads to a larger damping. This is because the equivalent wavelength λ_ϕ becomes smaller and thus leads to a more effective Sisyphus effect.

Consider a Ferris wheel light field composed of two LG beams labelled 1, 2 co-propagating along the z-direction and both are polarised along the x-direction, but with opposite optical angular momenta l₁ = −l₂ = l. The electric fields of these LG beams are given by:

$\begin{eqnarray}&&{{\bf{E}}}_{\mathrm{1,2}}(z,\rho ,\phi )=\displaystyle \frac{1}{2}{E}_{k00}{C}_{| l| ,p}{u}_{p}^{l}(\rho ,z)\exp ({ikz}\pm {il}\phi )\hat{{\boldsymbol{x}}},\end{eqnarray} \tag{ 158 }$

with

$\begin{eqnarray}\begin{array}{rcl}{u}_{p}^{l}(\rho ,z) & = & \displaystyle \frac{1}{\sqrt{1+{z}^{2}/{z}_{R}^{2}}}{\left(\displaystyle \frac{\sqrt{2}\rho }{{w}_{0}\sqrt{1+{z}^{2}/{z}_{R}^{2}}}\right)}^{| l| }\\ & & \times {L}_{p}^{| l| }\left(\displaystyle \frac{\sqrt{2}\rho }{{w}_{0}\sqrt{1+{z}^{2}/{z}_{R}^{2}}}\right)\exp \left(-\displaystyle \frac{{\rho }^{2}}{{w}_{0}^{2}(1+{z}^{2}/{z}_{R}^{2})}\right).\end{array}\end{eqnarray} \tag{ 159 }$

The total electric field of the optical Ferris wheel light field is the sum

$\begin{eqnarray}&&{\bf{E}}(z,\rho ,\phi )={E}_{k00}{C}_{| l| p}{u}_{p}^{l}(\rho ,z)\cos (l\phi )\exp ({ikz})\hat{{\boldsymbol{x}}}.\end{eqnarray} \tag{ 160 }$

The intensity of the light field is then $I\propto {[{u}_{p}^{l}(\rho ,z)]}^{2}{\cos }^{2}(l\phi )$. The presence of the factor ${\cos }^{2}(l\phi )$ leads to the appearance of $2l$ petal-like high intensity regions. Figure 18 displays the spatial distribution of the Ferris wheel light field intensity (in arbitrary units) for the case where l = 2 and p = 0 and for the case where l = 2 and p = 1 together with the corresponding contour plots. These show the characteristic four petal-like intensity distribution. The Ferris wheel petal-like structure is richer when the radial index p is different from zero, in which case the intensity displays p + 1 petal-like regions.

Zoom In Zoom Out Reset image size

The above light fields are not the only ones that can be constructed. Other cylindrically symmetric optical lattices can be realised by interfering beams with opposite l but also different magnitudes. Such a scenario presents interesting features. The maximum of the at-focus intensity of the field of a donut beam occurs at the radial position ${\rho }_{0}=\sqrt{| l| /2}{w}_{0}$. Thus LG beams with different magnitudes of the azimuthal index l have their intensity maxima at different radial positions. The electric field of an LG beam has a FWHM equal to $2\mathrm{ln}(2){w}_{0}$ in the radial direction. The interference of such beams is such that ${\rho }_{\mathrm{1,0}}-{\rho }_{\mathrm{2,0}}=2\mathrm{ln}(2){w}_{0}$. The two LG fields have similar maximum amplitudes and are separated by one FWHM. This leads to a dark Ferris wheel lattice with an approximately uniform depth in the radial and azimuthal directions.

Furthermore, the optical Ferris wheel intensity patterns can be rotated in space when the two beams have a slight difference in frequency Δω = ω₂ − ω₁. There are various methods for the generation of precise laser frequency shifts, as for example by passing the light through an acousto-optical modulator, or when circularly polarized light is passed through a rotating half wave plate [160], which, due to an accumulated geometric or Berry phase [161], shifts the frequency by twice the rotational speed of the waveplate in the context of optical tweezers [162]. A rotating Ferris wheel due to a frequency difference Δω has an the electric field of the form:

$\begin{eqnarray}\begin{array}{rcl}{\bf{E}}(z,\rho ,\phi ) & = & \displaystyle \frac{1}{2}{E}_{k00}{C}_{| l| ,p}{u}_{p}^{l}(\rho ,z)\exp ({ikz})\exp ({il}\phi )\exp (i{\omega }_{1}t)\\ & & \times [1+\exp (-2{il}\phi )\exp (i{\rm{\Delta }}\omega t)]\hat{{\boldsymbol{x}}}.\end{array}\end{eqnarray} \tag{ 161 }$

The corresponding intensity is such that $I\,\propto {[{u}_{p}^{l}(\rho ,z)]}^{2}{\cos }^{2}(l\phi -t{\rm{\Delta }}\omega /2)$, indicating that the pattern rotates at a rate ${{\rm{\Omega }}}_{{rot}}={\rm{\Delta }}\omega /2| l|$. This rotating pattern can be used as an azimuthal optical conveyor belt for trapped atoms as in the experiment by Xu et al [96]. It is important to note that for both bright and dark Ferris wheel lattices, the rotation is not subject to mechanical noise, which means that the pattern would be extremely stable over rotational frequencies ranging from mHz to tens of MHz.

Consider now the interaction of atoms with a Ferris wheel light field. Once more, we concentrate on a two-level atom with a transition frequency ω₀ interacting with a static optical Ferris wheel light field. The interaction is characterised by a Rabi frequency given by:

$\begin{eqnarray}&&{\rm{\Omega }}(\rho ,\phi ,z)=2{{\rm{\Omega }}}_{0}{C}_{| l| p}{u}_{p}^{l}(\rho ,z)\cos (l\phi ).\end{eqnarray} \tag{ 162 }$

Assuming large detuning, the trapping optical dipole potential is given by:

$\begin{eqnarray}\begin{array}{rcl}U(\rho ,\phi ,z) & = & \displaystyle \frac{{\hslash }{{\rm{\Delta }}}_{0}{{\rm{\Omega }}}^{2}(\rho ,\phi ,z)}{4}\\ & = & {\hslash }{{\rm{\Delta }}}_{0}{{\rm{\Omega }}}_{0}^{2}{C}_{| l| ,p}^{2}{({u}_{p}^{l})}^{2}{\cos }^{2}(l\phi ).\end{array}\end{eqnarray} \tag{ 163 }$

Here, Ω₀ is the Rabi frequency associated with a Gaussian beam of the same power and beam waist as the two LG beams involved in setting up the optical Ferris wheel light field. The trapping potential (for Δ₀ < 0) has minima at the radial positions $({\rho }_{0},{\phi }_{| l| },z)=({w}_{0}\sqrt{| l| /2},n\pi /| l| ,0)$ where $n\,=0,1,\,...,2| l| -1$. An atom deeply trapped in such a rotationally symmetric potential is subject to the simple harmonic approximation about the potential minimum and irrespective of the value of l the potential has trapping regions on the common axis of the beams. In the trapping region located on the positive x-axis and for red detuning, the potential has a minimum at $({x}_{0},{y}_{0},{z}_{0})=({w}_{0}\sqrt{| l| /2},0,0)$, so performing a Taylor expansion about this minimum, we find

$\begin{eqnarray}&&U(x,y)={U}_{0}^{| l| }-\displaystyle \frac{1}{2}{k}_{x}{(x-{w}_{0}\sqrt{| l| /2})}^{2}-\displaystyle \frac{1}{2}{k}_{y}{y}^{2}-\displaystyle \frac{1}{2}{k}_{z}{z}^{2},\end{eqnarray} \tag{ 164 }$

where the derived force constants k_x, k_y, k_z and ${U}_{0}^{| l| }$ are given by:

$\begin{eqnarray}\begin{array}{rcl}{k}_{x} & = & \displaystyle \frac{16{\hslash }{{\rm{\Omega }}}_{0}^{2}| l{| }^{| l| }{e}^{-| l| }}{{{\rm{\Delta }}}_{0}{w}_{0}^{2}\pi | l| !},{k}_{y}=\displaystyle \frac{8{\hslash }{{\rm{\Omega }}}_{0}^{2}| l{| }^{| l| }{e}^{-| l| }}{{{\rm{\Delta }}}_{0}{w}_{0}^{2}\pi (| l| -1)!},\\ {k}_{z} & = & \displaystyle \frac{4{\hslash }{{\rm{\Omega }}}_{0}^{2}| l{| }^{| l| }{e}^{-| l| }}{{{\rm{\Delta }}}_{0}{z}_{R}^{2}\pi | l| !},{U}_{0}^{| l| }=\displaystyle \frac{2{\hslash }{{\rm{\Omega }}}_{0}^{2}| l{| }^{| l| }{e}^{-| l| }}{{{\rm{\Delta }}}_{0}\pi | l| !}.\end{array}\end{eqnarray} \tag{ 165 }$

For large values of l, application of the Stirling's approximation gives $l!\approx \sqrt{2\pi | l| }| l{| }^{| l| }\exp (-| l| )$ and we then have

$\begin{eqnarray}\begin{array}{rcl}{k}_{x} & = & \displaystyle \frac{16{\hslash }{{\rm{\Omega }}}_{0}^{2}}{{{\rm{\Delta }}}_{0}{w}_{0}^{2}{\pi }^{3/2}\sqrt{2| l| }},{k}_{y}=\displaystyle \frac{8{\hslash }{{\rm{\Omega }}}_{0}^{2}\sqrt{2| l| }}{{{\rm{\Delta }}}_{0}{w}_{0}^{2}{\pi }^{3/2}},\\ {k}_{z} & = & \displaystyle \frac{4{\hslash }{{\rm{\Omega }}}_{0}^{2}}{{{\rm{\Delta }}}_{0}{z}_{R}^{2}{\pi }^{3/2}\sqrt{2| l| }},{U}_{0}^{| l| }=\displaystyle \frac{2{\hslash }{{\rm{\Omega }}}_{0}^{2}}{{{\rm{\Delta }}}_{0}{\pi }^{3/2}\sqrt{2| l| }},\end{array}\end{eqnarray} \tag{ 166 }$

where we have taken the detuning ${{\rm{\Delta }}}_{0}$ to be negative. The parameters k_x, k_y are larger than k_z since in general z_R ≫ w₀. This means that in-plane trapping is much stronger than axial trapping. A complete three dimensional trapping would then require an additional trapping potential to be set up in the axial direction. In a Ferris wheel scheme, axial trapping can be considerable only for tightly focused beams. Moreover, equation (166) shows an interesting dependence on the index l, such that as l increases the potential ${U}_{0}^{| l| }$ becomes shallower and a similar behaviour is shown by the axial potential. The in-plane potential depth decreases in the x-direction and increases in the y-direction. Furthermore, other features arise at other trapping positions such as the point $({x}_{0},{y}_{0},{z}_{0})=({w}_{0}\sqrt{| l| /2},0,0)$ on the x-axis. At the corresponding trapping point $({x}_{0},{y}_{0},{z}_{0})\,=(0,{w}_{0}\sqrt{| l| /2},0)$ on the y-axis the force constant k_x becomes k_y and vice versa. Since the intensity pattern is rotationally symmetric, the potential at the different trapping sites can be cast in the form

$\begin{eqnarray}&&U(x,y)={U}_{0}^{| l| }-\displaystyle \frac{1}{2}{k}_{x^{\prime} }x{{\prime} }^{2}-\displaystyle \frac{1}{2}{k}_{y^{\prime} }{y}^{{\prime} 2}-\displaystyle \frac{1}{2}{k}_{z}{z}^{2},\end{eqnarray} \tag{ 167 }$

where the primed symbols are given by:

$\begin{eqnarray}&&\begin{array}{l}x^{\prime} =(x-{w}_{0}\sqrt{| l| /2})\cos ({\phi }_{| l| }),\\ y^{\prime} =(y-{w}_{0}\sqrt{| l| /2})\sin ({\phi }_{| l| }),\\ {k}_{x}^{{\prime} }={\cos }^{2}({\phi }_{| l| }){k}_{x}+{\sin }^{2}({\phi }_{| l| }){k}_{y},\\ {k}_{y}^{{\prime} }={\sin }^{2}({\phi }_{| l| }){k}_{x}+{\cos }^{2}({\phi }_{| l| }){k}_{y}.\end{array}\end{eqnarray} \tag{ 168 }$

Thus, we have an anisotropic harmonic oscillator potential, and the harmonic approximation leads to oscillation frequencies given by ${\omega }_{x^{\prime} ,y^{\prime} ,z^{\prime} }=\sqrt{{k}_{x^{\prime} ,y^{\prime} ,z^{\prime} }/M}$ where M is the atomic mass.

When two-level atoms are trapped in a dipole trap the trapping quality depends on two important factors, namely the depth of the optical dipole potential and the photon scattering rate. A numerical estimate of the trapping quality can be made as follows. Consider the D2 ${5}^{2}{S}_{1/2}-{5}^{2}{P}_{3/2}$ transition of ⁸⁵Rb for which the de-excitation rate is Γ/2π = 5.98 MHz, the transition wavelength is λ = 780.9 nm, and the intensity is I_S = 16.4 W m⁻². We assume a ring lattice laser of total power of 0.12W, focused to a beam waist of w₀ = 10 μm and a negative detuning of 1064 nm for trapping. The Rabi frequency associated with each beam is related to the saturation intensity I_S by $I/{I}_{S}=2{{\rm{\Omega }}}_{0}^{2}/{{\rm{\Gamma }}}^{2}$ where $I=P/2{w}_{0}^{2}$, with P the total available laser power (such that P/2 is provided by each of the interfering beams). Also, we have a scattering rate $S\approx \tfrac{U{\rm{\Gamma }}}{{\hslash }{\rm{\Delta }}}$ [163]. With these parameters, it is possible to construct a ring lattice of depth about 25 μK and a scattering rate S ≈ 0.013 s⁻¹. The spatial distribution of the trapping potential is shown in figure 19.

Zoom In Zoom Out Reset image size

The above analysis indicates that the Ferris wheel lattice could provide a potentially dynamic three-dimensional trap for atoms. The trapping is sufficient in the transverse direction, though the potential is shallower in the z-direction. For a lattice that traps in the intensity maxima (red lattice), we could use a tightly focused Ferris field (short Rayleigh range) but there is a trade-off between axial confinement and scattering rate. However, it has been suggested that an additional localisation field can be set up along the z-direction with a hybrid configuration of a Ferris light field and a quadrupole magnetic trap [164, 165]. Alternatively, it is possible to create an axial confinement in a ring lattice by using counter-propagating laser beams forming a standing wave. This leads to the generation of an axially separated stack of lattices similar to the ones in [99]. However, by introducing a frequency shift between the forward and backwards LG beams, the individual ring lattices will not only rotate but also translate along the z-axis.

The twisted optical potential tubes or HOT are formed by the interference of two counter-propagating LG beams, with opposite winding numbers l and the same polarisation, which results in the generation of a three-dimensional twisted standing wave. When a two-level atom interacts with such a light field the optical dipole potential (in the far off-resonance case) is given by:

$\begin{eqnarray}\begin{array}{rcl}U(\rho ,\phi ,z) & = & \displaystyle \frac{{\hslash }{{\rm{\Delta }}}_{0}{{\rm{\Omega }}}^{2}(\rho ,\phi ,z)}{4}\\ & = & {\hslash }{{\rm{\Delta }}}_{0}{{\rm{\Omega }}}_{0}^{2}{C}_{| l| p}^{2}{({u}_{p}^{l})}^{2}{\cos }^{2}(l\phi +{kz}).\end{array}\end{eqnarray} \tag{ 169 }$

This HOT dipole potential is shown in figure 20 for the case where l = 1 and p = 0. This pattern has a left-handed helical shape with a pitch equal to 2πh ($h=| l| /k$) and has two tubes where the maximum intensity is at the geometrical centre of each tube at z = 0 and decreases in the radial direction away from the centre of each tube, and away from the z = 0 plane along each tube.

Zoom In Zoom Out Reset image size

The motion of an atom in such a potential has been analysed in the semi-classical approximation which treats the external variables classically [151]. The atom is considered as subjected to both the optical dipole potential and the gravitational potential and depend on the helix orientation with respect to the lab frame. The equations of motion can be derived using the Lagrangian formalism in cylindrical coordinates, leading to three coupled nonlinear differential equations of the second order for which there is no exact general analytical solution. The atom trajectory can, however, be calculated numerically and analytically in special cases. The numerical solution is based on the fourth order Runge–Kutta method subject to initial conditions for the cold atom inside the HOT. For negative detuning, the atom is attracted towards the high intensity regions.

The initial position of the cold atom can be chosen at the maximum intensity point (which is the minimum value of the dipole potential), which, in cylindrical coordinates, is $({\rho }_{0},{\phi }_{0},{z}_{0})=\left({w}_{0}\sqrt{\tfrac{| l| }{2}},\tfrac{(n-1)\pi }{| l| },0\right)$, where n = 1, 2, ..., 2l is the index of the tubes of the helical optical potential. For example, for l = 1, the helical optical potential has two tubes: the first tube has index n = 1 while the second one has index n = 2, as in figure 20. For the initial velocity, we choose v = (v_r, v_ϕ, v_z) = (5 cm s⁻¹, 5 cm s⁻¹, 0). This is reasonable as the initial velocity of the cold atom should not be less than the recoil velocity v_rec (in order to ensure the validity of the semi-classical approximation) and must be greater than the Doppler velocity v_D (so as to keep the interaction resonant), i.e. v_rec < v₀ < v_D.

For an atom in the region where $z\ll {z}_{R}$, assuming that the small radial 'wiggling' of the motion does not affect the global oscillations in the z-direction, it is possible to obtain an analytical solution of the equations of motion. We have

$\begin{eqnarray}&&\phi (t)=-\displaystyle \frac{\sqrt{4{\dot{\phi }}_{0}^{2}+{\gamma }^{2}}2{\omega }_{s}^{2}}{\sin }({\omega }_{s}t+{\rm{\Theta }})+\displaystyle \frac{\gamma }{2{\omega }_{s}^{2}},\end{eqnarray} \tag{ 170 }$

$\begin{eqnarray}\begin{array}{rcl}z(t) & = & -\displaystyle \frac{h\sqrt{4{\dot{\phi }}_{0}^{2}+{\gamma }^{2}}2{\omega }_{s}^{2}}{\sin }({\omega }_{s}t+{\rm{\Theta }})\\ & & -\displaystyle \frac{h| {\dot{\phi }}_{0}| }{{\omega }_{f}t}\sin ({\omega }_{f}t)-\displaystyle \frac{\gamma h}{2{\omega }_{s}^{2}},\end{array}\end{eqnarray} \tag{ 171 }$

$\begin{eqnarray}&&\rho (t)=-\sqrt{\displaystyle \frac{l}{2}}w(z)+\displaystyle \frac{{\dot{\rho }}_{0}}{{\omega }_{\rho }}\sin ({\omega }_{r}t),\end{eqnarray} \tag{ 172 }$

where ${\dot{\phi }}_{0}$ is the initial angular velocity, ${\omega }_{s}=\tfrac{4{\tan }^{3}({\theta }_{R})}{2| l| \sec ({\theta }_{R})}\sqrt{\tfrac{{E}_{{rec}}\epsilon }{{{\hslash }}^{2}}}$, $\gamma =2{gh}/({r}_{o}^{2}+{h}^{2})$, ${\omega }_{f}=\tfrac{2\sqrt{{E}_{{rec}}\epsilon (1+{\tan }^{2}({\theta }_{R})}}{h}$ and ${\omega }_{\rho }\,=\tfrac{2\lambda \sqrt{{E}_{{rec}}\epsilon }}{\pi {w}_{0}{\hslash }}$, where ${E}_{{rec}}={{\hslash }}^{2}{k}^{2}/2M$ is the recoil energy, ${\theta }_{R}\,=\arctan (h/{\rho }_{0})$ is the pitch angle with $h=| l| /k$ and $\epsilon =-\tfrac{4{\hslash }{{\rm{\Omega }}}_{0}^{2}{C}_{| l| ,p}^{2}}{{{\rm{\Delta }}}_{0}}\tfrac{| l{| }^{| l| }}{| l| !}\exp (-| l| )$ is the depth of the potential at the minimum point.

Figure 21 displays the trajectories, calculated both numerically and analytically, for the following set of parameters. The transition is taken as ${5}^{2}{S}_{1/2}-{5}^{2}{P}_{3/2}$ in ⁸⁵Rb for which λ = 780.2 nm, I_s = 1.64 W m⁻², and Γ/2π = 5.98 MHz. The recoil and Doppler velocities for laser cooling of an ⁸⁵Rb atom are v_rec = 0.602 cm s⁻¹ and v_D = 11.85 cm s⁻¹, respectively [44]. The laser power is P = 80mW, detuning Δ = 2.57 × 10¹³ Hz and the beam waist w₀ = 4 μm [96]. Figures 21(a) and (b) provide an excellent agreement between the numerical and analytical calculations. Both figures show the global oscillatory behaviour of the atom between two turning points along the z-axis and following a helical trajectory due to the helical geometry of the dipole potential.

Zoom In Zoom Out Reset image size

The physical origin of this type of motion lies in the term ${\cos }^{2}(l\phi +{kz})$ which is responsible for the formation of $2l$ potential wells (each well corresponds to a tube in the potential depicted in figure 20 in the (z, ϕ) plane. Each of these wells has energy minima along the line lϕ + kz = (n − 1)π (n is the index of the tube of the potential). This topological feature of the dipole potential drives the atom to oscillate locally about the line lϕ + kz = (n − 1)π, which is the locus of the minima of the potential wells. Due to the coupling of the equations of motion the local oscillations induce an average motion along the line lϕ + kz = (n − 1)π, which guides the atom inside the tube of index n by keeping lϕ + kz = (n − 1)π and a radial distance $\rho ={w}_{z}\sqrt{| l| /2/2}$. This guiding elevates the atom along the z-direction.

Another important parameter of the atomic motion is the beam width w(z) which depends on the position in the z-direction. This dependence, which is shown in figure 22, has normally been ignored in previous works concerning the atomic motion in twisted beams, being considered negligible. However, here it plays an important role. Due to the factor 1/w(z) the depth of the potential is modified in the z-direction. It is straightforward to understand that if the kinetic energy of the atom is less than the depth of the dipole potential on this larger scale, the atom will perform a global oscillation between two turning points. Thus, the motion inside the twisted optical potential tubes is made up of two component motions: a local atomic oscillation in the region 0 < z < λ and 0 < ϕ < 2π and a global oscillation in the region λ < z < z_R. The two types of motion are due to the fact that the dipole potential has two different topological features with different spatial scales.

Zoom In Zoom Out Reset image size

The turning points of the atomic trajectory constitute one of the important features of the atomic motion inside the twisted optical tube. This feature defines the furthest point the atom can be guided along the HOT. Additionally, the turning points are a feature of the atomic gross motion that can be manipulated by changing the characteristic parameters of the LG beams, namely the power, the detuning and the beam waist. In general, the upper turning point of the atom can be higher when the dipole potential is weaker. This can be achieved by making the beam waist larger, the beam power smaller or the detuning larger. On the other hand, the lower turning point of the atom occurs at a lower position and farther than the upper turning point when the dipole potential becomes weaker.

The positions of the turning points are symmetric with respect to the origin when the dipole potential is strong and therefore the influence of gravity is negligible. When the dipole potential is dominant over the gravitational one, the trapped atom will oscillate between the symmetrical positions of the upper and lower turning points, a situation equivalent to an atom reflected between two mirrors of an atomic cavity. When the dipole potential is weaker an asymmetry between the positions of the lower and the upper turning points (where the lower turning point becomes more distant from the origin than the upper turning point) arises since the influence of gravity is then stronger. At the limit of very weak dipole potentials, the motion of the atom is governed almost entirely by gravity and thus has only one turning point. Its initial velocity allows the atom to move up and reach the upper turning point, then the atom starts to fall under the influence of gravity only and follows in its downward motion the helical path determined by the topology of the optical tubes.

A HOT intensity pattern can also be rotated once we arrange for a slight frequency difference between the two interfering LG beams [166]. The most interesting effect on atomic motion is that for specific choices of the values and the sign of the rotating angular frequency the trapped atoms can be dragged in an upward or downward motion. In this case, the action of the rotating HOT on atoms is reminiscent of the operation of the Archimedes screw with which even today in several places of the world people elevate water from rivers and lakes. This Archimedes screw for atoms was proposed and presented in [154] and an experiment on this was reported by Hadad et al [168]. Here, we outline the essential elements of the treatment by Al Rsheed et al [154].

The potential in this scheme is given by

$\begin{eqnarray}\begin{array}{rcl}U(\rho ,\phi ,z,t) & = & \displaystyle \frac{{\hslash }{{\rm{\Omega }}}^{2}(\rho ,\phi )}{4{{\rm{\Delta }}}_{0}}\\ & = & {\hslash }{{\rm{\Omega }}}_{0}^{2}{C}_{| l| p}^{2}{{\rm{\Delta }}}_{0}{u}^{2}(\rho ,z){\cos }^{2}(l\phi +{kz}-{\rm{\Delta }}\omega t/2).\end{array}\end{eqnarray} \tag{ 173 }$

This potential rotates at an angular velocity ${{\rm{\Omega }}}_{R}={{\rm{\Delta }}}_{0}\omega /2| l|$. The study of the atomic motion can be done in the rotating frame of reference, where the potential takes a form similar to the one in equation (169) but for new coordinates $(\rho ^{\prime} =\rho ,\phi ^{\prime} =\phi -{{\rm{\Omega }}}_{R}t,z^{\prime} =z)$. The equations of motion for the new coordinates are as follows:

$\begin{eqnarray}\begin{array}{rcl} & & \ddot{\rho }=-\displaystyle \frac{\partial U}{\partial \rho ^{\prime} }+m\rho ^{\prime} \dot{\phi }{{\prime} }^{2}+2m\rho ^{\prime} {{\rm{\Omega }}}_{R}\dot{\phi }^{\prime} +m\rho ^{\prime} {{\rm{\Omega }}}_{R}^{2},\\ & & m\rho {{\prime} }^{2}\ddot{\phi }^{\prime} =-\displaystyle \frac{\partial U}{\partial \phi ^{\prime} }-2{mr}^{\prime} \dot{\rho }^{\prime} \dot{\phi }^{\prime} -2{mr}^{\prime} \dot{\rho }^{\prime} {{\rm{\Omega }}}_{R},\\ & & \ddot{z}^{\prime} =-\displaystyle \frac{\partial U}{\partial z^{\prime} }.\end{array}\end{eqnarray} \tag{ 174 }$

The third term on the right-hand side of the first equation in (174) and the last term in the second equation are Coriolis forces, while the last term in the first equation is a centrifugal force. These are well known forces that appear because of the rotation of the HOT. The above three equations of motion are coupled nonlinear differential equations of the second order for which there is no exact analytical solution, but a solution can be obtained numerically using the fourth-order Runge–Kutta method.

The motion of an atom that is trapped inside a rotating HOT can be explained in terms of inertial forces. Initially, an atom at rest inside a rotating HOT will experience a centrifugal force ${F}_{r}={{mr}}_{0}{{\rm{\Omega }}}_{R}^{2}$ and will then move along the radial direction. Once in motion it acquires a radial velocity and an associated Coriolis force $F=-2m\dot{\rho }^{\prime} {{\rm{\Omega }}}_{R}$ along the azimuthal direction. This drives the rotating atom in a direction opposite to that of the angular velocity of the HOT. Finally, the atom will have a global motion along the HOT due to the coupling between the motions along the z- and the azimuthal directions. Consequently, the cold atom, which is initially at rest, will acquire a clockwise azimuthal velocity if it is trapped inside a counter-clockwise rotating HOT, while it will acquire a counter-clockwise azimuthal velocity if it is trapped inside a clockwise rotating HOT. In other words, the angular momentum that is transferred from the rotating HOT to the atom is directed opposite to the angular velocity of rotation of the HOT, in agreement with the prediction by Bekshaev et al [166].

We now demonstrate with a specific example that with a judicious choice of parameters the rotating HOT can be used for elevating atoms. To elevate an atom we must obey two conditions: first, the atom must be able to escape from the oscillations along the vertical z-direction and, second, it must simultaneously be kept trapped in the potential tube without escaping along the radial direction. Again the light field is assumed to excite the transition ${5}^{2}{S}_{1/2}-{5}^{2}{P}_{3/2}$, in ⁸⁵Rb for which λ = 780.24 nm, I_s = 16.4 W m⁻², Γ/(2π) = 5.98 MHz, the laser power is P = 80 mW, the detuning is Δ₀ = −2.57 × 10¹³ Hz and the beam waist is w₀ = 5 μm. The initial velocity is taken as (v_x = 5 cm s⁻¹, v_y = 5 cm s⁻¹, v_x = 0).

Figure 23 shows the helical motion of the atom in the rotating frame of reference for two different angular velocities of the HOT: ${{\rm{\Omega }}}_{R}=70\,\mathrm{kHz};$ Ω_R = −70 kHz. In the first case, the atom is performing an oscillation in the upward z-direction and in the second case the atom is performing an oscillation in the downward z-direction. Note, however, that the atom oscillates between two vertical positions and it is not elevated or dragged downwards.

Zoom In Zoom Out Reset image size

Figure 24 displays the time evolution of the vertical displacement of the atom. The atom can be elevated along the z-axis when the HOT rotates at angular velocities greater than 146 krad s⁻¹ counter-clockwise. It can also move downwards when the HOT rotates at angular velocities greater than 150 krad s⁻¹ clockwise. In these cases, the rotating HOT operates as an Archimedes screw for atoms. For other values of the rotational angular velocity, it clearly performs an oscillation along the z-axis, which means that it remains trapped in this direction.

Zoom In Zoom Out Reset image size

The operation of the rotating Ferris wheel as an Archimedes screw for atoms is possible for those angular velocities Ω_R for which the atom during the elevation remains trapped in the radial direction. The angular frequency of the axial oscillations is given by:

$\begin{eqnarray}&&{\omega }_{s}^{{\prime} }\approx \sqrt{{\omega }_{s}^{2}-\displaystyle \frac{\lambda }{4{\pi }^{4}}\displaystyle \frac{| l{| }^{2}}{{w}_{0}^{4}}{{\rm{\Omega }}}_{R}^{2}}.\end{eqnarray} \tag{ 175 }$

The angular frequency ${\omega }_{\rho }^{{\prime} }$ in the radial direction can be computed numerically. Here ω_s is the angular frequency of the axial oscillations in the static HOT case. Figure 25 displays the angular frequencies in the axial and radial directions and from the figure it can be seen that there are values of the HOT angular frequency ${{\rm{\Omega }}}_{R}$ for which the oscillation frequencies along the axial and radial direction, ${\omega }_{s}^{{\prime} }$ and ${\omega }_{\rho }^{{\prime} }$ respectively, become zero. We also see that the atomic radial frequency ${\omega }_{\rho }^{{\prime} }$ is always larger than the atomic global frequency ${\omega }_{s}^{{\prime} }$ and that there are rotation angular velocities for which these frequencies can be zero. In figure 25, these are denoted by ${{\rm{\Omega }}}_{R}^{s}$ and ${{\rm{\Omega }}}_{R}^{\rho }$, respectively. These are important since if the HOT rotates within the following range of angular velocities: $| {{\rm{\Omega }}}_{R}^{s}| \,\lt | {{\rm{\Omega }}}_{R}| \lt | {{\rm{\Omega }}}_{R}^{\rho }|$ then the atom can be elevated to any desired height along the z-axis while simultaneously remaining trapped in the radial direction. The atom can be transported upwards or downwards along the HOT by changing the direction of the rotation of the HOT. The values of ${{\rm{\Omega }}}_{R}^{s}$ and ${{\rm{\Omega }}}_{R}^{\rho }$ can be controlled by changing the dipole potential parameters such as the winding number l, the beam waist w₀, the beam power P, and the detuning Δ.

Zoom In Zoom Out Reset image size

Zoom In Zoom Out Reset image size

It is well established in elementary geometrical optics that when plane wave light is totally internally reflected at the interface between a dielectric material (like a glass prism) and vacuum then evanescent waves that propagate along the boundary are developed. An evanescent wave has an amplitude that decreases with distance away from the boundary so that its intensity falls away with a typical decay length of the order λ/2π where λ is the wavelength. The light fields associated with the evanescent wave have strong intensities and are localised within a small volume. There are thus strong spatial field gradients, which can influence atomic properties.

In addition to optical forces due to evanescent light atoms experience van der Waals attraction to the surface. Atoms can dwell in the vicinity of surfaces either as a result of chemisorption (producing bond formation) or physisorption. Here, we focus on physiosorbed atoms where binding energies are much smaller and the equilibrium distance to the surface is comparatively larger. Physisorbed atoms will respond to surface optical forces because they can represent a displacement from equilibrium, in a planar motion that leaves the distance to the surface unchanged. Undoubtedly, atomic-scale irregularity in the surface itself will modulate the atomic motions we describe, but these will be only minor perturbations to the main effects.

The physics of light at surfaces is in reality a little more involved when one is dealing with a light beam with finite spatial variations in the plane perpendicular to the axis of propagation. The first effect experienced by a light beam, such a Gaussian beam, on reflection is a Goos–Hänschen shift of the plane of incidence [169]. This is a lateral shift, which is distinct from a second, so-called, Imbert–Fedorov shift that is perpendicular to the plane of incidence [170, 171].

The reflection of a beam carrying OAM changes the vortex beam and creates additional modes of higher and lower orders. On reflection, a vortex beam has been shown to experience further shifts associated with the additional angular degrees of freedom. These are the angular Goos–Hänschen and Imbert–Federov shifts, both of which have been analysed and demonstrated [172, 173]. The angular shifts are in fact shifts in wavevector space (see [174, 175]). Merano et al [176] demonstrated both theoretically and experimentally that the spatial and angular shifts are in fact coupled.

However, the intensities of the additional modes responsible for the above shifts are typically small. A reasonable approximation is to ignore such effects and adopt a geometrical optics model in which the light beams are specularly reflected. When the totally internally reflected light is an LG beam that is assumed specularly reflected, the effect, as we explain shortly, is to produce SOVs [6]. These are evanescent waves endowed with angular momentum.

Electromagnetic surface modes can have strong interactions with two-level atoms in the vicinity of the interface, leading to considerable optical trapping potentials, forces and associated torques. We have seen that when the detuning of the laser light is positive, then the dipole force acts to repel the atoms away from the high intensity regions. With the potential barrier so created any incident atoms can be elastically reflected if their kinetic energy is smaller than the maximum of the optical dipole potential, and the system operates as an evanescent mode atom mirror (EWAM) [178]. A laser intensity of 1 W, focused on a surface area of the order of 1 mm², creates an atom mirror on which an atom can be reflected if the component of its velocity normal to the mirror is lower than a few meters per second, which corresponds to kinetic temperatures on the order of few mK [43].

The evanescent wave atom mirror (EWAM) has been used in both the technological and fundamental research of atomic physics for many years [91, 178–205]. The EWAM allows one to reflect ultra-cold atoms [184] in order to probe quantum electrodynamic retardation effects [185]. It is also the basic component for the creation of gravito-optical traps [186, 187]. The first demonstration of an EWAM was in 1987, where it was used to reflect thermal atoms at grazing angles [188]. In 1990, it was used with cold atoms at normal incidence [189]. Since then, EWAM has been extensively studied by several groups, both experimentally [190–195] and theoretically [196–199]. The control of the effective potential barrier has been demonstrated in the case of a two-level atom interacting with surface plasmons [190–192], a dielectric waveguide structure [200] and a metallic film [201] deposited on the surface of the mirror. Multiple bounces of atoms have been observed when evanescent waves were created on concave surfaces [202]. The EWAM has also been used to investigate atom optics in the time domain [203]. One of the most spectacular properties of an EWAM is the quantum state-selective character of the atomic reflections which were demonstrated by Balykin et al [204]. An atom mirror of a three-level atom in the so-called Λ-configuration has also been proposed [205]. Finally, evanescent wave mirrors have been considered for small objects at surfaces [206–208], rather than for near-resonance atoms and molecules.

The intensity of the evanescent wave in an EWAM can be increased by a few orders of magnitude by introducing a thin metal layer into the dielectric-vacuum interface due to the excitation of surface plasmons produced, or by introducing a dielectric film of high refractive index, which essentially produces a dielectric optical fibre for the laser radiation. The repeated reflection of the laser light from the dielectric-vacuum and dielectric–dielectric interfaces substantially increases the intensity of the evanescent wave [209]. When an EWAM with a thin metal film is irradiated by an LG beam we have the so-called surface plasmon optical vortices (SPOVs). These specifically plasmonic modes which are once again features with an intrinsic angular momentum [210, 211].

We now ignore the small beam effects in the forms of the Goos–Hänschen and Imbert–Federov shifts and adopt a geometrical optics model in which the twisted light beams are totally internally reflected at a planar interface between a dielectric material and vacuum. The result of the total internal reflection is the generation of an evanescent light which carries an in-plane distribution of the incident beam and its angular momentum properties. This is a surface optical vortex (SOV) endowed with the OAM of the incident light. Figure 26 schematically represents the process of total internal reflection leading to the generation of surface optical vortices, as surface modes with OAM.

The electric field of an LG beam travelling along the z-axis in a medium of a constant refractive index n, characterised by the integers l and p, frequency ω and axial wavevector k = nk₀ where k₀ = ω/c is the wavevector in vacuum. If the interface with the vacuum occupies the plane z = 0 and the angle of incidence, θ, exceeds the total internal reflection angle, an evanescent mode is created in the vacuum. The main requirements are the applicability of the standard phase matching condition of boundary reflection and the condition that the electric field vector component tangential to the surface is continuous across the boundary. Figure 27 displays the intensity distribution of an SOV due to an internally reflected LG mode on the planar surface of a dielectric. The assumed parameters are given in the caption of this figure.

Zoom In Zoom Out Reset image size

The evanescent light possesses well-defined intensity maxima and minima that can be used to trap adsorbed atoms or to reflect incident atoms with transition frequencies appropriately detuned from the frequency ω of the light. We also see that the spatial profile of the intensity distribution is, in fact, no longer circular, but elliptical, because the light strikes the surface at the angle of incidence θ and the ellipticity increases with increasing θ.

Consider now the case of co-propagating incident beams of opposite winding number l creating an interference of two surface vortices, in a manner similar to that discussed in the previous section which leads to the generation of the optical Ferris wheel [100]. The total electric field in the vacuum region results from the interference of the two evanescent light beams in the azimuthal direction.

Twisted light can also lead to the generation of surface plasmonic optical vortices [212, 213]. An experimentally accessible scenario is the case where a thin metallic film is deposited on the surface of a glass prism and, as before, a LG beam is totally internally reflected on the inner interface as shown in figure 28.

Zoom In Zoom Out Reset image size

The metallic film enhances greatly the evanescent fields and the interaction with a two-level atom in the vicinity is stronger than in the absence of the metallic film, so the corresponding mechanical effects should be larger. From Maxwell's equations the electric field vector components emerge with in-plane polarisation in the three regions of the layered structure as shown in figure 28, namely a dielectric, occupying the region z < −d; a surface film occupying the region −d < z < 0, and the vacuum region occupying the space z > 0. These fields are then subject to boundary and phase-matching conditions. This procedure leads to the evanescent field in the vacuum region.

An atom in the vacuum region with position vector R(t) = (x(t), y(t), z(t)) interacts with the surface plasmon vortex and the interaction is characterised by the Rabi frequency Ω(R(t)) and the phase Θ(R(t)).

To confine the atom to an angular path in the plane parallel to the surface, it is necessary to use two internally reflected incident beams as shown in figure 28. Here, two LG beams, labelled 1 and 2, are incident at angles ϕ₁ and ϕ₂. The two beams, which are assumed as identical, are totally internally reflected and have field components within the film, and surface plasmonic components in the vacuum region. Once the forces acting on the centre of mass of the atom are specified, the motion of the atom in the vicinity of the surface can be determined. The dynamics again follows a Newtonian equation of motion, driven by a sum of the forces delivered by each beam.

To illustrate the results of the theory leading to typical trajectories, we consider a sodium atom in two confocal, counter-propagating LG beams as in figures 29 and 30 assuming the same magnitude of detuning, but one beam has positive detuning and the other negative detuning . It is seen that the trajectories of the sodium atom are very different in the two types of detuning. The confinement regions are now concentric elliptical valleys defined by the intensity distributions, radial confinement leading to vibrational motion in a radial direction and resulting in an overall zigzag trajectory.

Zoom In Zoom Out Reset image size

Zoom In Zoom Out Reset image size

In recent years, there has been a growing interest in extraordinary spin in evanescent light modes. The reference here is to spin directed transverse to the direction of propagation. Much of the work has been done for subwavelength optical fibres (see, for example, [214, 215]), but the phenomenon is general in this setting [216]. Note, however, that the twisting here is not in the phase of the optical field.

Bliokh et al [216] explored the local momentum and spin distributions of evanescent waves. The electric field of their evanescent wave emerges from that of an elliptically-polarised plane wave propagating along the z-axis carrying momentum and spin in the form ${\bf{E}}=A(\hat{{\boldsymbol{x}}}+m\hat{{\boldsymbol{y}}})\exp ({ikz})/\sqrt{(1+| m{| }^{2})}$ where k = ω/c. A rotation of the plane wave field by an imaginary angle iθ leads to the electric field E_evan of an evanescent mode in the half-space x > 0, occupied by vacuum

$\begin{eqnarray}&&{{\bf{E}}}_{{evan}}=\displaystyle \frac{A}{\sqrt{1+| m{| }^{2}}}\left(\hat{{\boldsymbol{x}}}+m\displaystyle \frac{k}{{k}_{z}}\hat{{\boldsymbol{y}}}-i\displaystyle \frac{\kappa }{{k}_{z}}\hat{{\boldsymbol{z}}}\right)\exp ({{ik}}_{z}z-\kappa x),\end{eqnarray} \tag{ 176 }$

where ${k}_{z}=k\cosh \theta \gt k$. In the above, A is the wave amplitude and caret denote unit vectors; m is a complex number that determines the polarisation state. The evanescent mode propagates along the z-axis and its field decays exponentially along the x-axis. It is characterised by the longitudinal wavenumbers k_z and κ, the spatial decay rate. These combine to form the complex wavevector ${\bf{k}}={k}_{z}\hat{{\boldsymbol{z}}}+i\kappa \hat{{\boldsymbol{x}}}$. The calculated density of each of the canonical momentum ${{\boldsymbol{\pi }}}^{0}$, spin momentum ${{\boldsymbol{\pi }}}^{s}$ and SAM s of this evanescent wave are as follows

$\begin{eqnarray}\begin{array}{rcl}{{\boldsymbol{\pi }}}^{0} & = & \displaystyle \frac{w}{\omega }{k}_{z}\hat{{\boldsymbol{z}}};\,\,\,\,\,{{\boldsymbol{\pi }}}^{s}=\displaystyle \frac{w}{\omega }\left(\displaystyle \frac{{\kappa }^{2}}{{k}_{z}}\hat{{\boldsymbol{z}}}+\tilde{\sigma }\displaystyle \frac{\kappa k}{{k}_{z}}\hat{{\boldsymbol{y}}}\right)\\ {\bf{s}} & = & \displaystyle \frac{w}{\omega }\left(\tilde{\sigma }\displaystyle \frac{\kappa }{{k}_{z}}\hat{{\boldsymbol{z}}}+\displaystyle \frac{\kappa }{{k}_{z}}\hat{{\boldsymbol{y}}}\right),\end{array}\end{eqnarray} \tag{ 177 }$

where (in Gaussian units) $w={(8\pi \omega )}^{-1}\omega | A{| }^{2}\exp (-2\kappa x)$ is the spatially-inhomogeneous energy density of the wave and $\tilde{\sigma }=2{\mathfrak{I}}{(m)(1+| m{| }^{2})}^{-1}$ is the helicity (ellipticity of polarisation).

The three expressions presented in equation (177) are the main findings of the work by Bliokh et al Bliokh2014 who emphasised the remarkable peculiarities of the momentum and spin. In particular:

• (1)
  Since k_z > k, the evanescent wave possesses a longitudinal canonical momentum component ${{\boldsymbol{\pi }}}_{z}$ which is greater than the plane wave momentum ${\boldsymbol{\pi }}={wk}/\omega$ that created it.
• (2)
  The group velocity in the evanescent wave is v_gz = ck_z/k > c which confirms that the evanescent wave is superluminal in the direction of propagation.
• (3)
  The theory predicts a super-momentum transfer per photon (i.e. larger than ${\hslash }k$) from the evanescent wave to a dipole particle via the radiation force ${F}_{z}\propto {{\boldsymbol{\pi }}}_{z}^{0}$. This is in conformity with the super-momentum transfer [217] which was observed earlier by Howard and Imbert [218] in the resonant interaction between a moving atom and an evanescent wave.
• (4)
  The results show that there are transverse y-components of the momentum and spin of the evanescent wave propagating in the (x, y) plane. The y-component of the momentum ${{\boldsymbol{\pi }}}_{y}^{0}\propto \tilde{\sigma }w\kappa k/{k}_{z}$, which depends on the helicity $\tilde{\sigma }$. The y-component of the spin is ${s}_{y}\propto w\kappa /{k}_{z}$, which is helicity-independent.

So far we have assumed that the evanescent wave exists in the vicinity of a planar surface. There are other contexts in which evanescent modes feature prominently, most notably in waveguides and in whispering galleries. Here too, it has been found that the polarisation of an allowed evanescent mode exhibits a longitudinal component along the direction of propagation. The work by Junge et al [214] investigated the interaction of a single atom with a whispering gallery mode in a microresonator, taking account of the effects of the non-transversal polarisation of the whispering gallery mode in the interaction.

The development of laser cooling and trapping has been based on the interaction of coherent light with atoms in the electric dipole approximation. Other higher multipolar effects have been ignored since they are considered to be too small [219]. The next in the multipolar order is the electric quadrupole. Electric quadrupole transition rates are typically smaller by a factor $g={({a}_{0}k)}^{2}$ in comparison with electric dipole transitions, where a₀ is the Bohr radius and k is the wavenumber of the ordinary laser light. For processes involving transitions in the optical region, we have g ≈ 10⁻⁶.

Although usually weak, quadrupole effects become important at high intensities or when the light is tightly focused [220], or when the transition in question is driven between two long lived states, in which case the Rabi frequency may be larger than the linewidth, leading to coherent oscillations of the upper state population [221, 222]. Further advancements in optical techniques have allowed more quadrupole transitions to be observed and utilised. In particular, very weak quadrupole transitions have been detected in hydrogen molecules and these have been regarded as of particular interest in probing the atmospheres of various celestial objects [223]. Enhancements of optical absorption of an electric quadrupole transition in caesium atoms interacting with an evanescent field have also been observed [224]. Indeed, quadrupole transitions can be significantly enhanced in the vicinity of material surfaces, including microstructures where enhancements by two orders of magnitude are predicted and have been experimentally observed [225, 226].

Here, we seek to explore what mechanical effects a LG beam would create on a two-level atom when the atomic transition is electric quadrupole allowed. The aim is to find out whether we can achieve mechanical effects of substantial strength when LG beams with high OAM content interact with atoms by quadrupole allowed transitions. Once more, we consider a two-level system with a ground state, denoted $| 1\rangle$ of energy ${{ \mathcal E }}_{1}$ and an excited state $| 2\rangle$ of energy ${{ \mathcal E }}_{2}$, such that the resonance frequency is ${\omega }_{0}=({{ \mathcal E }}_{2}-{{ \mathcal E }}_{1})/{\hslash }$. The atom interacts with an LG beam characterised by the quantum numbers l and p propagating along the z- axis with an axial wave-vector k.

The basic quantum mechanical Hamiltonian formalism in this case follows an analogous initial set of steps to those followed in the case of atoms interacting with light in the electric dipole approximation. The only difference here is that the interaction Hamiltonian is

$\begin{eqnarray}&&{\hat{H}}_{Q}=-\displaystyle \frac{1}{2}{{ex}}_{i}{x}_{j}{{\rm{\nabla }}}_{i}{E}_{j}({\bf{R}}),\end{eqnarray} \tag{ 178 }$

where the Einstein summation convention applies. Here x_i are the components of the internal position vector x = (x, y, z) and ∇_j are components of the gradient operator which act only on the spatial coordinates of the transverse electric field vector E as a function of the centre of mass variable R = (X, Y, Z).

We assume that the LG mode is linearly polarised along the x-direction and that its quantised electric field as a function of the centre of mass coordinate R now expressed in cylindrical coordinates R = (ρ, ϕ, Z) (with $\rho =\sqrt{{X}^{2}+{Y}^{2}}$) has the familiar form of equations (52)–(54). Here, for simplicity, we shall ignore the Gouy phase such that the phase of the LG beam at position R is given by ${{\rm{\Theta }}}_{{klp}}({\bf{R}})={kZ}+l\phi$. With the electric field polarized along the x-direction, the quadrupole interaction Hamiltonian equation (178) now takes the form

$\begin{eqnarray}&&{\hat{H}}_{Q}=-\displaystyle \frac{1}{2}\left\{{\hat{Q}}_{{xx}}\displaystyle \frac{\partial {E}_{x}}{\partial X}+{\hat{Q}}_{{xy}}\displaystyle \frac{\partial {E}_{x}}{\partial Y}+{\hat{Q}}_{{xz}}\displaystyle \frac{\partial {E}_{x}}{\partial Z}\right\},\end{eqnarray} \tag{ 179 }$

where ${\hat{Q}}_{{ij}}={{ex}}_{i}{x}_{j}$ are the elements of the quadrupole tensor operator, which for the two-level atom can be written in terms of ladder operators as

$\begin{eqnarray}&&{\hat{Q}}_{{ij}}={Q}_{{ij}}(\pi +{\pi }^{\dagger }),\end{eqnarray} \tag{ 180 }$

where ${Q}_{{ij}}=\langle 1| {\hat{Q}}_{{ij}}| 2\rangle$ are quadrupole matrix elements between the two atomic levels.

Substituting for the fields, we can write the quantised quadrupole interaction Hamiltonian in the form

$\begin{eqnarray}&&{\hat{H}}_{Q}={\hslash }{\hat{a}}_{{klp}}{{\rm{\Omega }}}_{{klp}}^{Q}({\bf{R}}){e}^{i{{\rm{\Theta }}}_{{klp}}({\bf{R}})}+{\rm{h}}.{\rm{c}}.\end{eqnarray} \tag{ 181 }$

Here, ${{\rm{\Omega }}}_{{klp}}^{Q}({\bf{R}})$ is the complex Rabi frequency defined as follows

$\begin{eqnarray}&&{\hslash }{{\rm{\Omega }}}_{{klp}}^{Q}({\bf{R}})={E}_{k00}{C}_{| l| p}{u}_{p}^{l}({\bf{R}})\{{Q}_{{xx}}{ \mathcal F }+{Q}_{{yx}}{ \mathcal J }+{{ikQ}}_{{zx}}\},\end{eqnarray} \tag{ 182 }$

where, at z = 0,

$\begin{eqnarray}\begin{array}{rcl}{ \mathcal F } & = & \left(\displaystyle \frac{| l| X}{{\rho }^{2}}-\displaystyle \frac{2X}{{w}_{0}^{2}}-\displaystyle \frac{{ilY}}{{\rho }^{2}}+\displaystyle \frac{1}{{L}_{p}^{| l| }}\displaystyle \frac{\partial {L}_{p}^{| l| }}{\partial X}\right);\\ { \mathcal J } & = & \left(\displaystyle \frac{| l| Y}{{\rho }^{2}}-\displaystyle \frac{2Y}{{w}_{0}^{2}}+\displaystyle \frac{{ilX}}{{\rho }^{2}}+\displaystyle \frac{1}{{L}_{p}^{| l| }}\displaystyle \frac{\partial {L}_{p}^{| l| }}{\partial Y}\right).\end{array}\end{eqnarray} \tag{ 183 }$

The form of the interaction Hamiltonian is similar to the one for the electric dipole transitions. The only difference is the way that the Rabi frequency has been defined. The theoretical and experimental justification of this model has been extensively discussed in [227]. With both the phase and the complex Rabi frequency defined, the steady state force on the moving atom due to the LG laser mode is written in a manner similar to case of electric dipole transitions. As in the case of electric dipole transitions, the dissipative force can now be understood as a result of quadrupole absorptions followed by spontaneous emissions of the light by the atom, while the quadrupole force, which is proportional to the gradient of the Rabi frequency, is responsible for confining the atom to the maximal or minimal intensity regions of the field, depending on the detuning Δ_klp. The quadrupole force is derivable from a quadrupole potential

$\begin{eqnarray}&&{U}_{{quad}}({\bf{R}})=\displaystyle \frac{1}{2}{\hslash }{{\rm{\Delta }}}_{{klp}}\mathrm{ln}\left(1+\displaystyle \frac{| {{\rm{\Omega }}}_{{klp}}^{Q}({\bf{R}}){| }^{2}/2}{{{\rm{\Delta }}}_{{klp}}^{2}+{{\rm{\Gamma }}}_{Q}^{2}/4}\right).\end{eqnarray} \tag{ 184 }$

In experimental situations where we have large detuning $| {{\rm{\Delta }}}_{{klp}}| \gg | {{\rm{\Omega }}}^{Q}| ;| {{\rm{\Delta }}}_{{klp}}| \gg {{\rm{\Gamma }}}_{Q}$, the quadrupole potential can be written to a good approximation as

$\begin{eqnarray}&&{U}_{{quad}}({\bf{R}})\approx \displaystyle \frac{{\hslash }}{4{{\rm{\Delta }}}_{{klp}}}| {{\rm{\Omega }}}_{{klp}({\bf{R}})}^{Q}{| }^{2}.\end{eqnarray} \tag{ 185 }$

It is clear from the above expressions that if we wish to compare the corresponding expressions for forces and potentials in the electric dipole and electric quadrupole transitions, we need to investigate the modulus squared Rabi frequency $| {{\rm{\Omega }}}_{{klp}}^{Q}({\bf{R}}){| }^{2}$, which is rather different from the corresponding case in electric dipole transitions.

For illustration, we now consider the case of an LG donut mode of winding number l, but for which p = 0. In this case, the derivative in ${ \mathcal F }$ in equation (183) is equal to zero, since ${L}_{0}^{| l| }$ is a constant for all l. We also assume that the atom is constrained to move in the X–Y plane and the quadrupole transition is such that ${Q}_{{xy}}=0={Q}_{{xz}}$. this can occur for example in a ${Y}_{l=0}^{m=0}\to {Y}_{l=2}^{m=0}$ transition. In this case, the Rabi frequency equation (182) takes the following simpler form,

$\begin{eqnarray}&&{\hslash }{{\rm{\Omega }}}_{{kl}0}^{Q}({\bf{R}})={E}_{k00}{u}_{0}^{l}(\rho ){Q}_{{xx}}\left(\displaystyle \frac{| l| X}{{\rho }^{2}}-\displaystyle \frac{2X}{{w}_{0}^{2}}-\displaystyle \frac{{ilY}}{{\rho }^{2}}\right).\end{eqnarray} \tag{ 186 }$

Expressing lengths in units of w₀, so that $\bar{R}=R/{w}_{0}$, etc, we find for the modulus square of the Rabi frequency entering the dissipative force

$\begin{eqnarray}\begin{array}{rcl}{{\hslash }}^{2}| {{\rm{\Omega }}}_{{kl}0}^{Q}{| }^{2} & = & {E}_{k00}^{2}{C}_{| l| ,p}^{2}| {u}_{0}^{l}{| }^{2}{\left(\displaystyle \frac{{Q}_{{xx}}}{{w}_{0}}\right)}^{2}\\ & & \times \left\{{\left(\displaystyle \frac{| l| \bar{X}}{{\bar{\rho }}^{2}}\right)}^{2}+{\left(\displaystyle \frac{| l| \bar{Y}}{{\bar{\rho }}^{2}}\right)}^{2}+4{\bar{X}}^{2}\left[1-\displaystyle \frac{| l| }{{\bar{\rho }}^{2}}\right]\right\}.\end{array}\end{eqnarray} \tag{ 187 }$

The topology of the Rabi frequency will be imprinted in the topology of the quadrupole potential in the case of large detuning. It is interesting to explore the relevant depth and the spatial structure of the trapping potential given by equation (185) and how these are affected by the choice of the vortex and atomic parameters. To be specific, we consider Cs as an atom recently explored for its quadrupolar transition ${6}^{2}{S}_{1/2}\to {5}^{2}{D}_{5/2}$, specifying the de-excitation rate Γ_Q and a quadrupolar matrix element Q_xx. The optical vortex is such that the amplitude E₀₀₀ is related to the intensity by $I={\epsilon }_{0}{{cE}}_{k00}^{2}/2$. We also need a suitable value for the detuning Δ and, since we wish to maximise the quadrupolar effects we take a large value of winding number l. The parameters are ${w}_{0}=10\,\mu {\rm{m}};\,\lambda =675\,\mathrm{nm};$ ${Q}_{{xx}}\approx 10{{ea}}_{B}^{2};\,\,{{\rm{\Gamma }}}_{Q}=7.8\,\times {10}^{5}\,{{\rm{s}}}^{-1};$ and ${\rm{\Delta }}={10}^{2}{{\rm{\Gamma }}}_{Q};$ $P=1{\rm{W}};\,I=3.18\times {10}^{9}\,{\rm{W}}\ {{\rm{m}}}^{-2}.$ It is also convenient to define a scaling parameter Ω₀ as follows

$\begin{eqnarray}&&{{\rm{\Omega }}}_{0}=\displaystyle \frac{1}{{\hslash }}{\left(\displaystyle \frac{2I}{{\epsilon }_{0}c}\right)}^{1/2}\displaystyle \frac{{Q}_{{xx}}}{{w}_{0}}=136{{\rm{\Gamma }}}_{Q},\end{eqnarray} \tag{ 188 }$

where the last equality emerges on substituting the relevant parameters defined above. Figure 31 displays the quadrupole potential and the corresponding contour plots in two different cases namely when l = 3 and l = 300. Experimentally, winding numbers as large as l = 300 can be achieved, as emphasised in [228]. The trapping potentials are given in absolute temperature units. It is obvious that the increase of the winding number l gives a deeper trapping potential. From the contour plots, we also see a different spatial structure of the potential. As l increases, we obtain two crescent-like trapping regions. This spatial structure can be explained by an analysis of equation (187) on substituting for $| {u}_{p}^{| l| }{| }^{2}$, expressed in terms of the dimensionless variables. In the large l case, we have a distribution with two regions of variation and there are high symmetry points. To identify the dependence on l, we consider the points $(\bar{X},\bar{Y})=(0,\pm 1)$, the expression between the curly brackets in $| {{\rm{\Omega }}}_{{kl}0}^{Q}{| }^{2}$ becomes equal to l², while at the points $(\bar{X},\bar{Y})=(\pm 1,0)$ the curly bracket reduces to ${(l-2)}^{2}$, both of these observations effectively scale as l² for large l. We have also verified that the maxima and minima of $| {{\rm{\Omega }}}_{{kl}0}^{Q}{| }^{2}$ actually occur at the following $(\bar{X},\bar{Y})$ points

$\begin{eqnarray}&&\begin{array}{l}(\bar{X},\bar{Y})=(\pm \sqrt{| l| /2},0)\,\,(\mathrm{minimum});\\ (\bar{X},\bar{Y})=(0,\pm \sqrt{[| l| -1]/2)}\,\,(\mathrm{maximum}).\end{array}\end{eqnarray} \tag{ 189 }$

It is seen that the positions where the Rabi frequency maximises are different from those in the case where we have an electric dipole transition. In this case, the Rabi frequency maximises at points where $\bar{R}=\sqrt{| l| /2}$. The reason is that the strength of the electric quadrupole interaction depends on the gradient of the electric field. Thus, such an interaction can be maximum even at points where the electric field and thus the intensity are zero [229]. This counter-intuitive observation has been demonstrated in an experiment where a single ion was positioned at different locations inside an optical cavity [230].

Zoom In Zoom Out Reset image size

The depth of the quadrupole trap is sufficiently large to lead to the trapping of atoms. Moreover, as our analysis has shown the photon scattering rate is very low, so ensuring long trapping lifetimes. This means that the interaction of LG light with an atom in a quadrupole-allowed transition can lead to significant mechanical effects on the atoms. The facility to generate LG light in the laboratory with large values of l [228] indicates that the quadrupolar mechanical effects should be amenable to experimental verification.

It seems reasonable to suggest that a further enhancement of quadrupolar vortex interactions could be achieved by placing the atoms near the surface of plasmonic structures and arranging the generation of surface plasmonic modes endowed with the vortex properties. Dipole allowed transitions are subject to strong enhancement under these conditions.

The mechanical effects of the Gouy and curvature phase terms on the gross motion of two-level atoms have been explored by Lembessis and Babiker [239]. The outlines of their arguments are as follows. In the paraxial approximation the electric field associated with a LG mode, of wavelength $\lambda =2\pi /k$ propagating in the z-direction and polarised in the x−direction is given by equations (52)–(54). In equation (54), the third term is identified as the Gouy phase term, namely

$\begin{eqnarray}&&{{\rm{\Theta }}}_{{Gouy}}=-(2p+| l| +1){\tan }^{-1}(z/{z}_{R}),\end{eqnarray} \tag{ 190 }$

and the curvature term is the last term, namely

$\begin{eqnarray}&&{{\rm{\Theta }}}_{{curve}}=\displaystyle \frac{k{\rho }^{2}z}{2({z}^{2}+{z}_{R}^{2})}.\end{eqnarray} \tag{ 191 }$

The beam is characterised by a wavevector given by ${\bf{K}}={\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{lp}}$ where the gradient of the phase function is given by:

$\begin{eqnarray}\begin{array}{rcl}{\bf{K}} & = & {\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{lp}}=k\left[1-(2p+| l| +1)\displaystyle \frac{{z}_{R}}{k({z}^{2}+{z}_{R}^{2})}\right.\\ & & \left.+\displaystyle \frac{{\rho }^{2}({z}_{R}^{2}-{z}^{2})}{{({z}^{2}+{z}_{R}^{2})}^{2}}\right]\widehat{{\bf{z}}}+\displaystyle \frac{l}{\rho }\hat{{\boldsymbol{\phi }}}+\displaystyle \frac{{kz}\rho }{({z}^{2}+{z}_{R}^{2})}\hat{{\bf{r}}}.\end{array}\end{eqnarray} \tag{ 192 }$

In fact not just the wavevector, but also the Poynting vector expressions are significantly modified compared with the expressions that are valid for low values of the indices l and p provided that we work with parameters that can make the contributions from the Gouy phase equation (190) and the curvature phase equation (191) of appreciable sizes. This conclusion, whilst it introduces additional complexity, suggests that when experimental results are assessed, it may be important to consider such effects if simpler formulations give imprecise agreement.

Recall that radiation pressure gives rise to two distinct forces, namely the dissipative force and the dipole force. In the saturation limit where ${{\rm{\Omega }}}_{{lp}}\gg {\rm{\Delta }},\,{\rm{\Gamma }}$, the dissipative force can be approximated to

$\begin{eqnarray}&&\langle {{\bf{F}}}_{\mathrm{diss}}{\rangle }_{{lp}}\approx \displaystyle \frac{1}{2}{\hslash }{\rm{\Gamma }}{\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{lp}}=\displaystyle \frac{1}{2}{\hslash }{\rm{\Gamma }}{\bf{K}}.\end{eqnarray} \tag{ 193 }$

Consider the situation in which the atoms move near the focus plane of the LG mode such that z ≪ z_R. In this case, the wave-vector of the beam K takes the following effective form

$\begin{eqnarray}&&{\bf{K}}={k}_{{eff}}\hat{{\boldsymbol{z}}}\approx k\left[1-\displaystyle \frac{(2p+| l| +1)}{{{kz}}_{R}}+\displaystyle \frac{{\rho }^{2}}{2{z}_{R}^{2}}\right]\hat{{\boldsymbol{z}}}.\end{eqnarray} \tag{ 194 }$

When the gradient terms originating from the Gouy phase and the curvature phase terms are considerable in size, they amount to an effective axial wavevector denoted by k_eff, so that the phase gradient in the vicinity of the focus plane can be written as

$\begin{eqnarray}&&{\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{pl}}\approx {k}_{{\text{}}{eff}}\widehat{{\bf{z}}}+\displaystyle \frac{l}{\rho }\hat{{\boldsymbol{\phi }}}.\end{eqnarray} \tag{ 195 }$

The above relations show clearly that the axial wavevector is modified from k to k_eff. In the specific case p = 0 and making use of the relation ${z}_{R}=\pi {w}_{0}^{2}/\lambda$ we find that the winding number l should be close to (kw₀)² and since, kw₀ ≫ 1, only LG beams with large value of l could exhibit a non-negligible effect, i.e. such that k_eff differs significantly from k.

To understand better the relevant size of the modifications we consider the following numerical estimations. Consider an LG mode of wavelength λ = 2π/k = 852.35 nm, with azimuthal and radial indices l = 300, p = 3, respectively. We focus on four different cases of beam waist with respective values ${w}_{0}=3\lambda ,5\lambda ,10\lambda$ and 20λ , and seek to explore how the effective wavevector k_eff changes with the radial position r near the focus plane, i.e. in the region at z ≈ 0 of the beam. The plot of k_eff as a function of radius ρ, scaled in beam waist units, is shown in figure 32 in which we clearly see that k_eff becomes considerably different from that of k as the beam waist decreases in value. The effect is even more interesting since as we also see for w₀ = 3λ the effective axial wavevector k_eff takes negative values at certain radial positions: the interpretation is that locally the atom 'sees' a beam travelling in the opposite direction. We must, however, be careful in interpreting this scenario since, as has recently been pointed out, when the focusing is very tight the generated LG beam is not a pure state as we have the production of modes with higher and lower winding numbers due to a small field component in the propagation direction, so the above ideal picture does not precisely apply [157, 240].

Zoom In Zoom Out Reset image size

A direct consequence of the modification of the axial wavevector is that the dissipative force on a two-level atom is also modified. In the saturation limit, this force is now given by:

$\begin{eqnarray}&&\langle {{\bf{F}}}_{\mathrm{diss}}{\rangle }_{{lp}}=\displaystyle \frac{1}{2}{\hslash }{\rm{\Gamma }}\left\{{k}_{{\text{}}{eff}}\widehat{{\bf{z}}}+\displaystyle \frac{l}{\rho }\hat{{\boldsymbol{\phi }}}\right\}.\end{eqnarray} \tag{ 196 }$

Note that the axial $(\hat{{\bf{z}}})$ dissipative force, which in the absence of the anomalous Gouy and curvature phases is known to be given simply by $\langle {{\bf{F}}}_{\mathrm{diss}}{\rangle }_{{lp}}=(1/2){\hslash }{\rm{\Gamma }}k\widehat{{\bf{z}}}$, is now modified by the inclusion of the additional phase terms By contrast, these phase anomalies have no effect on the azimuthal $\hat{{\boldsymbol{\phi }}}$ force component. The analysis shows that, since the effective wavevector is nullified on critical radial distances and changes its sign from negative to positive around them, there may be novel ways to handle atoms via LG light beams. A light beam can decelerate the atomic motion even in the case where it propagates in the same direction with the atom.

The mechanical effects of light on atom are very sensitive to the Doppler shift experienced by a moving atom. If the atom has a velocity V then the Doppler shift is given by ${\delta }_{D}=\{{\boldsymbol{\nabla }}{{\rm{\Theta }}}_{{lp}}\}\cdot {\bf{V}}$. This topic has been investigated analytically by Allen, Babiker and Power, [130], so it now seems clear (in view of the discussion in section 8.1) that the Doppler shift too is subject to modifications due to Gouy and curvature phases for highly twisted light and there are also consequences in the context of the dynamics of the optical molasses in such LG beams [241].

The creation of a fork-like mask is achieved when we interfere a LG beam with a Gaussian (G) beam. The propagation direction of the G wave is considered to be slightly tilted at an angle β with respect to z-axis. Both beams are assumed to be polarised along the y-direction. The electric field of the G beam is given by

$\begin{eqnarray}&&{{\bf{E}}}_{G}(\rho ,z)=\hat{{\boldsymbol{y}}}{{ \mathcal E }}_{G}(\rho ,z){e}^{-{ik}\tfrac{{\rho }^{2}}{2R(z)}}{e}^{i\zeta (z)}{e}^{{{ik}}_{x}x}{e}^{{ikz}},\end{eqnarray} \tag{ 197 }$

where ${{ \mathcal E }}_{G}(\rho ,z)=\tfrac{{E}_{G,0}}{\sqrt{(1+{(z/{z}_{R})}^{2}}}{e}^{-{\rho }^{2}/{w}^{2}(z)}$ with E_G,0 being the Gaussian wave amplitude. The total electric field of this configuration is:

$\begin{eqnarray}&&{\bf{E}}(x,y,z)=\hat{{\boldsymbol{y}}}{ \mathcal E }(x,y,z)/2,\end{eqnarray} \tag{ 198 }$

where ${ \mathcal E }(x,y,z)$ is the field distribution given by the sum

$\begin{eqnarray}&&{ \mathcal E }(x,y,z)={{ \mathcal E }}_{G}(\rho ,z){e}^{i({k}_{x}x+{kz}}+{{ \mathcal E }}_{{LG}}f(\rho ,z){e}^{-{il}\phi }{e}^{{ikz}},\end{eqnarray} \tag{ 199 }$

where ${{ \mathcal E }}_{{\rm{LG}}}={{ \mathcal E }}_{00}(2/\pi {(1+| l| !)}^{1/2}$ with l the winding number of the LG mode and the function $f(\rho ,z)\,={[1+{z}^{2}/{z}_{R}^{2}]}^{-1/2}{\left(\tfrac{\rho \sqrt{2}}{w(z)}\right)}^{| l| }{e}^{-{\rho }^{2}/w{(z)}^{2}}$. The above field is characterised by an intensity I, which is proportional to $| { \mathcal E }(x,y,z){| }^{2}$. Explicitly, at z = 0, we have:

$\begin{eqnarray}\begin{array}{rcl}| { \mathcal E }(x,y){| }^{2} & = & {{ \mathcal E }}_{G}^{2}+{{ \mathcal E }}_{{LG}}^{2}{f}^{2}(\rho )\\ & & +2{{ \mathcal E }}_{G}{{ \mathcal E }}_{{LG}}f(\rho )\cos ({k}_{x}r\cos \phi +l\phi ).\end{array}\end{eqnarray} \tag{ 200 }$

It is instructive at this stage to consider the following numerical example. We assume that the LG beam has a beam waist w_LG,0 = 15 μm. The winding number of the LG beam is taken as l = 1 and its power is 81 μW. Both beams have wavelength λ = 589.16 nm. This is the wavelength which can excite the ${3}^{2}{S}_{1/2}-{3}^{2}{P}_{3/2}$ transition in a Na atom which has a saturation intensity I_S = 64 W m⁻². The Gaussian beam has a beam waist equal to w_G,0 = 200 μm and its power is 8.2 mW. The G beam propagation direction is tilted at an angle equal β = 5⁰ with respect to the LG beam propagation direction. The spatial distribution of the total intensity is displayed in figure 33.

Zoom In Zoom Out Reset image size

A two-level atom interacting with the above field has a Rabi frequency ${{\rm{\Omega }}}^{2}(\rho ,\phi )\propto I\propto | { \mathcal E }(x,y,z){| }^{2}$, which at z = 0 is given by,

$\begin{eqnarray}\begin{array}{rcl}{{\rm{\Omega }}}^{2}(\rho ,\phi ) & = & {{\rm{\Omega }}}_{G}^{2}(\rho )+{{\rm{\Omega }}}_{{LG}}^{2}{f}^{2}(\rho ,z)\\ & & +2{{\rm{\Omega }}}_{G}(\rho ){{\rm{\Omega }}}_{{LG}}f(\rho )\cos ({k}_{x}\rho \cos \phi +l\phi ),\end{array}\end{eqnarray} \tag{ 201 }$

where ${{\rm{\Omega }}}_{G}(\rho )={{\rm{\Omega }}}_{G,0}\exp (-{\rho }^{2}/{w}_{0}^{2})$ and ${{\rm{\Omega }}}_{{\rm{LG}}}(\rho )={{\rm{\Omega }}}_{{\rm{LG}},0}f(\rho )$. On interacting with the mask field, the atom experiences an optical dipole potential. In the case of far detuning such that Ω/Δ ≪ 1, we have for the dipole potential

$\begin{eqnarray}&&U(\rho ,\phi )=\displaystyle \frac{{\hslash }{{\rm{\Omega }}}^{2}(\rho ,\phi )}{4{\rm{\Delta }}}.\end{eqnarray} \tag{ 202 }$

The dipole potential acts on the atom in its ground state and results in the diffraction of the atom over a short interaction time τ. We assume that the atom enters the potential at the time t = −τ and its state function at that instant is Ψ(ρ, ϕ, −τ). After the diffraction process, the atomic state function is at time t = 0 and is given by

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,0)={\rm{\Psi }}(\rho ,\phi ,-\tau ){e}^{-{iU}\tau /{\hslash }}.\end{eqnarray} \tag{ 203 }$

On substituting for U from equation (202), we have

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,0)={\rm{\Psi }}(\rho ,\phi ,-\tau )\left(-\displaystyle \frac{i\tau {{\rm{\Omega }}}^{2}(\rho ,\phi )}{4{\rm{\Delta }}}\right).\end{eqnarray} \tag{ 204 }$

The physical interpretation of the above expression is that the diffraction process through the optical potential over the short period of time τ is in the form of a phase imprint on the initial wave function [256]. This is the basic principle of vortex sorting in BECs. Substituting for Ω from equation (201), we have

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,0)={\rm{\Psi }}(\rho ,\phi ,-\tau ){e}^{-{iA}\tau }{e}^{-{iB}\tau }{e}^{-{iC}\tau \cos ({k}_{x}x+l\phi )},\end{eqnarray} \tag{ 205 }$

where A, B and C are functions of ρ only and are defined by

$\begin{eqnarray}\begin{array}{rcl}A(\rho ) & = & \displaystyle \frac{{{\rm{\Omega }}}_{G}^{2}(\rho )}{4{\rm{\Delta }}};\,\,\,B(\rho )=\displaystyle \frac{{{\rm{\Omega }}}_{{LG}}^{2}(\rho ){f}^{2}(\rho )}{4{\rm{\Delta }}};\\ C(\rho ) & = & \displaystyle \frac{{{\rm{\Omega }}}_{{LG}}f(\rho ){{\rm{\Omega }}}_{G}^{2}(\rho )}{2{\rm{\Delta }}}.\end{array}\end{eqnarray} \tag{ 206 }$

The last exponential factor involving dependence on k_x and ϕ can be expressed as a sum over Bessel functions J_n(z) using the Jacobi–Anger identity, namely

$\begin{eqnarray}&&{e}^{{iz}\cos \theta }=\displaystyle \sum _{-\infty }^{\infty }{i}^{n}{J}_{n}(z){e}^{{in}\theta }.\end{eqnarray} \tag{ 207 }$

We obtain

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,0)={\rm{\Psi }}(\rho ,\phi ,-\tau ){e}^{-{iA}\tau }{e}^{-{iB}\tau }\displaystyle \sum _{-\infty }^{\infty }{i}^{n}{J}_{n}(C\tau ){e}^{{inl}\phi }{e}^{{{ink}}_{x}x}.\end{eqnarray} \tag{ 208 }$

The initial state function of the atoms prior to entering the interaction region (i.e. at time t = −τ) is best discussed with reference to a practical scenario involving a cold atomic wavepacket. Such a wavepacket is considered to have a transverse Gaussian profile with a typical cross-section of dimensions of the order of tens of microns. Thus, we can write

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,z,-\tau )=N\exp \left(-\displaystyle \frac{4\mathrm{ln}2}{{\sigma }_{\perp }^{2}}{\rho }^{2}\right){e}^{-{{iK}}_{z}^{{dB}}z},\end{eqnarray} \tag{ 209 }$

where ${\sigma }_{\perp }$ is the transverse size of the atomic wavepacket, K^dB_z is the atomic wavevector along the z-direction and N is a normalisation factor.

Equation (208) shows that the atomic state function is made up of a series of atom vortex states each labelled by the index n = 0, ±1, ±2, .... and each is endowed with angular momentum nlℏ propagating at an angle θ_n relative to the z-axis given by

$\begin{eqnarray}&&{\theta }_{n}={\sin }^{-1}\left(\displaystyle \frac{{{nk}}_{x}}{{K}_{z}^{{dB}}}\right)\approx n{\sin }^{-1}\left(\displaystyle \frac{{k}_{x}}{{K}_{z}^{{dB}}}\right).\end{eqnarray} \tag{ 210 }$

The central component is such that n = 0, which is an Airy-type state function and carries no angular momentum. Explicitly, we have

$\begin{eqnarray}&&{{\rm{\Psi }}}_{0}=N\exp \left(-\displaystyle \frac{4\mathrm{ln}2}{{\sigma }_{\perp }^{2}}{\rho }^{2}\right){e}^{-{iA}\tau }{e}^{-{iB}\tau }{J}_{0}(C\tau ){e}^{-{{iK}}_{z}^{{dB}}z}\end{eqnarray} \tag{ 211 }$

while the first order states are those for which n = ±1

$\begin{eqnarray}&&{{\rm{\Psi }}}_{\pm 1}={{Ni}}^{\pm 1}\exp \left(-\displaystyle \frac{4\mathrm{ln}2}{{\sigma }_{\perp }^{2}}{\rho }^{2}\right){e}^{-{iA}\tau }{e}^{-{iB}\tau }{J}_{\pm 1}(C\tau ){e}^{\pm {il}\phi }{e}^{-{{iK}}_{z}^{{dB}}z}.\end{eqnarray} \tag{ 212 }$

These state functions correspond to atomic beams carrying orbital angular momenta ±lℏ. Note that lℏ is the OAM of the LG beam which was required to construct the fork pattern. This angular momentum is seen here as having been transferred to the atomic beams to the lowest diffraction order. The situation is depicted schematically in figure 34. For practical purposes, it is desirable to be able to ensure that the atomic vortex beams are well separated, with minimum or no overlap. This requirement clearly depends on the parameters used to generate the diffraction pattern and the amplitude of a given component depends on the initial state and the corresponding Bessel function. The process described above is in fact a Raman-Nath diffraction and there are certain criteria in which the Raman-Nath regime applies, namely (i) that the width of the initial atomic beam must be large compared with the spatial extent of the diffracting potential and (ii) that the transverse kinetic energy of the atoms as they enter the diffraction region should be smaller than the maximum energy of the atom-light field interaction.

Zoom In Zoom Out Reset image size

The creation of a spiral mask is achieved when a Gaussian beam is passed through a thin lens of width d, refractive index n and focal length f. Then the electric field of the Gaussian beam is given by:

$\begin{eqnarray}\begin{array}{rcl}{ \mathcal E }(\rho ,z) & = & \hat{{\boldsymbol{y}}}{{ \mathcal E }}_{G}(\rho ,z){e}^{-{iknd}}{e}^{{ik}{\rho }^{2}/2f}\\ & & \times {e}^{{ikz}{\rho }^{2}/({z}^{2}+{z}_{R}^{2})}{e}^{-i{\tan }^{-1}(z/{z}_{R})}{e}^{{ikz}}/2.\end{array}\end{eqnarray} \tag{ 213 }$

On interference of this beam with a LG donut beam l, p(=0), we have for the total electric field:

$\begin{eqnarray}&&\begin{array}{l}{{ \mathcal E }}_{{tot}}(\rho ,z)=\hat{{\boldsymbol{y}}}\displaystyle \frac{1}{2}{e}^{{ikz}}{e}^{{ik}{\rho }^{2}/2({z}^{2}+{z}_{R}^{2})}{e}^{-i{\tan }^{-1}(z/{z}_{R})}{e}^{{ikz}{\rho }^{2}/({z}^{2}+{z}_{R}^{2})}\\ \times \,[{{ \mathcal E }}_{G}(\rho ,z){e}^{i(-{knd}+k{\rho }^{2}/2f)}+{{ \mathcal E }}_{{LG}}f(\rho ,z){e}^{i(l\phi -| l| {\tan }^{-1}(z/{z}_{R})}].\end{array}\end{eqnarray} \tag{ 214 }$

This field has an intensity proportional to the $| {{ \mathcal E }}_{{tot}}(\rho ,z){| }^{2}$, which at z = 0 is given by:

$\begin{eqnarray}\begin{array}{rcl}| {{ \mathcal E }}_{{tot}}(\rho ){| }^{2} & = & | {{ \mathcal E }}_{{LG}}(\rho )f(\rho ){| }^{2}+| {{ \mathcal E }}_{G}(\rho ){| }^{2}\\ & & +2{{ \mathcal E }}_{{LG}}f(\rho ){{ \mathcal E }}_{G}(\rho )\cos (l\phi +{knd}-k{\rho }^{2}/2f).\end{array}\end{eqnarray} \tag{ 215 }$

The intensity of this light field has a spiral profile in the transverse plane, as illustrated by the following numerical example. We assume that both beams have equal beam waists w₀ = 15 μm, equal wavelengths λ = 1 083.33 nm. The Gaussian beam has a power of 0.3 μW while the LG beam has a power 1.4 μW. The wavelength corresponds to the transition ${2}^{3}{S}_{1}-{2}^{3}{P}_{2}$ in the ⁴He atom. The winding number of the LG beam is l = 2, while the lens is characterised by the following parameter values: d = 0.5 mm and f = 100 μm. The intensity of the total light field with the characteristic spiral transverse profile is presented in figure 35.

Zoom In Zoom Out Reset image size

The atom interacting with the above field experiences a potential given in equation (202) with a Rabi frequency Ω(ρ, ϕ) whose square modulus is given by

$\begin{eqnarray}\begin{array}{rcl}| {\rm{\Omega }}(\rho ,\phi ){| }^{2} & = & | {{\rm{\Omega }}}_{{LG}}(\rho ){| }^{2}+| {{\rm{\Omega }}}_{G}(\rho ){| }^{2}\\ & & +2{{\rm{\Omega }}}_{{LG}}(\rho ){{\rm{\Omega }}}_{G}(\rho )\cos (l\phi +{knd}-k{\rho }^{2}/2f),\end{array}\end{eqnarray} \tag{ 216 }$

where ${{\rm{\Omega }}}_{G}(\rho )={{\rm{\Omega }}}_{G,0}\exp (-{\rho }^{2}/{w}_{0}^{2})$ and Ω_LG(ρ) = Ω_LG,0f(ρ).

In the scheme shown in figure 36, a BEC which has been released from a trap moving in free space is directed towards the light mask and made to interact with it for a short time interval and gets diffracted by the optical dipole potential. We assume that the BEC initially occupying the ground state of the trap and immediately after its release enters the interaction region at time t = −τ. To a good approximation, the condensate wave-function can be considered as a Gaussian one as described in equation (209).

Zoom In Zoom Out Reset image size

After the diffraction, the atomic wave function acquires a phase imprint and so has the form,

$\begin{eqnarray}&&{\rm{\Psi }}(\rho ,\phi ,0)={\rm{\Psi }}(\rho ,\phi ,-\tau )\exp \left(-\displaystyle \frac{2i\tau {{\rm{\Omega }}}^{2}(\rho ,\phi )}{{{\rm{\Delta }}}_{1}}\right),\end{eqnarray} \tag{ 217 }$

where Δ₁ = ω_L1 − ω₀. Using equation (216) and the Jacobi–Anger equation, this becomes:

$\begin{eqnarray}\begin{array}{rcl}{\rm{\Psi }}(\rho ,\phi ,0) & = & {\rm{\Psi }}(\rho ,\phi ,-\tau ){e}^{-{iB}\tau }{e}^{-{iC}\tau }\\ & & \times \displaystyle \sum _{-\infty }^{\infty }{i}^{m}{J}_{m}(E\tau ){e}^{{iml}\phi }{e}^{{imknd}}{e}^{-{ima}{\rho }^{2}},\end{array}\end{eqnarray} \tag{ 218 }$

where $a=k/2f,B(\rho )={{\rm{\Omega }}}_{{LG}}^{2}(\rho )/4{{\rm{\Delta }}}_{1},C(\rho )={{\rm{\Omega }}}_{G}^{2}(\rho )/4{{\rm{\Delta }}}_{1}$ and $E(\rho )={{\rm{\Omega }}}_{G}(\rho ){{\rm{\Omega }}}_{{LG}}(\rho )/2{{\rm{\Delta }}}_{1}$. The diffraction pattern consists of AV beams, with a quantised angular momentum along z-direction equal to mℏ. These AV beams are focused at the points mπ/λa = mf along the z-axis. This is a rather simpler diffraction pattern than that in the case of the fork-like mask described in the previous subsection. Here, the different AV beams are in focus in different planes along the propagation direction, while in the fork-like mask case they propagate in different directions. Equation (218) indicates that the diffraction pattern is made up of a term Ψ₀ with no OAM content and different diffraction orders of opposite winding numbers Ψ_±m which means there is a quantized OAM mℏ along the propagation axis.

$\begin{eqnarray}\begin{array}{rcl} & & {{\rm{\Psi }}}_{0}\propto {e}^{-{iB}\tau }{e}^{-{iC}\tau }{\rm{\Psi }}(\rho ,\phi ,-\tau ){J}_{0}(E\tau ),\\ & & {{\rm{\Psi }}}_{\pm m}\propto -{{ie}}^{-{iB}\tau }{e}^{-{iC}\tau }{\rm{\Psi }}(\rho ,\phi ,-\tau )\\ & & \times {J}_{\pm m}(E\tau ){e}^{\pm {iml}\phi }{e}^{\pm {imknd}}{e}^{\mp {ima}{\rho }^{2}}.\end{array}\end{eqnarray} \tag{ 219 }$

The two AVs with opposite angular momenta $\mp m{\hslash }$ are defocused over mf and $-{mf}$ respectively.

The spiral diffraction scheme could be exploited for the generation of an atom Ferris wheel beam [255]. This is the atomic counterpart of the light Ferris wheel beam because the probability distribution at a plane transverse to the atomic propagation direction has a characteristic petal-like structure similar to the optical Ferris wheel transverse intensity pattern [100]. The fact that the generated AVBs are all focused on a straight line is the main advantage of the spiral diffraction scheme. If we can shift the focus of one AVB with winding number $-m$, without disturbing the focus of all the other AVBs, then we can make it interfere with the AVB of winding number +m and generate the atom Ferris wheel. This can be achieved by the interaction of a suitably tailored vortex light field which can cause a second phase imprint on the AVB with winding number $-m$. This imprint does not act on the other AVBs if we apply a spatially inhomogeneous magnetic field that makes all the rest of the AVBs very far detuned from the light field, so the associated phase shift is negligible.

The realization of atom vortex beams would open up a new area of atom optics in which atoms carrying OAM interact with each other, or with other forms of matter. Further theoretical studies and various applications should be anticipated including atom interferometry; the functioning of LG light mask as a dispersive prism for de Broglie wavelengths; the encoding and processing of quantum information in atom vortex states entangled with other states such as motional or spin atomic states; the interference of atomic vortices with opposite winding numbers and building quantum entanglement in the infinite dimensional Hilbert space of atom vortex states.

Currently there are different schemes which have been shown to lead to the generation of artificial magnetic and electric fields when atoms either in free space or when trapped in optical lattices interact with suitably structured light fields [257]. In the case of free atoms, their interaction with the light results in an atomic motion that mimics that of a charged particle subject to a magnetic field. This means that the atom is subject to a Lorentz-like force [264] causing the atom to move along a closed path. How does this type of motion arise? The physical origin of this force is the creation of a Berry phase acquired by a particle moving in a closed path [265]. The realisation of artificial magnetism requires the engineering of situations where a neutral particle is made to acquire a geometrical phase when it moves along a closed path C. Thus the focus turned to the Berry phase effect in atom-light interactions [266, 267]. In this case, the atom-light coupling gives rise to the so-called dressed states [268]. These states vary on a short spatial scale (typically the wavelength of light) and so the generated artificial gauge fields can be quite intense.

Consider an atom prepared in a dressed state $| \chi ({{\bf{r}}}_{0})\rangle$ moving sufficiently slowly to follow adiabatically the local dressed state $| \chi ({{\bf{r}}}_{t})\rangle$. On completing the trajectory C, it returns to the dressed state $| \chi ({{\bf{r}}}_{0})\rangle$ having acquired a phase factor that contains a geometric component. The quantum motion of the atom is formally equivalent to that of a charged particle in a static magnetic field. Such models have been studied for different beam configurations for two-level as well as three-level atoms [264]. It is important to note that the emergence of these artificial fields requires a coherent interaction between the light fields and the atoms. Thus, the interaction time must be limited in values t < Γ ⁻¹, with Γ being the spontaneous emission rate of the excited state.

It is well established that if we make the assumption that the particle is initially prepared in the internal dressed state $| \chi ({{\bf{r}}}_{1}(t)\rangle$ and proceeds in an adiabatic elimination of the state $| \chi ({{\bf{r}}}_{2}(t)\rangle$ then the interaction of the atom with the light field is formally equivalent to the motion of a charged particle in a vector field ${\bf{B}}$ and a scalar field V(R) given by [268]

$\begin{eqnarray}&&q{\bf{B}}({\bf{R}})=-{\hslash }{{\rm{\Delta }}}_{0}\displaystyle \frac{{\rm{\Omega }}({\bf{R}})}{{({{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}}))}^{3/2}}\overrightarrow{{\rm{\nabla }}}({\rm{\Omega }}({\bf{R}}))\times \overrightarrow{{\rm{\nabla }}}(\phi ({\bf{R}})),\end{eqnarray} \tag{ 220 }$

$\begin{eqnarray}\begin{array}{rcl}V({\bf{R}}) & = & \displaystyle \frac{{{\hslash }}^{2}}{2M}\left[\displaystyle \frac{{{\rm{\Delta }}}_{0}^{2}}{{({{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}}))}^{2}}{(\overrightarrow{{\rm{\nabla }}}{\rm{\Omega }}({\bf{R}}))}^{2}\right.\\ & & \left.+\displaystyle \frac{{{\rm{\Omega }}}^{2}({\bf{R}})}{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}})}{(\overrightarrow{{\rm{\nabla }}}\phi ({\bf{R}}))}^{2}\right].\end{array}\end{eqnarray} \tag{ 221 }$

Here, Ω(R) is the Rabi frequency and ϕ(R) is the phase of the coherent light field. Note that the generation of an artificial vector field B demands that both the amplitude and the phase of the electric field have a spatial dependence and that a scenario where an atom is initially prepared in the state $| \chi ({{\bf{r}}}_{2}\rangle$ instead of $| \chi ({{\bf{r}}}_{1}\rangle$ will result in the same scalar potential energy V but opposite magnetic field B(R). The scalar potential V can be interpreted as the kinetic energy associated with the fast micromotion of the particle. This was first explained for a classical continuous internal degree of freedom by Aharonov and Stern [269]. The magnetic field is related to the Berry's phase that appears when a quantum system, here the two-state system associated with the internal degree of freedom of the particle, is slowly transported round a contour C, while remaining in one of the eigenstates of its Hamiltonian [265].

The above theory is valid in the case where the light-atom coupling strength is far larger than the recoil energy associated with the exchange of a photon between the atom and the light field, i.e, ${\hslash }{\rm{\Omega }}\gg {{\hslash }}^{2}{k}^{2}/2M$. However, when we consider the interaction of an atom with an optical vortex we need to take into account the fact that the processes of exchange between light and matter involve both linear and orbital-angular momentum. The recoil energy in this case is given by:

$\begin{eqnarray}&&{E}_{{rec}}=\displaystyle \frac{{{\hslash }}^{2}{k}^{2}}{2M}+\displaystyle \frac{{{\hslash }}^{2}{l}^{2}}{2M{\rho }^{2}}.\end{eqnarray} \tag{ 222 }$

The second term in equation (222) is due to the angular momentum exchanged for an atom localised at a radial position ρ from the beam axis. At first sight, it seems that this angular momentum should be considerably large at small radial positions. However, an LG beam has a dark core at small radial positions and thus the probability of an interaction between the beam and the atom near the core is negligibly small. The interaction probability is considerable at regions where the vortex beam intensity is large. For a LG beam, with p = 0, the intensity is maximum at the radial coordinate ${\rho }_{0}={w}_{0}\sqrt{| l| /2}$ where the ratio of the values of the angular to the translational recoil kinetic energy terms is equal to $2| l| /({k}^{2}{w}_{0}^{2})$. It is easy to see that this ratio becomes larger as either the angular momentum lℏ carried by the vortex photon becomes larger, or the beam waist w₀ becomes smaller. For the parameters and the particular atom interactions which we focus on here, the rotational recoil energy is negligible but it can be comparable to the translational recoil energy for smaller beam waists (tighter focusing) and high winding numbers.

Consider next the case where the two-level atom is irradiated by a monochromatic LG beam propagating along the z-direction and plane-polarised, say, along the x-direction. In this case the atom, which is considered to be near the focus z = 0, experiences the following artificial vector field:

$\begin{eqnarray}\begin{array}{rcl}{\bf{B}}({\bf{R}}) & = & \displaystyle \frac{{\hslash }k}{{{qw}}_{0}}\displaystyle \frac{{{\rm{\Delta }}}_{0}{{\rm{\Omega }}}^{2}({\bf{R}})}{{({{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}}))}^{3/2}}\\ & & \times \left[\left(-\displaystyle \frac{2y}{{w}_{0}^{2}}+\displaystyle \frac{{ly}}{{\rho }^{2}}\right)\hat{{\bf{x}}}+\left(\displaystyle \frac{2x}{{w}_{0}^{2}}-\displaystyle \frac{{lx}}{{\rho }^{2}}\right)\hat{{\bf{y}}}\right.\\ & & +\left.\displaystyle \frac{l({x}^{2}-{y}^{2})}{k{\rho }^{2}}\left(\displaystyle \frac{2}{{w}_{0}^{2}}-\displaystyle \frac{l}{{\rho }^{2}}\right)\hat{{\bf{z}}}\right].\end{array}\end{eqnarray} \tag{ 223 }$

The above artificial magnetic field vector has three components which appear to have a complex position dependence. But the field expressions can fortunately be simplified further. The component B_z along the z-direction has a relatively small size compared to the other two components. This is easily seen because of the dependence on k in the denominator of the B_z expression. Thus, we can safely assume that the artificial magnetic field at focus lies on the (x, y) plane. We can have a more detailed picture of the properties of this field by plotting the magnitude of the magnetic field as well as the corresponding field lines on the (x, y) plane. Figure 37 displays the magnitude of the artificial magnetic field, and the inset to this figure is a vector plot which shows the direction of the generated artificial field. We have assumed that the LG beam has a winding number l = 1. In figure 38, we also display the artificial gauge magnetic field for a Gaussian (G) beam of the same power and beam waist. The light beams have a wavelength λ = 852 nm and so can excite the transition ${6}^{2}{S}_{1/2}-{6}^{2}{P}_{3/2}$ in a ¹³³Cs atom which has an excited state transition rate Γ = 2π × 5.15 MHz. We assume that both beams have the same power, and a beam waist equal to 150 μm. The interaction is characterised by a detuning Δ₀ = 2.5Γ and a Rabi frequency Ω₀ = 9Γ. All the plots shown below have been generated using the same parameters, where the magnetic field is in units of ${B}_{0}={\hslash }k/{{qw}}_{0}^{2}$.

Zoom In Zoom Out Reset image size

Zoom In Zoom Out Reset image size

From the comparison of the two figures, namely figure 37 and figure 38, it may be deduced that the magnitude of the artificial magnetic field for a LG is larger than that for a G beam. Note, however, that as the beam winding number l increases the magnitude of the generated artificial magnetic field decreases. The magnetic field in the case of the G beam has a cylindrical symmetry with a maximum ring area. In the case of LG beam the magnetic field has cylindrical symmetry but there are two concentric rings. Moreover, the direction of the field is opposite in the two rings and can be reversed with a change of the beam winding number from l to −l. It seems that the LG beams offer more possibilities for artificial magnetic field generation. There is thus the possibility of using artificial magnetic fields generated by LG beams for the creation of extended regions where the orbital magnetism can be be sufficiently strong to generate states of non-zero circulation. This is desirable in cases where a superfluid is placed in such regions in order that its ground state will exhibit a vortex lattice. In addition to the artificial magnetic vector field, there is also a scalar artificial potential V given by:

$\begin{eqnarray}&&\begin{array}{l}V({\bf{R}})=\displaystyle \frac{{{\hslash }}^{2}}{2M}\displaystyle \frac{{{\rm{\Delta }}}_{0}^{2}{{\rm{\Omega }}}^{2}({\bf{R}})}{{({{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}}))}^{2}}\left\{{\left(\displaystyle \frac{| l| }{\rho }-\displaystyle \frac{2\rho }{{w}_{0}^{2}}\right)}^{2}\right.\\ \quad \left.+\,\left(\displaystyle \frac{{{\rm{\Delta }}}_{0}^{2}+{{\rm{\Omega }}}^{2}({\bf{R}})}{{{\rm{\Delta }}}_{0}^{2}}\right)\left[\displaystyle \frac{{l}^{2}}{{\rho }^{2}}+{\left(k-\displaystyle \frac{| l| +1}{2{z}_{R}}+\displaystyle \frac{k{\rho }^{2}}{2{z}_{R}^{2}}\right)}^{2}\right]\right\}.\end{array}\end{eqnarray} \tag{ 224 }$

Figure 39 displays the artificial scalar potential in atomic recoil energy units while the inset represents the scalar potential when the same transition is excited by a Gaussian beam with the same power and beam waist. It can be seen that the magnitude of the scalar field generated by a LG beam is smaller than that generated by the interaction of the atom with a G beam. There is however a striking difference, namely the appearance of a donut like profile of the potential in the case of a LG beam, but not in the G case. This means that the potential will affect trapping in a LG beam as much as the artificial magnetic field in the inset affects the trapping in an ordinary Gaussian optical dipole trap.

Zoom In Zoom Out Reset image size

The use of two-level atoms for the creation of artificial gauge fields has a serious drawback arising from the fact the internal state of the atom is everywhere a linear combination of the ground and the excited state. The short lifetime of the excited state imposes a limit on the existence of such potentials. We may overcome this obstacle by considering the so called 'dark sates' which are possible when we consider atoms with a three-level lambda configuration [270–272].

In the lambda configuration, we have two ground states $| 1\rangle$ and $| 2\rangle$, which can be two different hyperfine states of an atom, and an excited state $| 0\rangle$. The atom interacts with two resonant coherent beams. The first one excites the transition $| 1\rangle \leftrightarrow | 0\rangle$ while the second excites the transition $| 1\rangle \leftrightarrow | 0\rangle$. These excitations are characterized by Rabi frequencies ${{\rm{\Omega }}}_{1}({\bf{R}})\,=| {{\rm{\Omega }}}_{1}({\bf{R}})| \exp [{\phi }_{1}({\bf{R}})]$ and ${{\rm{\Omega }}}_{2}({\bf{R}})=| {{\rm{\Omega }}}_{2}({\bf{R}})| \exp [{\phi }_{2}({\bf{R}})]$ respectively. In the analysis of the artificial gauge fields with three-level atoms in the lambda-configuration, there are two factors that play important roles, namely the ratio of the two Rabi frequencies ζ and the phase difference of the two beams S. These factors are defined as follows

$\begin{eqnarray}&&S={\phi }_{1}({\bf{R}})-{\phi }_{2}({\bf{R}}),\,\,\,\,\,\,\zeta =\displaystyle \frac{{{\rm{\Omega }}}_{1}({\bf{R}})}{{{\rm{\Omega }}}_{2}({\bf{R}})}=| \zeta | \exp ({iS}).\end{eqnarray} \tag{ 225 }$

Assuming that the two ground states are at the same energy, we can neglect the two-photon detuning ${\epsilon }_{21}=0$. In this case the interaction Hamiltonian has two eigenstates—namely the dark one $| D\rangle$ and the bright one $| B\rangle$ which are given by:

$\begin{eqnarray}&&\begin{array}{l}| D\rangle =\displaystyle \frac{1}{\sqrt{1+| \zeta {| }^{2}}}(| 1\rangle -{\zeta }^{* }| 2\rangle ),\\ | B\rangle =\displaystyle \frac{1}{\sqrt{1+| \zeta {| }^{2}}}(\zeta | 1\rangle -| 2\rangle )\end{array}\end{eqnarray} \tag{ 226 }$

It has been shown that when the atom is in the dark state the artificial vector and scalar fields are given respectively by [271]:

$\begin{eqnarray}&&\begin{array}{l}q{\bf{B}}({\bf{R}})={\hslash }\displaystyle \frac{{\rm{\nabla }}S\times {\rm{\nabla }}| \zeta {| }^{2}}{{(1+| \zeta {| }^{2})}^{2}},\\ V({\bf{R}})=\displaystyle \frac{{{\hslash }}^{2}}{2M}\displaystyle \frac{{({\rm{\nabla }}| \zeta | )}^{2}+| \zeta {| }^{2}{({\rm{\nabla }}S)}^{2}}{{(1+| \zeta {| }^{2})}^{2}}.\end{array}\end{eqnarray} \tag{ 227 }$

From this, we deduce that there is a non-vanishing artificial magnetic field only when there are non-zero gradients of the relative intensity and phase. This means that such a field cannot be created using plane waves interacting with the three-level atom.

There is a deeper physical meaning of the variables and parameters involved in equation (227). The gradient ∇S is proportional to the relative momentum of the two beams, while ${({\rm{\nabla }}| \zeta | )}^{2}/{(1+| \zeta {| }^{2})}^{2}$ is a vector associated with the centre of mass of the two beams. The suggestion is that to create an artificial magnetic field the two beams must have a relative OAM. This is the key feature of the scheme which has been proposed. Note that the above formalism is valid provided that the atoms move sufficiently slowly to remain in the dark state during their motion. This is the adiabaticity requirement which is formally given by the condition Ω ≫ F with ${\rm{\Omega }}=\sqrt{| {{\rm{\Omega }}}_{1}{| }^{2}+| {{\rm{\Omega }}}_{2}{| }^{2}}$ the rms (root mean square) Rabi frequency, which characterizes the energy difference of the dark state with the remaining ones, and $F\,=| {\rm{\nabla }}\zeta \dot{{\bf{v}}}| /(1+| \zeta {| }^{2})$, where v is the velocity vector. The adiabatic condition implies that Ω⁻¹ should be much smaller than the time taken by an atom to travel a characteristic length over which the amplitude or the phase of the ratio ζ changes considerably. For atoms moving along the y-axis the relevant length is 1/k ≈ 10⁻⁷ m. On the other hand, the Rabi frequency can be of the order of 10⁷ to 10⁸ s⁻¹. Therefore, the adiabatic condition should hold for atomic velocities up to meters per second. These estimations do not take into account the possible lifetime of the dark state due to adiabatic coupling [272].

Assume that the two beams are different and carry different orbital angular momenta so they are characterized by wavevectors ${k}_{1},{k}_{2}$, winding numbers l₁, l₂ and Rabi frequencies Ω₁(R), Ω₂(R). We then have ζ = Ω₁(R)/Ω₂(R) and S = lϕ, where l = l₁ − l₂ is the difference of the beams winding numbers. This scheme generates an artificial magnetic field B given by:

$\begin{eqnarray}&&q{\bf{B}}({\bf{R}})=\displaystyle \frac{{\hslash }l}{\rho }\displaystyle \frac{1}{{(1+| \zeta {| }^{2})}^{2}}\hat{\phi }\times {\rm{\nabla }}| \zeta {| }^{2}\end{eqnarray} \tag{ 228 }$

which for fields with a cylindrical symmetry as for LG beams has the final form:

$\begin{eqnarray}&&q{\bf{B}}({\bf{R}})=-\hat{z}\displaystyle \frac{{\hslash }l}{\rho }\displaystyle \frac{1}{{(1+| \zeta {| }^{2})}^{2}}\displaystyle \frac{\partial }{\partial \rho }| \zeta {| }^{2}\end{eqnarray} \tag{ 229 }$

and there is also a scalar potential given by:

$\begin{eqnarray}&&V=\displaystyle \frac{{{\hslash }}^{2}}{2m}\displaystyle \frac{{({\rm{\nabla }}| \zeta | )}^{2}+| \zeta {| }^{2}{({\rm{\nabla }}S)}^{2}}{{(1+| \zeta {| }^{2})}^{2}}.\end{eqnarray} \tag{ 230 }$

Unfortunately this scheme again suffers from a drawback: namely that the two LG beams are simultaneously zero at points where ρ = 0. Thus the adiabaticity condition is violated. However, the scheme can be adopted when one of the two beams is a LG beam while the other one is Gaussian as shown in figure 40. This then offers the advantage that the effective magnetic field can now be shaped by choosing proper beams.

Zoom In Zoom Out Reset image size

Consider an atom irradiated by a LG beam of winding number l and a G beam. In this case, we end up with the following artificial magnetic field:

$\begin{eqnarray}&&q{\bf{B}}({\bf{R}})=\displaystyle \frac{{\hslash }| l| | \zeta {| }^{2}}{{(1+| \zeta {| }^{2})}^{2}}\left\{\displaystyle \frac{2}{\rho }\left[({k}_{1}-{k}_{2})-\displaystyle \frac{| l| }{{z}_{R}}\right]\hat{\phi }+\displaystyle \frac{2l}{{\rho }^{2}}\hat{z}\right\}.\end{eqnarray} \tag{ 231 }$

Equation (231) shows that the magnetic field is directed along the beam propagation axis, when the two beams are co-propagating with equal wave numbers so k₁−k₂ ≈ 0. By contrast, if the beams are counter-propagating then the field has an azimuthal component which dominates over the axial one. However, the azimuthal component comes mainly from the counter-propagating character of the two beams while the axial component comes from the optical angular momentum of the beam.

We now analyse the magnetic field in the case of co-propagating and counter-propagating beams when the two beams irradiate a Cs atom and excite a Λ-transition in the D2 line of the atom, where the common upper level is the 6²P_3/2 excited state while the two lower levels are the F = 3 and F = 4 hyperfine states of 6²S_1/2. As we see in figure 41, in the case of counter-propagating fields we obtain a stronger magnetic field which has a hole at the centre. This is not the case in the scenario involving co-propagating beams, but the magnetic field in that case is much weaker.

Zoom In Zoom Out Reset image size

It has been shown [272] that in this scheme, the effective magnetic flux through a circle of radius ρ₀ is given by:

$\begin{eqnarray}&&{\rm{\Phi }}=\oint {\bf{A}}d{\bf{l}}=-2\pi {\hslash }\displaystyle \frac{l| {\zeta }_{0}{| }^{2}}{{(1+| \zeta {| }^{2})}^{2}},\end{eqnarray} \tag{ 232 }$

where 2πℏ is the Dirac flux quantum, and $l| {\zeta }_{0}{| }^{2}$ is the intensity ratio at the radius ρ = ρ₀. The flux Φ reaches its maximum of 2πℏl if the ratio $| {\zeta }_{0}{| }^{2}\gg 1$, i.e. if the intensity of the probe field exceeds the control field at the selected radius ρ₀. Since the winding number of the light beams can currently be as large as several hundreds, it is possible to induce a substantial flux Φ in the atomic cloud. This might enable us to study phenomena related to filled Landau levels with a large number of atoms in quantum gases.

One case where it is possible to achieve the requirement of large gradients which is necessary for the creation of large magnitudes artificial fields is when a SOV interacts with an atom in the vicinity of a dielectric/vacuum interface [273]. As discussed earlier, it is reasonable to adopt a geometrical optics model in which the light beams involved in the total internal reflection, leading to the creation of evanescent light, are specularly reflected at the interface of a dielectric with vacuum—see figure 26. The SOVs are endowed with OAM; they are strongly localised and so have very large field gradients. These gradients depend crucially on the refractive index of the dielectric material and/or the angle of incidence of the laser beam. This gives us more control parameters with which we can monitor the properties of the artificial magnetic fields, specifically their strength and/or their spatial structure. Indeed we can choose a dielectric with a higher index of refraction, a larger angle of incidence as well as the parameters that determine the field magnitude in the free-space case like beam intensity, beam waist, Rabi frequency and detuning. There is also another parameter that will play an important role, namely the beam winding number l. It appears that as l increases the magnitude of the magnetic field increases. This point requires some detailed explanation. As the winding number increases the beam power is spread in a larger area. Thus, the intensity of the beam decreases and so does the Rabi frequency. Thus, the argument that the artificial magnetic fields become stronger as the winding number of the beam increases is true only provided that the Rabi frequency is properly adjusted, either by increasing the intensity or by decreasing the beam waist [274]. The strongest field is created if the incident angle of the plane wave is much greater than the critical angle for the total internal reflection θ_cr. Then, however, the magnetic field is considerable in a short range in vacuum [273]. This makes difficult to trap atomic clouds sufficiently far away from the surface of the prism-vacuum interface to avoid the influence of the van der Waals interaction between the atom and the dielectric material of the prism.

Artificial magnetic fields have been shown that can be used for creating atomic mirrors [273]. Typically, atom mirrors have been based on the optical dipole potential created by evanescent fields. However, in this context the atoms behave like charged particles inside an artificial magnetic field, thus they follow curved trajectories. If evanescent fields are properly tailored the atoms may be pushed away from the dielectric-vacuum interface due to a Lorentz-like force. Thus, in practice, we will have atom mirrors for three level atoms. In [273], the authors have shown that if a BEC trapped in a MOT is released and under the influence of the gravity is directed towards the prism-vacuum interface then the artificial magnetic field can act to reflect the falling atoms. Their scheme involves the interaction of a three-level atom with two coherent light fields: one an evanescent wave created by the total internal reflection of a Gaussian beam and the other is an ordinary Gaussian beam propagating in free space close to the surface. In the case of three-level atoms, very strong magnetic fields can be created when two Gaussian beams are laterally displaced. These fields can be even larger when the atoms interact with two laterally displaced evanescent fields [177]. It remains to be investigated if and how schemes involving different combinations of SOVs could lead to enhanced artificial gauge magnetic fields.

Artificial gauge fields with twisted beams have been realised in more complicated cases involving a tripod scheme of the light-atom coupling [275, 276]. This is a scheme where three laser beams drive transitions from three ground states to a common excited state. This scheme is interesting in the particular case where two of the beams are circularly polarised with opposite winding numbers l = ±1 propagating along the z-direction, while the third one is linearly polarised along the y-direction and propagates along the x-direction. In this case, the generated artificial magnetic field has a leading term which corresponds to the field of a magnetic monopole at the origin.

Finally, once again, we note that the schemes presented here concern the creation of artificial magnetic fields when twisted beams interact with atoms in free space. Such fields have also been generated for atoms trapped in optical lattices with the possibility of creating very strong artificial magnetic fields. The whole idea is based on the induction of a non-vanishing phase of atoms moving along a closed path on the lattice. This phase, proportional to the enclosed area, allows us to simulate a magnetic flux through the lattice [277]. A scheme with twisted beams based on this idea has been proposed to study realizations of a Hofstadter-Hubbard model on a cylinder geometry with fermionic cold atoms in optical lattices. The authors showed that the cylindrical optical lattices achieved with twisted beams can provide a landscape for the exhibition of fractional quantum Hall physics observed in this set-up [157].
